4 MP AcuSense Strobe Light and Audible Warning Fixed Bullet Network Camera

Warranty: 3 Year Hikvision ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Ubiquiti UniFi G5 Turret Ultra,Black. Ultra-compact, Tamper-resistant IK04, IP66 Weatherproof 2K HD PoE Camera, Long-range Night Vision

Warranty: 1 Year Manufacturer Warranty

Prices include GST. Professional installation available.

Ubiquiti G6 Dome Camera Weather Shield, White, G6 Dome Camera Accessory, Optimal image Quality, Protection Elements, Installed Outdoors, Wall, Pole.

Warranty: 1 Year Manufacturer Warranty

Prices include GST. Professional installation available.

Ubiquiti G5 Dome Camera Ultra Flush Mount,White, Accessory For Recessed Instal Into A Wall/Ceiling With Smoked Bubble Enhanced Discretion

Warranty: 1 Year Manufacturer Warranty

Prices include GST. Professional installation available.

Ubiquiti G5 Dome Camera Ultra Flush Mount,Black,Accessory For Recessed Instal Into A Wall/Ceiling With Smoked Bubble Enhanced Discretion

Warranty: 1 Year Manufacturer Warranty

Prices include GST. Professional installation available.

Ubiquiti Bullet Camera Angled Base, Mounting Accessory Enhances Tilt Angle by 22°, Achieve Unrestricted Viewing Angle, White

Warranty: 1 Year Manufacturer Warranty

Prices include GST. Professional installation available.

Ubiquiti G6 Pro Turret, White, All-Weather Tamper-Resistant 4K PoE+Cam, AI Engine, 2.36x Optic Zoom,1/1.2'CMOS, Light Clarity,L-Range IR Night Vision

Warranty: 1 Year Manufacturer Warranty

Prices include GST. Professional installation available.

Ubiquit UniFi Protect Cam Dome Camera G5 3-Pack, 2K HD PoE Ceiling Camera, Polycarbonate Housing, Partial Outdoor, Vandal resistant

Warranty: 1 Year Manufacturer Warranty

Prices include GST. Professional installation available.

4MP 4× Starlight IR WizSense Network PTZ Camera

Key Features

• 1/2.8" 4 MP CMOS image sensor

• 4× optical zoom

• Starlight low-light technology

• Max. 25/30 fps @ 4 MP

• IR illumination up to 20 m

• Perimeter protection (IVS)

• Face detection

• SMD 3.0

• Built-in microphone

• IP66 weatherproof, IK08 vandal-resistant

• Datasheet

Camera

Image Sensor

• Sensor Type: 1/2.8" CMOS

• Effective Pixels: 4 MP

• Max. Resolution: 2560 (H) × 1440 (V)

• Scanning System: Progressive

• Electronic Shutter: 1 s–1/30,000 s

• ROM: 256 MB

• RAM: 512 MB

Minimum Illumination

• Color: 0.005 lux @ F1.8 (30 IRE)

• B/W: 0.0005 lux @ F1.8 (30 IRE)

• 0 lux (IR on)

Illumination

• IR Distance: Up to 20 m (65.62 ft)

• IR LEDs: 3

• IR Control: Manual / SmartIR / Off

Lens

• Focal Length: 2.8 mm–12 mm

• Optical Zoom: 4×

• Max. Aperture: F1.8–F2.7

• Field of View:

  • Horizontal: 96.9°–31.6°

  • Vertical: 51.4°–17.8°

  • Diagonal: 116.2°–36.4°

• Focus Control: Auto / Semi-auto / Manual

• Close Focus Distance: 0.2 m–0.5 m

• Iris Control: Fixed

DORI Performance (EN-62676-4)

• Detect: 240 m (787.40 ft)

• Observe: 94.8 m (311.02 ft)

• Recognize: 48 m (157.48 ft)

• Identify: 24 m (78.74 ft)

DORI values do not represent intelligent function distances.

