• Operation: stay/away arming and disarming
• Keyfob lock and unlock function
• Fully remote configurable through App
• Multiple enrollment method and easy installation design
• Easy replaceable battery with PCB protected
• Frequency hopping against jamming for reliable transmission
• Datasheet

Electrical Characteristics

• Operating Humidity: 10% to 90% (non-condensing)

• Operating Temperature: -10 °C to +55 °C (-4 °F to +122 °F)

• Battery Life Span: Up to 3 years (standby time)

Wireless Transmission

• RF Frequency: 433 MHz

• RF Modulation: 2GFSK

• RF Distance: 500 m (open area)

General

• Shell Material: Panel (plastic) + Gasket (rubber)

• Color: White

• Weight: 16 g (5.64 oz)

• 433MHz two-way wireless communication
• LCD screen and LED to indicate system status
• System configuration through LCD screen
• Multiple operations like stay/away arm, disarm, silent alarm, output control
• One-Push fire alarm, panic alarm, and medical alarm
• Full touch key design with LED backlight
• Fully remote configurable through App
• Datasheet

Hardware Features

• Tag Reader Built-In: Supported

• Serial Ports: 3

• Tamper-Proof: Supported (Front and Rear)

• Buzzer: Supported

• Power Switch: Power On/Off

Electrical Characteristics

• Battery Type: Four CR123 Batteries

• Battery Life Span: Up to 2 Years (Standby Time)

• Power Consumption:

  • Quiescent Current: 80μA

  • Max Current: 300mA

  • Voltage: 3V

• Operation Temperature: -10°C to +55°C

• Operation Humidity: 10% to 90%

Wireless Transmission

• RF Frequency: 433 MHz

• RF Modulation: 2GFSK

• RF Distance: 800m (Open Area)

• Wireless Technology: Tri-X Wireless Technology

Display & Input

• Numeric Keys:

  • Number Keys: 0–9

  • Function Keys: *, #, Query, Away Arm, Stay Arm, Disarm, Output, Project, Right, Left

• LED Indicators:

  • Fault: Orange

  • Enrollment/Signal: Red/Green

  • Arm: Blue

  • Disarm: Green

  • Alarm: Red

General

• Installation Method: Wall Mounting

• Dimensions (W × H × D): 174.63 × 109.62 × 25.25 mm

• Weight:

  • With Batteries: 348g

  • Without Batteries: 282g

• Color: White

• 90°@180° adjustable coverage
• IP65 weather resistance for outdoor application
• Active IR anti-masking
• Multiple enrollment methods and easy installation
• Frequency hopping against jamming for reliable transmission
• Datasheet

Detection Performance

• Detection Method: Passive Infrared; Microwave

• Detection Range: 15 m

• Detection Angle: 90° @ 180° adjustable

• Detection Zones: 92

• Detectable Speed: 0.3–2 m/s

• Sensitivity: Auto; Low

• White Light Filter: 10,000 lux

• Microwave Frequency: 24GHz (24.15–24.25GHz)

• Pet Immunity: 40Kg

• Digital Temperature Compensation: Support

• Anti-masking: Support

• Adaptable Coverage: Support (Pattern mask included)

Features

• Digital Processing: Tri-Signal Logic

• Sealed Optics: Support

• Tamper Protection: Front; Rear

• Environment Temperature Indicator: Support

• Signal Strength Indicator: Support

• Anti-Sway Analytics: Support

Interface

• Power Switch: Yes

• Power Up Enrolling: Yes

• LED Indicator:

  • Green (Top PIR)

  • Red (Microwave)

  • Orange (Bottom PIR)

  • Green + Orange (Mask)

  • Blue (Alarm)

Transmission

• Transmission Technology: Tri-X Wireless

• Transmission Method: Two-Way RF Wireless

• Transmission Frequency: 433MHz

• Transmission Security: AES-128 Encryption

• Transmission Range (Free Space): 1 Km

• Frequency Hopping: Support

• Enrolling Method: Power Up, Remote ID, QR Code

Electrical Characteristics

• Standard Battery Life: Up to 5 years (standby time)

