• Wall Mount
• Aluminum alloy
• Hikvision White

• Aluminum alloy with surface spray treatment
• The cable hole design facilitates the cable routing
• The cap design facilitates the installation

• Junction Box
• Aluminum Alloy
• Hikvision Black
• Dataheet

Parameters

• Description: Junction Box for Dome (Bullet) Camera

• Appearance: Hikvision Black

• Material: Aluminum Alloy

• Dimension: 100 × 43.5 × 132.1 mm (3.94'' × 1.71'' × 5.20'')

• Weight: Approx. 320 g (0.66 lb.)

• Junction Box
• Aluminum Alloy
• Hikvision Black
• Dataheet

Parameters

• Description: Junction Box for Dome (Bullet) Camera

• Appearance: Hikvision Black

• Material: Aluminum Alloy

• Dimension: 100 × 43.5 × 132.1 mm (3.94'' × 1.71'' × 5.20'')

• Weight: Approx. 320 g (0.66 lb.)

• Junction Box
• Aluminum Alloy
• Hikvision White
• Dataheet

Parameters

• Description: Junction Box for Dome (Bullet) Camera

• Appearance: Hikvision White

• Material: Aluminum Alloy

• Dimension: 100 × 43.5 × 132.1 mm (3.94'' × 1.71'' × 5.20'')

• Weight: Approx. 320 g (0.66 lb.)

• Junction Box
• Aluminum Alloy
• Hikvision White
• Datasheet

Parameters

• Weight: Approx. 660 g (1.46 lb.)

• Appearance: Hikvision White

• Material: Aluminum Alloy

• Dimension: 137 mm × 54 mm × 171.5 mm (5.39" × 2.13" × 6.75")

• Description: Junction Box for Dome Camera

• Junction Box
• Aluminum Alloy
• Hikvision White

Parameters

• Description: Junction Box

• Appearance: Hikvision White

• Material: Aluminum Alloy

• Dimension: Φ155 mm × 36 mm (Φ6.1" × 1.42")

• Weight: 300 g (0.66 lb.)

• Aluminum alloy material with surface spray treatment
• Side outlet and bottom outlet
• Waterproof design
• Interchangeable bottom waterproof cover, and side gland nut
• Datasheet

Parameters

• Weight: 280 g (0.62 lb.)

• Appearance: Black

• Material: Aluminum Alloy

• Dimension: Ø137 mm × 42 mm (Ø5.4" × 1.7")

• Vertical Pole Mount
• Stainless Steel
• Hikvision White

Parameters

• Description: Vertical Pole Mount

• Appearance: White

• Material: Stainless Steel

• Dimension: 144 mm × 131.6 mm × 44.3 mm (5.67" × 5.18" × 1.74")

• Weight: 760 g (1.68 lb.)

• Vertical Pole Mount
• Stainless Steel&Steel
• Hikvision White

• Aluminum alloy material with surface spray treatment
• The outlet hole makes the feature looks better
• Convenient installation coordinating with lower bowl
• Datasheet

Parameters

• Weight: Approx. 703 g (1.55 lb.)

• Appearance: Hikvision White

• Material: Aluminum Alloy

• Dimension: Φ140 mm × 183.5 mm × 232 mm (Φ5.51" × 7.22" × 9.13")

• Range of Application: Suitable for DS-2CC51xxP(N) dome camera wall mounting

• Description: DS-2CC51xxP(N) Wall Mounting Bracket for Dome Camera

• Wall Mount
• Aluminum alloy
• Hikvision Black


Parameters

• Description: Wall Mount

• Appearance: Black

• Material: Aluminum Alloy

• Dimensions: 120 mm × 183.5 mm × 228.5 mm (4.72" × 7.22" × 9.0")

• Weight: 870 g (1.92 lb)