PTZ

• Pan Range: 0°–355°

• Tilt Range: 5°–90°

Speed

• Manual Pan: 0.1°/s–70°/s

• Manual Tilt: 0.1°/s–30°/s

• Preset Pan: 0.1°/s–80°/s

• Preset Tilt: 0.1°/s–40°/s

Functions

• Presets: 300

• Tours: 8 (up to 32 presets per tour)

• Power-off Memory: Yes

• Idle Motion: Preset / Tour

• PTZ Protocol: DH-SD

• PTZ Lock: Yes

Intelligent Functions

IVS (Perimeter Protection)

• Tripwire

• Intrusion

• Crossing fence

• Loitering detection

• Abandoned/missing object

• Fast moving

• Parking detection

• People gathering

• Human classification

Face Detection

• Face detection, snapshot, enhancement

• Face cutout: Face / one-inch photo

• Capture modes: Real-time / Quality priority

People Counting

• Line crossing counting

• Area counting

• Queue management

• Reporting supported for line crossing only

SMD

• SMD 3.0 supported

Video

Compression

• H.264H / H.264B / H.264

• H.265

• Smart H.264+ / Smart H.265+

• MJPEG (sub-stream)

Streaming

• Triple stream

Resolution

• 4M (2560 × 1440)

• 3M (2304 × 1296)

• 1080p, 1.3M, 720p

• D1, VGA, CIF

Frame Rate

• Main Stream: up to 25/30 fps

• Sub Stream 1: D1/VGA/CIF @ 25/30 fps

• Sub Stream 2: 720p @ 25/30 fps

Bit Rate

• Control: CBR / VBR

• H.264: 96 Kbps–14,848 Kbps

• H.265: 38 Kbps–8,960 Kbps

Image Processing

• Day/Night: ICR / Electronic (Color / B/W / Auto)

• WDR: 120 dB

• BLC / HLC: Supported

• White Balance: Auto, Indoor, Outdoor, Tracking, Manual, Sodium Lamp, Natural Light, Street Lamp

• Gain Control: Auto / Manual / Gain Priority

• Noise Reduction: 2D NR / 3D NR

• Motion Detection: Yes

• ROI: Yes

• EIS: Supported

• Defog: Electronic

• Digital Zoom: 16×

• Image Rotation: 180°

• S/N Ratio: ≥55 dB

• Privacy Masking: Up to 24 areas (8 per view, 8 colors)

Audio

• Compression: PCM, G.711A/U, G.726, MPEG-2 Layer II, G.722.1

• Audio I/O: 1 in / 1 out

• Built-in Mic: Yes (shared with audio input)

Network

• Ethernet: RJ-45 (10/100 Base-T)

• Protocols: IPv4/IPv6, TCP/IP, HTTP/HTTPS, RTSP, RTP, FTP, NTP, SNMP, QoS, DHCP, DDNS, ONVIF, and more

• Interoperability: ONVIF (Profile S/G/T), CGI, SDK

• Max Users: 20 (64 Mbps total bandwidth)

Storage

• Micro SD Card: Up to 512 GB

• Network Storage: FTP / SFTP / NAS

Software & Compatibility

• Web Browsers: IE9+, Chrome 41+, Firefox 52+, Safari 10+

• Management Software: DMSS, DSS Pro

• Mobile App: iOS / Android

Alarm & Events

• Alarm Actions: Snapshot, recording, email, preset, tour

• Events: Motion, tampering, audio detection, network disconnection, IP conflict, SD card status

Power

• Power Supply: 12 VDC ±10%, 2 A

• PoE: IEEE 802.3af

• Power Consumption:

  • Typical: 4 W

  • Max: 13 W (IR on)

Environment

• Operating Temperature: –30 °C to +60 °C

• Operating Humidity: ≤95%

• Protection: IP66, IK08, TVS 6000 V lightning protection, surge & transient protection

Physical

• Dimensions: 65.7 mm × Ø128.0 mm

• Net Weight: 0.5 kg

• Gross Weight: 0.7 kg

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

4MP 4× Starlight IR WizSense Network PTZ Camera

Key Features

• 1/2.8" 4 MP CMOS image sensor

• 4× optical zoom

• Starlight low-light technology

• Max. 25/30 fps @ 4 MP

• IR illumination up to 20 m

• Perimeter protection (IVS)

• Face detection

• SMD 3.0

• Built-in microphone

• IP66 weatherproof, IK08 vandal-resistant

• Datasheet

Camera

Image Sensor

• Sensor Type: 1/2.8" CMOS

• Effective Pixels: 4 MP

• Max. Resolution: 2560 (H) × 1440 (V)