  • Note: Battery life may be significantly reduced at low temperatures

• Power Supply: Battery Powered

• Battery Type: CR123A × 5

• Typical Voltage: 3V

General

• Operation Temperature: -25°C to 60°C (-13°F to 140°F)

• Storage Temperature: -25°C to 60°C (-13°F to 140°F)

• Operation Humidity: 10% to 90%

• IP Rating: IP65

• Dimensions (W × H × D): 75 mm × 202 mm × 73 mm

• Weight: 600g

• Mounting Height: 0.8 to 1.2 m

• Mounting Method: Wall

• Application Scenario: Outdoor

• Big screen display, modular design for multiple use applications
• Fully remote configurable through App
• Multiple enrollment method and easy installation design
• Frequency hopping against jamming for reliable transmission
• External probe included
• Datasheet

Detection Performance

• Detection Method: Temperature Sensor

• Detection Range:

  • -10°C to 55°C (Standalone)

  • -35°C to 99°C (With Included Probe)

Features

• Digital Processing: Support

• Tamper Protection: Front; Rear

• Environment Temperature Indicator: Support

• Signal Strength Indicator: Support

Interface

• LED Indicator: On-Screen Display

• Display Screen Size: 2.7 inch

Transmission

• Transmission Technology: Tri-X Wireless

• Transmission Method: Two-Way RF Wireless

• Transmission Frequency: 433MHz

• Transmission Security: AES-128 Encryption

• Transmission Range (Free Space): 800m

• Frequency Hopping: Support

• Enrolling Method: Power Up, Remote ID, QR Code

Electrical Characteristics

• Power Supply: Battery Powered

• Battery Type: AAA × 2

• Typical Voltage: 3V

• Standard Battery Life: Up to 2 years (standby time)

General

• Operation Temperature: -10°C to 55°C (14°F to 131°F)

• Storage Temperature: -20°C to 60°C (-4°F to 140°F)

• Operation Humidity: 10% to 90%

• Dimensions (W × H × D): 62.6mm × 62.6mm × 18mm

• Weight: 73.5g

• Mounting Method: Wall

• Application Scenario: Indoor (Standalone / With Included Probe)

• High quality chamber with photoelectric sensor
• 10 years battery life

Detection Performance

• Detection Method: Chamber with Photoelectric Sensor

Features

• Environment Temperature Indicator: Support

• Signal Strength Indicator: Support

Interface

• Power Switch: Yes

• Power Up Enrolling: Yes

• LED Indicator: Red (Alarm)

• Buzzer: ≥ 85dB @ 3m

Transmission

• Transmission Method: Two-Way RF Wireless

• Transmission Frequency: 433MHz

• Transmission Security: AES-128 Encryption

• Transmission Range (Free Space): 800m

• Enrolling Method: Power Up, Remote ID, QR Code

Electrical Characteristics

• Standard Battery Life: Up to 10 years (standby time)

• Power Supply: Battery Powered

• Battery Type: Non-replaceable CR17450 × 1

• Typical Voltage: 3V

General

• Operation Temperature: -10°C to 60°C (14°F to 140°F)

• Storage Temperature: -20°C to 60°C (-4°F to 140°F)

• Operation Humidity: 10% to 90%

• Dimensions (W × H × D): φ102 × 35mm

• Weight: 125g

• Mounting Method: Ceiling

• Application Scenario: Indoor

• PIR Detection Range: 12m / 85.9°
• Glass Break Range: 8m / 120°
• Up to 30KG pet immunity
• Fully remote configurable through App
• Multiple enrollment method and easy installation design
• Easy replaceable battery with PCB protected
• Datasheet