• Wall Mount
• With Junction Box
• Aluminum alloy
• Hikvision White

• Wall Mount
• Aluminum Alloy and Steel
• Hikvision White
• Datasheet

Parameters

• Weight: 605 g

• Appearance: Hikvision White

• Material: Aluminum Alloy and Steel

• Dimensions: 122 × 120 × 169 mm

• Description: Wall Mounting Bracket for Dome Camera

• High quality imaging with 3K, 2960 × 1665 resolution
• 2.8 mm, 3.6 mm fixed focal lens
• Up to 40 m IR distance for bright night imaging
• Up to 20 m white light distance for bright night imaging
• One port for four switchable signals (TVI/AHD/CVI/CVBS）
• Water and dust resistant (IP66)
• High quality audio with audio over coaxial cable, built-in microphone
• Smart-Hybrid light, optimize your security with flexible lighting options
• Datasheet

Camera Specifications


• Sensor: 3K CMOS

• Max. Resolution: 2960 (H) × 1665 (V)

• Min. Illumination:

  • 0.01 Lux @ (F2.0, AGC ON)

  • 0 Lux with IR

• Shutter Time:

  • PAL: 1/25 s to 1/50,000 s

  • NTSC: 1/30 s to 1/50,000 s

• Day & Night: ICR

• Signal System: PAL/NTSC

• Image Settings: Brightness, Sharpness, Smart IR

• Frame Rate:

  • TVI: 3K @20 fps, 4 MP @25 fps/30 fps, 1080p @25 fps/30 fps

  • AHD: 5 MP @20 fps, 4 MP @25 fps/30 fps

  • CVI: 4 MP @25 fps/30 fps

  • CVBS: PAL/NTSC

• Day/Night Mode: Auto/Color

• WDR: Digital WDR

• Image Enhancement: DWDR, BLC, HLC, Global

• White Balance: Auto/Manual

• AGC: Yes

Lens

• Type: Fixed focal lens (2.8 mm, 3.6 mm)

• Focal Length & FOV:

  • 2.8 mm: H 104.9°, V 67.3°, D 129.8°

  • 3.6 mm: H 81.3°, V 50.7°, D 102.4°

• Mount: M12

Microphone

• Pickup Distance: Up to 5 m radius

• Quantity: 1

Illuminator

• Supplement Light Range:

  • IR: up to 40 m

  • White Light: up to 20 m

• Type: Smart, IR, White Light

Interface

• Video Output: Switchable TVI/AHD/CVI/CVBS

General

• Material:

  • Body: Metal

  • Enclosure: Metal

• Dimensions: Ø127.9 mm × 97.8 mm (Ø5.04" × 3.85")

• Weight: Approx. 476 g (0.75 lb.)

• Operating Conditions: -40 °C to 60 °C (-40 °F to 140 °F), ≤90% humidity (non-condensing)

• Communication: HIKVISION-C

• Language: English

Power

• Supply: 12 VDC ± 25%

  • Recommended: one adapter per camera

• Consumption: Max. 3.3 W

Approval

• Protection: IP66

• TCP/IP, Wi-Fi, and 3/4G network
• New generation wireless protocol: Tri-X/Cam-X
• Long RF transmission distance
• Two-way communication with AES-128 encryption
• Connects up to 96 wireless zones/outputs (including 48 PIRCAMs), 48 wireless keyfobs, 4 repeaters, 6 sounders(3 internal+3 external), 8 tag readers and keypads
• Supports up to 48 network users, including 1 installer, 1 administrator, and 46 normal users
• Voice prompt
• Configuration via Web client, mobile client, and Convergence Cloud
• Hik-Connect and Hik-ProConnect configuration depends on the user access level
• Pushes alarm notification via messages or phone calls
• Views live videos from Hik-Connect
• Alarm video clips via emails and APP
• Supports LED indicator to indicates system status
• 4520 mAh lithium backup battery
• SIA-DC09 protocol, and supports both Contact ID and SIA data format
• Supports Hik-IP Receiver and Hik-IP Receiver Pro for ARC communication
• Datasheet