• Scanning System: Progressive

• Electronic Shutter: 1 s–1/30,000 s

• ROM: 256 MB

• RAM: 512 MB

Minimum Illumination

• Color: 0.005 lux @ F1.8 (30 IRE)

• B/W: 0.0005 lux @ F1.8 (30 IRE)

• 0 lux (IR on)

Illumination

• IR Distance: Up to 20 m (65.62 ft)

• IR LEDs: 3

• IR Control: Manual / SmartIR / Off

Lens

• Focal Length: 2.8 mm–12 mm

• Optical Zoom: 4×

• Max. Aperture: F1.8–F2.7

• Field of View:

  • Horizontal: 96.9°–31.6°

  • Vertical: 51.4°–17.8°

  • Diagonal: 116.2°–36.4°

• Focus Control: Auto / Semi-auto / Manual

• Close Focus Distance: 0.2 m–0.5 m

• Iris Control: Fixed

DORI Performance (EN-62676-4)

• Detect: 240 m (787.40 ft)

• Observe: 94.8 m (311.02 ft)

• Recognize: 48 m (157.48 ft)

• Identify: 24 m (78.74 ft)

DORI values do not represent intelligent function distances.

PTZ

• Pan Range: 0°–355°

• Tilt Range: 5°–90°

Speed

• Manual Pan: 0.1°/s–70°/s

• Manual Tilt: 0.1°/s–30°/s

• Preset Pan: 0.1°/s–80°/s

• Preset Tilt: 0.1°/s–40°/s

Functions

• Presets: 300

• Tours: 8 (up to 32 presets per tour)

• Power-off Memory: Yes

• Idle Motion: Preset / Tour

• PTZ Protocol: DH-SD

• PTZ Lock: Yes

Intelligent Functions

IVS (Perimeter Protection)

• Tripwire

• Intrusion

• Crossing fence

• Loitering detection

• Abandoned/missing object

• Fast moving

• Parking detection

• People gathering

• Human classification

Face Detection

• Face detection, snapshot, enhancement

• Face cutout: Face / one-inch photo

• Capture modes: Real-time / Quality priority

People Counting

• Line crossing counting

• Area counting

• Queue management

• Reporting supported for line crossing only

SMD

• SMD 3.0 supported

Video

Compression

• H.264H / H.264B / H.264

• H.265

• Smart H.264+ / Smart H.265+

• MJPEG (sub-stream)

Streaming

• Triple stream

Resolution

• 4M (2560 × 1440)

• 3M (2304 × 1296)

• 1080p, 1.3M, 720p

• D1, VGA, CIF

Frame Rate

• Main Stream: up to 25/30 fps

• Sub Stream 1: D1/VGA/CIF @ 25/30 fps

• Sub Stream 2: 720p @ 25/30 fps

Bit Rate

• Control: CBR / VBR

• H.264: 96 Kbps–14,848 Kbps

• H.265: 38 Kbps–8,960 Kbps

Image Processing

• Day/Night: ICR / Electronic (Color / B/W / Auto)

• WDR: 120 dB

• BLC / HLC: Supported

• White Balance: Auto, Indoor, Outdoor, Tracking, Manual, Sodium Lamp, Natural Light, Street Lamp

• Gain Control: Auto / Manual / Gain Priority

• Noise Reduction: 2D NR / 3D NR

• Motion Detection: Yes

• ROI: Yes

• EIS: Supported

• Defog: Electronic

• Digital Zoom: 16×

• Image Rotation: 180°

• S/N Ratio: ≥55 dB

• Privacy Masking: Up to 24 areas (8 per view, 8 colors)

Audio

• Compression: PCM, G.711A/U, G.726, MPEG-2 Layer II, G.722.1

• Audio I/O: 1 in / 1 out

• Built-in Mic: Yes (shared with audio input)

Network

• Ethernet: RJ-45 (10/100 Base-T)

• Protocols: IPv4/IPv6, TCP/IP, HTTP/HTTPS, RTSP, RTP, FTP, NTP, SNMP, QoS, DHCP, DDNS, ONVIF, and more

• Interoperability: ONVIF (Profile S/G/T), CGI, SDK

• Max Users: 20 (64 Mbps total bandwidth)