Detection Performance

• Detection Method: Passive Infrared; Acoustic Sensor

• Detection Range: 12m

• Detection Angle: 85.9°

• Detection Zones: 52

• Detectable Speed: 0.3–2 m/s

• Pet Immunity: 30Kg

• PIR Sensitivity: Auto, High, Pet

• White Light Filter: 6500 lux

• Glass Break Range: 8m

• Glass Type: Float, Plate, Tampered, Wired, Laminated Leaded, Double Glazing

• Glass Break Sensitivity: 2m, 4m, 6m, 8m

• Glass Thickness: 2.4mm to 6.4mm

• Glass Size: 0.3m x 0.3m to 3m x 3m

• Digital Temperature Compensation: Support

• Creep Zone Protection: Support

Features

• Digital Processing: Support

• Sealed Optics: Support

• Tamper Protection: Front; Rear

• Environment Temperature Indicator: Support

• Signal Strength Indicator: Support

Interface

• Power Switch: Yes

• Power Up Enrolling: Yes

• LED Indicator:

  • Green (PIR)

  • Red (BG)

  • Blue (Alarm)

Transmission

• Transmission Technology: Tri-X Wireless

• Transmission Method: Two-Way RF Wireless

• Transmission Frequency: 433MHz

• Transmission Security: AES-128 Encryption

• Transmission Range (Free Space): 1Km

• Frequency Hopping: Support

• Enrolling Method: Power Up, Remote ID, QR Code

Electrical Characteristics

• Standard Battery Life: Up to 4 years (standby time)

• Power Supply: Battery Powered

• Battery Type: CR123A × 2

• Typical Voltage: 3V

General

• Operation Temperature: -10°C to 55°C (14°F to 131°F)

• Storage Temperature: -20°C to 60°C (-4°F to 140°F)

• Operation Humidity: 10% to 90%

• Dimensions (W × H × D): 65.5mm × 103mm × 48.5mm

• Weight: 134g

• Mounting Height: 1.8 to 2.4m

• Mounting Method: Wall

• Application Scenario: Indoor

• Bracket: Optional Wall & Ceiling Accessory

• Detection range: 12m / 85.9°
• Up to 30KG pet immunity
• SEC (Smart Environmental Control) - Advanced digital signal processing and 3D optics
• 24/7 colorful imaging
• Large integrated memory buffer for image storage
• Fully remote configurable through App
• Multiple enrollment method and easy installation design
• Easy replaceable battery with PCB protected
• Datasheet

• Detection Range: 15m / 85.9°
• Up to 30KG pet immunity
• SEC (Smart Environmental Control) - Advanced digital signal processing and 3D optics
• Fully remote configurable through App
• Multiple enrollment method and easy installation design
• Easy replaceable battery with PCB protected
• Frequency hopping against jamming for reliable transmission
• Datasheet

• IP66 protective level, UV stable
• Fully remote configurable through App
• Multiple enrollment methods and easy installation design
• Frequency hopping against jamming for reliable transmission
• Datasheet

• Slim design for an unobtrusive (unnoticeable) installation
• Fully remote configurable through App
• Multiple enrollment methods and easy installation design
• Frequency hopping against jamming for reliable transmission
• Datasheet

• Slim design for an unobtrusive (unnoticeable) installation
• Fully remote configurable through App
• Multiple enrollment methods and easy installation design
• Frequency hopping against jamming for reliable transmission
• Datasheet

• Magnetic contact combined with shock and tilt detection
• 2 wired inputs extension
• Fully remote configurable through App
• Multiple enrollment methods and easy installation design
• Frequency hopping against jamming for reliable transmission
• Datasheet

• Slim design for an unobtrusive (unnoticeable) installation
• Fully remote configurable through App
• Multiple enrollment methods and easy installation design
• Frequency hopping against jamming for reliable transmission
• Datasheet

• Accidental press protection
• Fully remote configurable through App
• IP66 daily environment protection
• Frequency hopping against jamming for reliable transmission
• Optional lanyard and wristband accessory available
• Datasheet

• Dual effective emergency button
• Fully remote configurable through App
• Multiple enrollment methods and easy installation design
• Frequency hopping against jamming for reliable transmission
• IP66 water proof
• Datasheet

