MARS new DUAL BAND and DUAL POL antenna specially designed for arenas and stadiums that have to supply high capacity and reliable wireless data. MARS MA-WA82220-DBDP14 provides solutions for services such as LTE, Cellular (2G, 2.5G and 3G), Wi-Fi and WiMAX applications. The antenna is PIM certified, thus making it suitable for all multi-carrier systems.

FEATURES:

• Provides a 12dBi gain for 698-960MHz
• Provides a 13dBi gain for 1700-2700MHz

Additional Features:

• Efficient and stable performance with 12-13 dBi of gain.
• UV protected radome suitable for harsh environment installations
• Durable construction
• Easy mounting allowing Az/El adjustment
• Aesthetic design
• Weatherized and durable
• Wind survival rating of 200 km/h

The Laird FG9026 900 MHz omnidirectional antenna is designed for use as an LPWAN base station antenna. Covering the full 915 MHz ISM band from 902 to 928 MHz the antenna has been optimised for LPWAN IoT networks. It uses a finely tuned collinear stacked-dipole design which ensures maximum radiated efficiency and stability across the 915 MHz band. Laird's fiberglass base station antennas are collinear designs enclosed in high-density fiberglass, which is covered with a protective ultraviolet inhibiting coating. The radiating elements are made from high-efficiency copper and are carefully phased to provide maximum gain in the horizontal plane.   The mounting sleeves are tuned to eliminate RF currents from the transition line.  This results in a "cold" sleeve allowing great freedom in mounting.  This high-quality and well-focused beam provides the highest gain and best efficiency.

FEATURES:

• Tuned specifically for 915 MHz ISM IoT LPWANs
• Easy installation
• Weatherproof, UV-stabilised radome
• N Female connector

Mounting kit sold separately.

The Laird Connectivity FG9026 Omni-Directional Antenna 900MHz 8dBi applications are used by private organizations and government agencies around the globe.  Typical applications include land-based and marine radio and data transmissions for public safety agencies, commercial organizations, and the military.

Please allow 12 weeks lead time. Small omni-directional outdoor antenna for WiFi and industrial 5G applications.

FEATURES:

• Supports all Wi-Fi 6E bands.
• Supports the 3.7-3.8 GHz industrial 5G application.
• Fire retardant acc. to DIN 5510-2, BS 6853, NF F16-101/102, EN 45545-2.
• Rugged design with single hole mounting.

The Huber+Suhner Sencity 8dBi Dual-Band Omni WiFi Antenna, 2.4GHz amp; 5GHz is 50.6mm high x86mm in diameter

Please allow 4-6 weeks lead time. Omni-directional WiFi stick antenna.

FEATURES:

• IEEE 802.11 b/g, frequency band 2.4 - 2.5 GHz
• WiFi wireless LAN / WLAN
• Gain 6 dBi, vertically polarized antenna
• Ingress protection IP 67 (IEC 60529)
• For outdoor and indoor applications
• Pole or wall mount

The Huber+Suhner Sencity 6dBi Omni WiFi Antenna, 2.4GHz radome comes in a signal white colour and is made of glass fibre PORTS

Please allow 6-8 weeks lead time. Omni-directional dual-band WiFi stick antenna for application with WiFi standards.

FEATURES:

• IEEE 802.11 a/p/h/b/g/y/n/ac
• Working in the frequency bands 2.3 - 2.5 GHz and 4.8 to 6 GHz.
• Gain 6 dBi, vertically polarized antenna.
• Ingress protection IP 67 (IEC 60529).
• For outdoor and indoor applications.
• Wall or pole mount with L-bracket.

The Huber+Suhner Sencity 6dBi Dual-Band Omni WiFi Antenna, 2.4GHz amp; 5GHz operates in -40 °C to +85 °C and can be stored in -55 °C to +85 °C PORTS

Please allow 4-6 weeks lead time. Omni-directional WiFi antenna.

FEATURES:

• IEEE 802.11 a/h, frequency band: 5.15 to 5.875 GHz
• Wireless LAN / Wi-Fi WLAN
• Indoor and outdoor applications - IP67
• Pole/mast and wall mount

The Huber+Suhner Sencity 6dBi Omni WiFi Antenna, 5GHz randome comes in a grey-white colour and is made of polypropylene PORTS

Please allow 4-6 weeks lead time. Railway rooftop antenna for 2G/3G/4G/5G cellular and Wi-Fi 4/Wi-Fi 6 bands.

FEATURES:

• Multiple Antenna installations support Cellular and Wi-Fi MIMO.
• Rugged design meets EN 50155 Railway Standard.
• Fire retardant according to EN 45545-2 and NFPA-130.
• Dedicated grounding contact (optional).
• Cable conduit support (optional).

The Huber+Suhner 3G-5G Sencity Rail Antenna, 1x1 SISO operates in -55 °C to +85 °C and can be stored within the same temperature.  Survives wind speed of 500 km/h PORTS

Please allow 6-8 week lead time. Rugged vehicle rooftop multi-band antenna

FEATURES:

• Suitable for heavy-duty vehicles like buses and trucks.
• Supports 2G/3G/4G cellular bands
• 2x2 MIMO
• GPS/ GLONASS
• Single-hole mounting, easy cable feed-through

The Huber+Suhner 3G-4G Sencity Road Antenna, 2x2 MIMO + GNSS operates and can be stored in -40 °C to +85 °C.  It made from acrylic ester-styrene-acrylonitrile and is dark grey.