Storage

• Micro SD Card: Up to 512 GB

• Network Storage: FTP / SFTP / NAS

Software & Compatibility

• Web Browsers: IE9+, Chrome 41+, Firefox 52+, Safari 10+

• Management Software: DMSS, DSS Pro

• Mobile App: iOS / Android

Alarm & Events

• Alarm Actions: Snapshot, recording, email, preset, tour

• Events: Motion, tampering, audio detection, network disconnection, IP conflict, SD card status

Power

• Power Supply: 12 VDC ±10%, 2 A

• PoE: IEEE 802.3af

• Power Consumption:

  • Typical: 4 W

  • Max: 13 W (IR on)

Environment

• Operating Temperature: –30 °C to +60 °C

• Operating Humidity: ≤95%

• Protection: IP66, IK08, TVS 6000 V lightning protection, surge & transient protection

Physical

• Dimensions: 65.7 mm × Ø128.0 mm

• Net Weight: 0.5 kg

• Gross Weight: 0.7 kg

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

4 MP 4x Zoom IR Mini PT Dome Network Camera

Warranty: 3 Year HiLook (by Hikvision) Manufacturer Warranty

4 MP 4x Zoom IR Mini PT Dome Network Camera

Warranty: 3 Year HiLook (by Hikvision) Manufacturer Warranty

32-ch 1U 16 PoE 4K NVR

Warranty: 3 Year HiLook (by Hikvision) Manufacturer Warranty

Key Features

• Up to 32-channel IP camera inputs, plug & play with 16 PoE (Power-over-Ethernet) interfaces
• Supports H.265+, H.265, H.264+, and H.264 video formats
• Decoding capacity:
  • 2 channels @ 12 MP
  • 3 channels @ 8 MP
  • 6 channels @ 4 MP
  • 12 channels @ 1080p
• Supports up to 256 Mbps incoming bandwidth

Specification

Video and Audio

• IP Video Input: 32 channels
• Incoming Bandwidth: 256 Mbps
• Outgoing Bandwidth: 160 Mbps
• HDMI Output:
  • 1 channel, supports resolutions:
    • 4K (3840 × 2160) @ 30 Hz
    • 2K (2560 × 1440) @ 60 Hz
    • 1920 × 1080 @ 60 Hz
    • 1600 × 1200 @ 60 Hz
    • 1280 × 1024 @ 60 Hz
    • 1280 × 720 @ 60 Hz
    • 1024 × 768 @ 60 Hz
• VGA Output:
  • 1 channel, supports resolutions:
    • 1920 × 1080 @ 60 Hz
    • 1280 × 1024 @ 60 Hz
    • 1280 × 720 @ 60 Hz
• Video Output Mode: HDMI/VGA independent output
• CVBS Output: Not available
• Audio Output: 1 channel, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
• Two-Way Audio: 1 channel, RCA (Linear, 1 KΩ)

Decoding

• Decoding Format: H.265, H.265+, H.264+, H.264
• Recording Resolution:
  • 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
• Synchronous Playback: 16 channels

Auxiliary Interface

• SATA: 2 SATA interfaces
• Storage Capacity: Up to 10 TB per HDD
• USB Interface:
  • Front Panel: 1 × USB 2.0
  • Rear Panel: 1 × USB 2.0
• Alarm In/Out: 4/1

General

• GUI Language Support:
  • English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz, Brazilian Portuguese, Indonesian

Power & Environmental

• Power Supply: 100 to 240 VAC, 50 to 60 Hz
• Power Consumption: ≤ 15 W (without HDD and PoE off)
• Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
• Working Humidity: 10% to 90%

Physical Specifications

• Dimensions (W × D × H): 385 mm × 315 mm × 52 mm (15.2" × 12.4" × 2.0")
• Weight: ≤ 3 kg (6.6 lb) (without HDD)

Certifications

• FCC: Part 15 Subpart B, ANSI C63.4-2014
• CE: EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
• Obtained Certifications: CE, FCC, IC, CB, KC, UL, RoHS, REACH, WEEE, RCM, UKCA, LOA, BIS

Warranty: 3 Year HiLook (by Hikvision) Manufacturer Warranty

Key Features

• Up to 32-channel IP camera inputs, plug & play with 16 PoE (Power-over-Ethernet) interfaces
• Supports H.265+, H.265, H.264+, and H.264 video formats
• Decoding capacity:
  • 2 channels @ 12 MP
  • 3 channels @ 8 MP
  • 6 channels @ 4 MP
  • 12 channels @ 1080p
• Supports up to 256 Mbps incoming bandwidth