• 3D optics including creep-zone protection, full coverage without dead angle
• 24G microwave to prevent wall penetration
• Digital temperature compensation
• Fully remote configurable through App
• Multiple enrollment method and easy installation design
• Easy replaceable battery with PCB protected
• Frequency hopping against jamming for reliable transmission
• Datasheet

Detection Performance

• Detection Method: Passive Infrared / Microwave

• Detection Range: 12 m

• Detection Angle: 85.9°

• Detection Zones: 52

• Detectable Speed: 0.3 – 2 m/s

• Sensitivity: High / Auto / Pet

• Pet Immunity: Up to 30 kg

• White Light Filter: 6500 lux

• Microwave Frequency: 24 GHz (24.15 – 24.25 GHz)

• Digital Temperature Compensation: Supported

• Creep Zone Protection: Supported

• Feature - Digital Processing: Supported

• Sealed Optics: Supported

Support

• Tamper Protection: Front / Rear

• Environment Temperature Indicator: Supported

• Signal Strength Indicator: Supported

Interface

• Power Switch: Power Up Enrolling

• LED Indicator:

  • Green (PIR)

  • Red (Microwave)

  • Blue (Alarm)

Transmission

• Transmission Technology: Tri-X Wireless

• Transmission Method: Two-Way RF Wireless

• Transmission Frequency: 433 MHz

• Transmission Security: AES-128 Encryption

• Transmission Range (Free Space): 1.2 km

• Frequency Hopping: Supported

• Enrolling Method: Power Up / Remote ID / QR Code

Electrical Characteristics

• Standard Battery Life: Up to 5 years (standby time)

• Power Supply: Battery Powered

• Battery Type: CR123A × 2

• Typical Voltage: 3 V

General

• Operating Temperature: -10°C to 55°C (14°F to 131°F)

• Storage Temperature: -20°C to 60°C (-4°F to 140°F)

• Operating Humidity: 10% to 90%

• Dimensions (W × H × D): 65.5 mm × 103 mm × 48.5 mm

• Weight: 141 g

• Mounting Height: 1.8 to 2.4 m

• Mounting Method: Wall

• Application Scenario: Indoor

• Bracket: Optional Wall & Ceiling Accessory

• 1/2.7" Progressive Scan CMOS
• 2.0 mm fixed lens
• 3D Digital Noise Reduction
• Easy Installation
• The direction of the Angle can be adjusted to fit the TT Detector's Angle
• Protection Level IP66
• Datasheet

Detection Performance

• Detection Method: Video Verification

Feature

• Digital Noise Reduction: 3D

Optics

• Focal Length: 2.0 mm @ F2.25

Video

• Field of View:

  • Horizontal: 137.2°

  • Vertical: 80.1°

• Image Type: JPEG

• Resolution Options:

  • 640 × 480

  • 320 × 240

  • 160 × 120

• Fill Light: Infrared Light

• Fill Light Range: 15 m

• Day/Night Switch: Auto

Interface

• Communication Interface: 1 × 12-Bit Data Interface

Electrical Characteristics

• Power Supply: 3 VDC

• Power Consumption: 1200 mA

General

• Operating Temperature: -25°C to 60°C (-13°F to 140°F)

• Storage Temperature: -25°C to 60°C (-13°F to 140°F)

• Operating Humidity: 10% to 90%

• IP Rating: IP66

• Dimensions (W × H × D): 74.1 mm × 72.35 mm × 53 mm

• Weight: 155 g

• Detection Range: 12m / 360°
• SEC (Smart Environmental Control) - Advanced digital signal processing and 3D optics
• Fully remote configurable through App
• Multiple enrollment method and easy installation design
• Easy replaceable battery with PCB protected
• Frequency hopping against jamming for reliable transmission
• Datatsheet

• Long range with narrow angle detection
• Fully remote configurable through App
• Multiple enrollment method and easy installation design
• Easy replaceable battery with PCB protected
• Frequency hopping against jamming for reliable transmission
• Datasheet