Software Features

• Diagnostics: Via APP or Web (Supported)

• Installer Accounts: 1

• Installer APP for Programming: Supported

• Onboard Video Clips: 4

• Web Server for Maintenance: Offline Configuration (Supported)

• Wi-Fi Standard: Supported

• Arm Modes: Away / Stay

• Firmware Upgrade: Via APP / Web Portal

• Admin Users: 1

• Wired Network: Supported

• Programming Tools:

  • Hik-Connect

  • Hik-ProConnect

  • Web Portal

  • IVMS4200

  • Convergence Cloud

• Forced Arming (Open Zones): Supported

• Event Log Capacity: 5000 entries

• User Accounts: 46

• User APP for Operation: Supported

• Voice Prompts: Supported

• Areas (Partitions): 32

• Auto Arm/Disarm Timers: Supported

Hardware Features

• RS232 Output: Supported

• SIM Slot: Dual

• 3G/4G Connectivity: Onboard (Supported)

• Tag Reader: Built-in

• Loudspeaker: Built-in

Electrical Characteristics

• Battery Type: Built-in Li-ion

• Power Supply: Built-in

• Operating Temperature: -10 °C to +55 °C

  • (Ensure adapter is connected)

• Battery Life: Up to 12 hours (may decrease at low temps)

Wireless Transmission

• RF Frequency: 868 MHz

• RF Method: Supported

• Wireless Security: Frequency Hopping + 128-bit AES Encryption

Display (LED Indicators)

• Arm / Disarm

• Alarm

• Tamper

• Fault

• Cloud

• Power

General Specifications

• Dimensions (W × H × D): 170 × 170 × 38.6 mm (6.7" × 6.7" × 1.5")

• Material: Plastic

• Color: White

• Weight: 557.5 g (19.7 oz)

Device Capacity

• Tags: Up to 48

• PIR Cameras: Supported (Max 48)

• Zones: 96 total (up to 48 with PIR Cam)

• Keypads: 8 (including tag reader models)

• Wireless Sounders: 6 (3 internal + 3 external)

• Wireless Repeaters: 4

• Keyfobs: 48

• Multi Transmitters: 6

Reporting & Integration

• Supported Protocols:

  • ARC

  • SIA DC09 (Level 2, Contact ID)

  • ISUP

  • ISAPI (SDK)

• Receivers:

  • Hik-IP Receiver

  • Hik-IP Receiver Pro

  • (Compatible with Sur-Gard & Ademco 685)

• Features:

  • Supports video verification

  • Remote control capability

• TCP/IP, Wi-Fi, and 3/4G network
• New generation wireless protocol: Tri-X/Cam-X
• Long RF transmission distance
• Two-way communication with AES-128 encryption
• Connects up to 96 wireless zones/outputs (including 48 PIRCAMs), 48 wireless keyfobs, 4 repeaters, 6 sounders(3 internal+3 external), 8 tag readers and keypads
• Supports up to 48 network users, including 1 installer, 1 administrator, and 46 normal users
• Voice prompt
• Configuration via Web client, mobile client, and Convergence Cloud
• Hik-Connect and Hik-ProConnect configuration depends on the user access level
• Pushes alarm notification via messages or phone calls
• Views live videos from Hik-Connect
• Alarm video clips via emails and APP
• Supports LED indicator to indicates system status
• 4520 mAh lithium backup battery
• SIA-DC09 protocol, and supports both Contact ID and SIA data format
• Supports Hik-IP Receiver and Hik-IP Receiver Pro for ARC communication
• Datasheet

Software Features

• Diagnostics: Via APP or Web (Supported)

• Installer Accounts: 1

• Installer APP for Programming: Supported

• Onboard Video Clips: 4

• Web Server for Maintenance: Offline Configuration (Supported)