Specification

Video and Audio

• IP Video Input: 32 channels
• Incoming Bandwidth: 256 Mbps
• Outgoing Bandwidth: 160 Mbps
• HDMI Output:
  • 1 channel, supports resolutions:
    • 4K (3840 × 2160) @ 30 Hz
    • 2K (2560 × 1440) @ 60 Hz
    • 1920 × 1080 @ 60 Hz
    • 1600 × 1200 @ 60 Hz
    • 1280 × 1024 @ 60 Hz
    • 1280 × 720 @ 60 Hz
    • 1024 × 768 @ 60 Hz
• VGA Output:
  • 1 channel, supports resolutions:
    • 1920 × 1080 @ 60 Hz
    • 1280 × 1024 @ 60 Hz
    • 1280 × 720 @ 60 Hz
• Video Output Mode: HDMI/VGA independent output
• CVBS Output: Not available
• Audio Output: 1 channel, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
• Two-Way Audio: 1 channel, RCA (Linear, 1 KΩ)

Decoding

• Decoding Format: H.265, H.265+, H.264+, H.264
• Recording Resolution:
  • 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
• Synchronous Playback: 16 channels

Auxiliary Interface

• SATA: 2 SATA interfaces
• Storage Capacity: Up to 10 TB per HDD
• USB Interface:
  • Front Panel: 1 × USB 2.0
  • Rear Panel: 1 × USB 2.0
• Alarm In/Out: 4/1

General

• GUI Language Support:
  • English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz, Brazilian Portuguese, Indonesian

Power & Environmental

• Power Supply: 100 to 240 VAC, 50 to 60 Hz
• Power Consumption: ≤ 15 W (without HDD and PoE off)
• Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
• Working Humidity: 10% to 90%

Physical Specifications

• Dimensions (W × D × H): 385 mm × 315 mm × 52 mm (15.2" × 12.4" × 2.0")
• Weight: ≤ 3 kg (6.6 lb) (without HDD)

Certifications

• FCC: Part 15 Subpart B, ANSI C63.4-2014
• CE: EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
• Obtained Certifications: CE, FCC, IC, CB, KC, UL, RoHS, REACH, WEEE, RCM, UKCA, LOA, BIS

Warranty: 3 Year HiLook (by Hikvision) Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Hikvision ANZ Manufacturer Warranty

6 MP AI Fixed Turret Network Camera

• High quality imaging with 6 MP resolution
• Support Human and Vehicle Intelligent Detection
• Dual IR lights to enhance night vision
• Built-in microphone for real-time audio security
• Water and dust resistant (IP67)
• Efficient H.265+ compression technology

Specification

Camera

• Image Sensor: 1/2.4" Progressive Scan CMOS
• Max. Resolution: 3200 × 1800
• Min. Illumination:
  • Color: 0.005 Lux @ (F1.6, AGC ON)
  • B/W: 0 Lux with IR
• Shutter Time: 1/3 s to 1/100,000 s
• Day & Night: IR cut filter
• Angle Adjustment:
  • Pan: 0° to 360°
  • Tilt: 0° to 75°
  • Rotate: 0° to 360°

Lens

• Lens Type: Fixed focal lens, 2.8 and 4 mm optional
• Focal Length & FOV:
  • 2.8 mm: Horizontal FOV 105°, Vertical FOV 55°, Diagonal FOV 127°
  • 4 mm: Horizontal FOV 78°, Vertical FOV 38°, Diagonal FOV 96°
• Lens Mount: M12
• Iris Type: Fixed
• Aperture: F1.6

DORI

• DORI (Detection, Observation, Recognition, Identification):
  • 2.8 mm: D: 76 m, O: 30 m, R: 15 m, I: 7 m
  • 4 mm: D: 115 m, O: 45 m, R: 23 m, I: 11 m

Illuminator

• Supplement Light Type: IR
• Supplement Light Range: Up to 30 m
• Smart Supplement Light: Yes
• IR Wavelength: 850 nm

Video

• Main Stream:
  • 50 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
  • 60 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
• Sub-Stream:
  • 50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
  • 60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
• Video Compression:
  • Main stream: H.265+/H.265/H.264+/H.264
  • Sub-stream: H.265/H.264/MJPEG
• Video Bit Rate: 32 Kbps to 16 Mbps
• H.264 Type: Baseline Profile, Main Profile, High Profile
• H.265 Type: Main Profile
• Bit Rate Control: CBR, VBR
• Region of Interest (ROI): 1 fixed region for the main stream