Detection Performance

• Detection Method: Passive Infrared

• Detection Range: 15 m

• Detection Angle: 6.3°

• Detection Zones: 18

• Detectable Speed: 0.3 – 2 m/s

• Pet Immunity: None

• White Light Filter: 6500 lux

• Digital Temperature Compensation: Supported

• Creep Zone Protection: Supported

• Feature - Digital Processing: Supported

• Sealed Optics: Supported

Support

• Tamper Protection: Front / Rear

• Environment Temperature Indicator: Supported

• Signal Strength Indicator: Supported

Interface

• Power Switch: Power Up Enrolling

• LED Indicator: Blue (Alarm)

Transmission

• Transmission Technology: Tri-X Wireless

• Transmission Method: Two-Way RF Wireless

• Transmission Frequency: 433 MHz

• Transmission Security: AES-128 Encryption

• Transmission Range (Free Space): 1.2 km

• Frequency Hopping: Supported

• Enrolling Method: Power Up / Remote ID / QR Code

Electrical Characteristics

• Standard Battery Life: Up to 5 years (standby time)

• Power Supply: Battery Powered

• Battery Type: CR123A × 1

• Typical Voltage: 3 V

General

• Operating Temperature: -10°C to 55°C (14°F to 131°F)

• Storage Temperature: -20°C to 60°C (-4°F to 140°F)

• Operating Humidity: 10% to 90%

• Dimensions (W × H × D): 65.5 mm × 103 mm × 48.5 mm

• Weight: 128 g

• Mounting Height: 2.4 to 3.6 m

• Mounting Method: Wall

• Application Scenario: Indoor

• Bracket: Optional Wall & Ceiling Accessory

• Slim design for window frame installation
• IP65 weather resistance for outdoor application
• Active IR anti-masking
• Directional detection support
• Multiple enrollment methods and easy installation
• Frequency hopping against jamming for reliable transmission
• Datasheet

Detection Performance

• Detection Method: Passive Infrared / Microwave

• Detection Range:

  • Wall mount: 10 m

  • Ceiling mount: 5 m

• Detection Angle: 5°

• Detection Zones: 32

• Detectable Speed: 0.3 – 2 m/s

• Sensitivity: Auto / Pet

• White Light Filter: 6500 lux

• Microwave Frequency: 24 GHz (24.15 – 24.25 GHz)

• Pet Immunity:

  • Wall mount: 12 kg

  • Ceiling mount: None

• Digital Temperature Compensation: Supported

• Creep Zone Protection: Supported

• Anti-masking: Supported

• Feature - Digital Processing: Supported

• Sealed Optics: Supported

Support

• Tamper Protection: Front / Rear

• Environment Temperature Indicator: Supported

• Signal Strength Indicator: Supported

• Directional Detection: Supported

Interface

• Power Switch: Power Up Enrolling

• LED Indicator:

  • Green (PIR)

  • Red (Microwave)

  • Green + Orange (Mask)

  • Blue (Alarm)

Transmission

• Transmission Technology: Tri-X Wireless

• Transmission Method: Two-Way RF Wireless

• Transmission Frequency: 433 MHz

• Transmission Security: AES-128 Encryption

• Transmission Range (Free Space): 1 km

• Frequency Hopping: Supported

• Enrolling Method: Power Up / Remote ID / QR Code

Electrical Characteristics

• Standard Battery Life: Up to 5 years (standby time)

  Note: Battery life may be significantly reduced at low temperatures.

• Power Supply: Battery Powered

• Battery Type: CR123A × 2

• Typical Voltage: 3 V

General

• Operating Temperature: -25°C to 60°C (-13°F to 140°F)

• Storage Temperature: -25°C to 60°C (-13°F to 140°F)

• Operating Humidity: 10% to 90%

• IP Rating: IP65

• Dimensions (W × H × D): 29.2 mm × 134.4 mm × 39.5 mm

• Weight: 120 g

• Mounting Height: 2 m to 3.5 m

• Mounting Method: Wall / Ceiling

• Application Scenario: Indoor / Outdoor

• Bracket: L-shaped adapter included

• Slim design for window frame installation
• IP65 weather resistance for outdoor application
• Active IR anti-masking
• Directional detection support
• Multiple enrollment methods and easy installation
• Frequency hopping against jamming for reliable transmission
• Datasheet