• Wi-Fi Standard: Supported

• Arm Modes: Away / Stay

• Firmware Upgrade: Via APP / Web Portal

• Admin Users: 1

• Wired Network: Supported

• Programming Tools:

  • Hik-Connect

  • Hik-ProConnect

  • Web Portal

  • IVMS4200

  • Convergence Cloud

• Forced Arming (Open Zones): Supported

• Event Log Capacity: 5000 entries

• User Accounts: 46

• User APP for Operation: Supported

• Voice Prompts: Supported

• Areas (Partitions): 32

• Auto Arm/Disarm Timers: Supported

Hardware Features

• RS232 Output: Supported

• SIM Slot: Dual

• 3G/4G Connectivity: Onboard (Supported)

• Tag Reader: Built-in

• Loudspeaker: Built-in

Electrical Characteristics

• Battery Type: Built-in Li-ion

• Power Supply: Built-in

• Operating Temperature: -10 °C to +55 °C

  • (Ensure adapter is connected)

• Battery Life: Up to 12 hours (may decrease at low temps)

Wireless Transmission

• RF Frequency: 868 MHz

• RF Method: Supported

• Wireless Security: Frequency Hopping + 128-bit AES Encryption

Display (LED Indicators)

• Arm / Disarm

• Alarm

• Tamper

• Fault

• Cloud

• Power

General Specifications

• Dimensions (W × H × D): 170 × 170 × 38.6 mm (6.7" × 6.7" × 1.5")

• Material: Plastic

• Color: White

• Weight: 557.5 g (19.7 oz)

Device Capacity

• Tags: Up to 48

• PIR Cameras: Supported (Max 48)

• Zones: 96 total (up to 48 with PIR Cam)

• Keypads: 8 (including tag reader models)

• Wireless Sounders: 6 (3 internal + 3 external)

• Wireless Repeaters: 4

• Keyfobs: 48

• Multi Transmitters: 6

Reporting & Integration

• Supported Protocols:

  • ARC

  • SIA DC09 (Level 2, Contact ID)

  • ISUP

  • ISAPI (SDK)

• Receivers:

  • Hik-IP Receiver

  • Hik-IP Receiver Pro

  • (Compatible with Sur-Gard & Ademco 685)

• Features:

  • Supports video verification

  • Remote control capability

• 868MHz two-way wireless communication
• AES-128 encryption
• LED display, show the differernt feedbacks with easy understanding
• Operation: Stay arm/away arm/disarm by areas
• Arming process with fault confirm, more secure
• Patrol tag check in
• Front and rear panel tamper-proof
• Datasheet

Hardware Features

• Power Switch: Power On/Off

Electrical Characteristics

• Battery Type: 3 × AA batteries

• Operating Humidity: 10% to 90% (non-condensing)

• Operating Temperature: -10 °C to 55 °C (-4 °F to +122 °F)

• Power Consumption:

  • Quiescent Current: 110 µA

  • Max Current: 292 mA

  • Voltage: 1.5 VDC

• Battery Life Span: Up to 2 years (standby time)

Wireless Transmission

• RF Frequency: 868 MHz

• RF Modulation: 2GFSK

• RF Distance: 1200 m (open area)

Display

• Indicator Lights:

  • 5 LEDs:

    • Area (blue)

    • Fault (orange)

    • Arm (blue)

    • Disarm (green)

    • Alarm (red)

    • Signal (red/green)

General

• Installation Method: Wall-mounting

• Dimensions (W × H × D): 75 × 124 × 21 mm

• Color: White

• Weight: 183 g

• Small and solid structure
• Convenient to carry with
• Datasheet

General Specifications

• Operating Temperature: -10 °C to 50 °C

• Shell Material: PVC, ABS

• Dimensions (W × H × D): 41 × 32 × 3.5 mm

• Color: White

• 433 MHz two-way wireless communication
• Configurable arming/disarming prompt sound and LED indicator
• 3 years battery life span (triggered every two weeks and alerting 90 s for each triggering)
• AES-128 encryption
• Front and rear panel tamper-proof
• 3 kinds of alarm sounds: fire alarm, panic alarm, and intrusion alarm
• Buzzer Decibel: 90 to 110 dB
• Fully remote configurable through App
• Multiple enrollment methods and easy installation design
• Frequency hopping against jamming for reliable transmission
• Datasheet