Audio

• Audio Type: Mono sound
• Environment Noise Filtering: Yes
• Audio Sampling Rate: 8 kHz/16 kHz
• Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
• Audio Bit Rate:
  • 64 Kbps (G.711ulaw)
  • 64 Kbps (G.711alaw)
  • 16 Kbps (G.722.1)
  • 16 Kbps (G.726)
  • 32 to 160 Kbps (MP2L2)
  • 16 to 64 Kbps (AAC-LC)

Network

• Security:
  • Password protection
  • Complicated password
  • Watermark
  • Basic and digest authentication for HTTP
  • WSSE and digest authentication for Open Network Video Interface
  • Security audit log
  • Host authentication (MAC address)
• Simultaneous Live View: Up to 6 channels
• API: Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)), ISAPI, SDK
• Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
• User/Host: Up to 32 users, 3 user levels: administrator, operator, and user
• Client: iVMS-4200, Hik-Connect
• Web Browser:
  • Plug-in required live view: IE 10, IE 11
  • Local service: Chrome 57.0+, Firefox 52.0+


• Wide Dynamic Range (WDR): 120 dB
• SNR: ≥ 52 dB
• Day/Night Switch: Day, Night, Auto, Schedule
• Image Enhancement: BLC, HLC, 3D DNR
• Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
• Privacy Mask: 4 programmable polygon privacy masks

Interface

• Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
• Built-in Microphone: Yes
• Reset Key: Yes

Event

• Basic Event:
  • Motion detection (support alarm triggering by specified target types (human and vehicle))
  • Video tampering alarm
  • Exception
• Smart Event:
  • Line crossing detection
  • Intrusion detection (support alarm triggering by specified target types (human and vehicle))
• Linkage:
  • Upload to FTP/memory card (-F)
  • Send email
  • Notify surveillance center
  • Trigger recording (-F)
  • Trigger capture

General

• Power:
  • 12 VDC ± 25%, 0.41 A, max. 5 W, Ø5.5 mm coaxial power plug, reverse polarity protection
  • PoE: IEEE 802.3af, Class 3, max. 6.5 W
• Material: Metal
• Dimension: Ø127.3 mm × 95.9 mm (Ø5.0" × 3.8")
• Package Dimension: 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")
• Weight: Approx. 600 g (1.3 lb.)
• With Package Weight: Approx. 909 g (2.0 lb.)
• Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing)
• Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing)
• Language: English, Ukrainian
• General Function: Heartbeat, anti-banding, mirror, password protection, password reset via email

Approval

• EMC:
  • CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014
  • RCM: AS/NZS CISPR 32: 2015
  • IC: ICES-003: Issue 7
• Safety:
  • UL: UL 62368-1
  • CB: IEC 62368-1: 2014+A11
  • CE-LVD: EN 62368-1: 2014/A11: 2017
  • BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
• Environment:
  • CE-RoHS: 2011/65/EU
  • WEEE: 2012/19/EU
  • Reach: Regulation (EC) No 1907/2006
• Protection: IP67: IEC 60529-2013

Warranty: 3 Year HiLook (by Hikvision) Manufacturer Warranty

6 MP AI Fixed Turret Network Camera

• High quality imaging with 6 MP resolution
• Support Human and Vehicle Intelligent Detection
• Dual IR lights to enhance night vision
• Built-in microphone for real-time audio security
• Water and dust resistant (IP67)
• Efficient H.265+ compression technology

Specification

Camera

• Image Sensor: 1/2.4" Progressive Scan CMOS
• Max. Resolution: 3200 × 1800
• Min. Illumination:
  • Color: 0.005 Lux @ (F1.6, AGC ON)
  • B/W: 0 Lux with IR
• Shutter Time: 1/3 s to 1/100,000 s
• Day & Night: IR cut filter
• Angle Adjustment:
  • Pan: 0° to 360°
  • Tilt: 0° to 75°
  • Rotate: 0° to 360°