Detection Performance

• Detection Method: Passive Infrared

• Detection Range:

  • Wall mount: 10 m

  • Ceiling mount: 5 m

• Detection Angle: 5°

• Detection Zones: 32

• Detectable Speed: 0.3 – 2 m/s

• Sensitivity: Auto / Pet

• White Light Filter: 6500 lux

• Pet Immunity:

  • Wall mount: 12 kg

  • Ceiling mount: None

• Digital Temperature Compensation: Supported

• Creep Zone Protection: Supported

• Anti-masking: Supported

• Feature - Digital Processing: Supported

• Sealed Optics: Supported

Support

• Tamper Protection: Front / Rear

• Environment Temperature Indicator: Supported

• Signal Strength Indicator: Supported

• Directional Detection: Supported

Interface

• Power Switch: Power Up Enrolling

• LED Indicator:

  • Blue (Alarm)

  • Green + Orange (Mask)

Transmission

• Transmission Technology: Tri-X Wireless

• Transmission Method: Two-Way RF Wireless

• Transmission Frequency: 433 MHz

• Transmission Security: AES-128 Encryption

• Transmission Range (Free Space): 1 km

• Frequency Hopping: Supported

• Enrolling Method: Power Up / Remote ID / QR Code

Electrical Characteristics

• Standard Battery Life: Up to 5 years (standby time)

  Note: Battery life may be significantly reduced at low temperatures.

• Power Supply: Battery Powered

• Battery Type: CR123A × 2

• Typical Voltage: 3 V

General

• Operating Temperature: -25°C to 60°C (-13°F to 140°F)

• Storage Temperature: -25°C to 60°C (-13°F to 140°F)

• Operating Humidity: 10% to 90%

• IP Rating: IP65

• Dimensions (W × H × D): 29.2 mm × 134.4 mm × 39.5 mm

• Weight: 118.5 g

• Mounting Height: 2 m to 3.5 m

• Mounting Method: Wall / Ceiling

• Application Scenario: Indoor / Outdoor

• Bracket: L-shaped adapter included

• Panoramic channel supports image stitching, with 180° horizontal field of view
• High quality imaging with 6 MP resolution in panoramicand channel and 4 MP resolution in PTZ channel
• Secures an expansive area with 32 × optical zoom and 16 × digital zoom
• AcuSense technology focuses on human and vehicle targets classification and supports face capture to detect, capture and select faces in motion
• Expansive night view with up to 200 m IR distance in PTZ channel and 30 m white light in panoramic channel
• Active strobe light and audio alarm to warn intruders off
• Smart-linkage between panoramic channel and PTZ channel
• Datasheet

Camera Specifications

Image Sensor:

• Panoramic Channel: 1/2.5" Progressive Scan CMOS

• PTZ Channel: 1/2.8" Progressive Scan CMOS

Max. Resolution:

• Panoramic Channel: 3632 × 1632

• PTZ Channel: 2560 × 1440

Min. Illumination:

• PTZ Channel: Color: 0.005 Lux @ (F1.5, AGC ON), B/W: 0.001 Lux @ (F1.5, AGC ON), 0 Lux with IR

• Panoramic Channel: Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with Light

Shutter Speed: 1 s to 1/30,000 s
Day & Night: IR cut filter
Zoom: 32× optical, 16× digital
Slow Shutter: Yes
HLC: Yes
3D DNR: Yes

Lens Specifications

Focal Length:

• Panoramic Channel: 2.8 mm

• PTZ Channel: 5.9 mm to 188.8 mm

FOV:

• Panoramic Channel: Horizontal field of view: 180° ±10°, Vertical field of view: 80° ±5°

• PTZ Channel: Horizontal field of view: 60.2° to 2.3°

Focus: Auto, Semi-auto, Manual
Aperture:

• Panoramic Channel: F1.0

• PTZ Channel: Max. F1.5

Zoom Speed:

• Panoramic Channel: No

• PTZ Channel: Approx. 5.6 s

Illuminator

Supplement Light Range:

• IR Distance: Up to 200 m

• White Light Distance:

  • Panoramic Channel: 30 m

PTZ Specifications

Movement Range (Pan): 360°
Movement Range (Tilt): -15° to 90°
Pan Speed: Configurable from 0.1° to 160°/s, Preset speed: 240°/s
Tilt Speed: Configurable from 0.1° to 120°/s, Preset speed: 200°/s
Proportional Pan: Yes
Presets: 300
Preset Freezing: Yes
Patrol Scan: 8 patrols, up to 32 presets for each patrol
Pattern Scan: 4 pattern scans, record time over 10 minutes for each scan
Park Action: Preset, Pattern scan, Patrol scan, Auto scan, Tilt scan, Random scan, Frame scan, Panorama scan
3D Positioning: Yes
PTZ Status Display: Yes
Scheduled Task: Preset, Pattern scan, Patrol scan, Auto scan, Tilt scan, Random scan, Frame scan, Panorama scan, Dome reboot, Aux output, Dome adjust
Power-off Memory: Yes

Video Specifications

Main Stream:

• PTZ Channel:

  • 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

  • 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

• Panoramic Channel:

  • 50 Hz: 25 fps (3632 × 1632, 3680 × 1656)

  • 60 Hz: 30 fps (3632 × 1632, 3680 × 1656)

Sub-Stream:

• PTZ Channel:

  • 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)

  • 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

• Panoramic Channel:

  • 50 Hz: 25 fps (1200 × 536, 960 × 432)

  • 60 Hz: 30 fps (1200 × 536, 960 × 432)

Third Stream:

• PTZ Channel:

  • 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)

  • 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

• Panoramic Channel: No

Video Compression:

• Main stream: H.265+/H.265/H.264+/H.264

• Sub-stream: H.265/H.264/MJPEG

• Third stream: H.265/H.264/MJPEG

Video Bit Rate: 32 Kbps to 16384 Kbps
H.264 Type: Baseline Profile, Main Profile, High Profile
H.265 Type: Main Profile
Scalable Video Coding (SVC): Yes
Region of Interest (ROI): Fixed region

Audio Specifications

Audio Compression:

• G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC, MP3

Audio Bit Rate:

• 32 to 192 Kbps (MP2L2)

• 16 to 64 Kbps (AAC-LC)

• 8 to 320 Kbps (MP3)

Audio Sampling Rate: 8 kHz, 16 kHz, 32 kHz, 48 kHz
Environment Noise Filtering: Yes

Network Specifications

Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, WebSocket, WebSockets, SRTP

Simultaneous Live View: 20
API: ISUP, SDK, ISAPI, Open Network Video Interface (Profile S, Profile G, Profile T)
User/Host: 32

Network Storage: NAS (NFS, SMB/CIFS), Auto network replenishment (ANR)
Client: iVMS-4200, HikCentral Pro, Hik-Connect
Web Browser: IE 11+, Chrome 57+, Firefox 52+, Safari 12+, Edge 79.0.309.65+

Image Settings

Image Parameters Switch: Yes
Image Settings: Saturation, brightness, contrast, sharpness
Day/Night Switch: Day, night, auto, schedule
Wide Dynamic Range (WDR):

• Panoramic Channel: Digital WDR

• PTZ Channel: 120 dB

SNR: > 52 dB
Defog: Yes
Image Stabilization: Yes
Image Enhancement: BLC, HLC, 3D DNR
Privacy Mask: 24 programmable polygon privacy masks, mask color or mosaic configurable
Regional Focus: Yes
Regional Exposure: Yes

Interface

Ethernet Interface: 1 RJ45 10/100M self-adaptive Ethernet port
On-board Storage: Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB
Audio:

• 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%

• 1 output (line out), line level, output impedance: 600 Ω
  Alarm: 2 input(s), 1 output(s)
  Reset: Yes

Event Specifications