RF Transmission

• RF Frequency: 433 MHz

• RF Modulation: 2GFSK

• RF Range: 900 m (open area)

Electrical Characteristics

• Battery Life Span: Up to 3 years (standby time)

General

• Operation Temperature: -10°C to 55°C (14°F to 131°F)

• Operation Humidity: 10% to 90% (non-condensing)

• Shell Material: PC + ABS

• Dimensions (W × H × D): 88 × 88 × 32 mm (3.46" × 3.46" × 1.26")

• Weight: 169.5 g (6.0 oz)

• Color: Blue/Red LED flash

• 433MHz two-way wireless communication
• Two-way communication, stable and secure
• LED display, show the differernt feedbacks with easy understanding
• Up to 35 hrs battery backup after mains lost, no worry about communication
• Finding and connecting up to 8 PIRCAM or smoke detectors automatically, smart auto-pairing
• Easy installation with new designed structure
• Datasheet

Software Features

• Auto Pairing: Supported

Hardware Features

• Serial Port: 2 (for debug)

• Tamper-Proof: 1 (front and back)

• Power Switch: 1

Electrical Characteristics

• Battery Type: Built-in Li-ion battery

• Power Supply: 100 VAC to 240 VAC

• Operation Humidity: 10% to 90%

• Operation Temperature: -10°C to +55°C

  Note: The battery cannot be charged at temperatures lower than 10°C. Please ensure the adapter is connected.

• Battery Life Span: Up to 35 hours at normal temperature

  Note: Battery working time may be significantly reduced at low temperatures.

Wireless Transmission

• RF Frequency: 433 MHz

• RF Method: Two-way communication

• RF Modulation: 2GFSK

• RF Distance: 800 m (open area)

• Wireless Security: AES-128

Display

• LED Status Indicators:

  • Register/Signal: Green/Red

  • Power: Green

  • Fault: Amber

General

• Installation Method: Wall mounting

• Dimensions (W × H × D): 150 mm × 150 mm × 25 mm

• Shell Material: Plastic

• Color: White

• Weight: 372 g

Device Management

• PIRCAM Pairing: Supported

• Keypad: LCD keypad not supported

• 433MHz two-way wireless communication
• AES-128 encryption
• LED display, show status of device and replay on/off display
• Small case design, which can be put into hiding places easily
• Automation operating, one button turn on/off from APP/Keyfob/Keypad
• Setting scenarios by different events
• Datasheet

Software Features

• Scenario Setting: By Alarm, By Operation, By Fault, By Schedule, By Manual

• Learning Button: 1 (for registration)

Hardware Features

• Serial Port: 1 (for debugging)

Electrical Characteristics

• Power Supply: AC 100V – 240V, 50/60 Hz

• Operating Humidity: 10% ~ 90%

• Operating Temperature: -10 °C ~ +55 °C

Wireless Transmission

• RF Frequency: 433 MHz

• RF Method: Two-way communication

• RF Modulation: 2GFSK

• RF Distance: 800 m

• Wireless Security: AES-128

Display

• LED Status Indicators:

  • Register/Signal: Green/Red

  • Power: Green

  • Relay Status: Blue

General

• Installation Method: Wall mounting or inside 86 box

• Dimensions (W × H × D): 38 × 25 × 18 mm

• Shell Material: Plastic

• Color: White

• Weight: 31.5 g

Device Management

• Relay Output: 1 (NO/NC, AC 100~240V, Max 13A)