Lens

• Lens Type: Fixed focal lens, 2.8 and 4 mm optional
• Focal Length & FOV:
  • 2.8 mm: Horizontal FOV 105°, Vertical FOV 55°, Diagonal FOV 127°
  • 4 mm: Horizontal FOV 78°, Vertical FOV 38°, Diagonal FOV 96°
• Lens Mount: M12
• Iris Type: Fixed
• Aperture: F1.6

DORI

• DORI (Detection, Observation, Recognition, Identification):
  • 2.8 mm: D: 76 m, O: 30 m, R: 15 m, I: 7 m
  • 4 mm: D: 115 m, O: 45 m, R: 23 m, I: 11 m

Illuminator

• Supplement Light Type: IR
• Supplement Light Range: Up to 30 m
• Smart Supplement Light: Yes
• IR Wavelength: 850 nm

Video

• Main Stream:
  • 50 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
  • 60 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
• Sub-Stream:
  • 50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
  • 60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
• Video Compression:
  • Main stream: H.265+/H.265/H.264+/H.264
  • Sub-stream: H.265/H.264/MJPEG
• Video Bit Rate: 32 Kbps to 16 Mbps
• H.264 Type: Baseline Profile, Main Profile, High Profile
• H.265 Type: Main Profile
• Bit Rate Control: CBR, VBR
• Region of Interest (ROI): 1 fixed region for the main stream

Audio

• Audio Type: Mono sound
• Environment Noise Filtering: Yes
• Audio Sampling Rate: 8 kHz/16 kHz
• Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
• Audio Bit Rate:
  • 64 Kbps (G.711ulaw)
  • 64 Kbps (G.711alaw)
  • 16 Kbps (G.722.1)
  • 16 Kbps (G.726)
  • 32 to 160 Kbps (MP2L2)
  • 16 to 64 Kbps (AAC-LC)

Network

• Security:
  • Password protection
  • Complicated password
  • Watermark
  • Basic and digest authentication for HTTP
  • WSSE and digest authentication for Open Network Video Interface
  • Security audit log
  • Host authentication (MAC address)
• Simultaneous Live View: Up to 6 channels
• API: Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)), ISAPI, SDK
• Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
• User/Host: Up to 32 users, 3 user levels: administrator, operator, and user
• Client: iVMS-4200, Hik-Connect
• Web Browser:
  • Plug-in required live view: IE 10, IE 11
  • Local service: Chrome 57.0+, Firefox 52.0+


• Wide Dynamic Range (WDR): 120 dB
• SNR: ≥ 52 dB
• Day/Night Switch: Day, Night, Auto, Schedule
• Image Enhancement: BLC, HLC, 3D DNR
• Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
• Privacy Mask: 4 programmable polygon privacy masks

Interface

• Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
• Built-in Microphone: Yes
• Reset Key: Yes

Event

• Basic Event:
  • Motion detection (support alarm triggering by specified target types (human and vehicle))
  • Video tampering alarm
  • Exception
• Smart Event:
  • Line crossing detection
  • Intrusion detection (support alarm triggering by specified target types (human and vehicle))
• Linkage:
  • Upload to FTP/memory card (-F)
  • Send email
  • Notify surveillance center
  • Trigger recording (-F)
  • Trigger capture

General

• Power:
  • 12 VDC ± 25%, 0.41 A, max. 5 W, Ø5.5 mm coaxial power plug, reverse polarity protection
  • PoE: IEEE 802.3af, Class 3, max. 6.5 W
• Material: Metal
• Dimension: Ø127.3 mm × 95.9 mm (Ø5.0" × 3.8")
• Package Dimension: 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")
• Weight: Approx. 600 g (1.3 lb.)
• With Package Weight: Approx. 909 g (2.0 lb.)
• Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing)
• Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing)
• Language: English, Ukrainian
• General Function: Heartbeat, anti-banding, mirror, password protection, password reset via email

Approval

• EMC:
  • CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014
  • RCM: AS/NZS CISPR 32: 2015
  • IC: ICES-003: Issue 7
• Safety:
  • UL: UL 62368-1
  • CB: IEC 62368-1: 2014+A11
  • CE-LVD: EN 62368-1: 2014/A11: 2017
  • BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
• Environment:
  • CE-RoHS: 2011/65/EU
  • WEEE: 2012/19/EU
  • Reach: Regulation (EC) No 1907/2006
• Protection: IP67: IEC 60529-2013

Warranty: 3 Year HiLook (by Hikvision) Manufacturer Warranty
