• High quality imaging with 8 MP resolution
• Excellent low-light performance with powered-by-DarkFighter technology
• Efficient H.265+ compression technology
• Clear imaging against strong back light by 120 dB true WDR technology
• Focus on human and vehicle targets classification based on deep learning
• Water and dust resistant (IP67)


Camera Specifications

Image Sensor

• Type: 1/1.8" Progressive Scan CMOS
• Max Resolution: 3840 × 2160
• Min Illumination:
  • Color: 0.003 Lux @ (F1.6, AGC ON)
  • B/W: 0 Lux with IR
• Shutter Time: 1/3 s to 1/100,000 s
• Day & Night: IR cut filter
• Angle Adjustment:
  • Pan: 0° to 360°
  • Tilt: 0° to 90°
  • Rotate: 0° to 360°

Lens

• Type: Fixed focal lens (2.8 mm, 4 mm, 6 mm optional)
• Focal Length & Field of View (FOV):
  • 2.8 mm: Horizontal 111°, Vertical 59°, Diagonal 131°
  • 4 mm: Horizontal 87°, Vertical 47°, Diagonal 102°
  • 6 mm: Horizontal 51°, Vertical 28°, Diagonal 60°
• Mount: M12
• Iris: Fixed
• Aperture: F1.6

DORI (Detection, Observation, Recognition, Identification)

• 2.8 mm:
  • Detection: 89.2 m
  • Observation: 35.4 m
  • Recognition: 17.8 m
  • Identification: 8.9 m
• 4 mm:
  • Detection: 99.4 m
  • Observation: 39.4 m
  • Recognition: 19.9 m
  • Identification: 9.9 m
• 6 mm:
  • Detection: 140.0 m
  • Observation: 55.6 m
  • Recognition: 28.0 m
  • Identification: 14.0 m

Illuminator

• Supplement Light Type: IR
• Supplement Light Range:
  • -2I: Up to 60 m
  • -4I: Up to 80 m
• Smart Supplement Light: Yes
• IR Wavelength: 850 nm

Video

• Main Stream:

  • 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
  • 60 Hz: 24 fps (3840 × 2160), 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

• Sub-Stream:

  • 50 Hz: 25 fps (640 × 480, 640 × 360)
  • 60 Hz: 30 fps (640 × 480, 640 × 360)

• Third Stream:

  • 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
  • 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
  • Note: Third stream is supported under certain settings.

• Video Compression:

  • Main: H.265/H.264/H.264+/H.265+
  • Sub: H.265/H.264/MJPEG
  • Third: H.265/H.264

• Video Bit Rate: 32 Kbps to 16 Mbps

• H.264 Type: Baseline/Main/High Profile

• H.265 Type: Main Profile

• Bit Rate Control: CBR/VBR

• Scalable Video Coding (SVC): H.264 and H.265 encoding

• Region of Interest (ROI): 1 fixed region for main and sub-stream

• Target Cropping: Yes

Network

• Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP
• Simultaneous Live View: Up to 6 channels
• API: Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
• User/Host: Up to 32 users (Administrator, Operator, User levels)
• Security:
  • Password protection, HTTPS encryption
  • IP address filtering, Security Audit Log
  • TLS 1.1/1.2, WSSE and digest authentication

Storage

• Network Storage: MicroSD/SDHC/SDXC (256 GB), NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
• Compatibility: Supports Hikvision memory card for encryption and health detection.


• Image Settings:
  • Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance
  • Adjustable via client software or web browser
• Day/Night Switch: Day, Night, Auto, Schedule
• Wide Dynamic Range (WDR): 120 dB
• Signal-to-Noise Ratio (SNR): ≥ 52 dB
• Image Enhancement: BLC, HLC, 3D DNR

Interface

• Ethernet: 1 RJ45 10 M/100 M self-adaptive port
• On-Board Storage: Micro SD slot (up to 256 GB)
• Reset Key: Yes

Event

• Basic:
  • Motion detection (human and vehicle classification)
  • Video tampering alarm, exception
• Smart:
  • Line crossing, intrusion, region entrance/exit detection (human and vehicle triggers)
  • Scene change detection
• Linkage: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording or capture

General

• Power:

  • -2I:
    • 12 VDC ± 25%, Max 7.5 W
    • PoE: IEEE 802.3af, Class 3, Max 9 W
  • -4I:
    • 12 VDC ± 25%, Max 10.5 W
    • PoE: IEEE 802.3af, Class 3, Max 12 W

• Dimension: Ø105 mm × 290 mm (Ø4.1" × 11.4")

• Package Dimension: 386 mm × 156 mm × 155 mm (15.2" × 6.1" × 6.1")

• Weight: Approx. 1270 g (2.8 lb.)

Approval

• EMC: FCC, CE-EMC, RCM, KC
• Safety: UL, CB, CE-LVD
• Environment: CE-RoHS, WEEE, REACH
• Protection: IP67
