• Captures a large area and great details at the same time
• High quality panoramic imaging with 6 MP resolution and details imaging with 4 MP
• Excellent low-light performance with powered-by-DarkFighter technology and ColorVu technology
• Secures an expansive area with 25× optical zoom and 16× digital zoom
• Expansive night view with up to 100 m IR distance & 30 m white light
• Supports 12V DC & PoE+
• Focuses on human and vehicle targets classification based on deep learning
• Datasheet

Camera Overview

Image Sensor

• Bullet Channel: 1/2.5" Progressive Scan CMOS

• PTZ Channel: 1/2.8" Progressive Scan CMOS

Maximum Resolution

• Bullet Channel: 3632 × 1632

• PTZ Channel: 2560 × 1440

Minimum Illumination

• Bullet Channel: 0.0005 Lux @ (F1.0, AGC ON); 0 Lux with light

• PTZ Channel:

  • Color: 0.005 Lux @ (F1.6, AGC ON)

  • B/W: 0.001 Lux @ (F1.6, AGC ON)

  • 0 Lux with IR

Shutter Speed

• 1 s to 1/30,000 s

Day & Night

• ICR (Infrared Cut Filter Removal)

Zoom

• PTZ Channel: 25 × optical, 16 × digital

Slow Shutter

• Yes

Lens

Focal Length

• Bullet Channel: 2.8 mm

• PTZ Channel: 4.8 to 120 mm, 25 × optical

Field of View (FOV)

• Bullet Channel:

  • Horizontal: 180±10°

  • Vertical: 80±5°

• PTZ Channel:

  • Horizontal: 55° to 2.4° (wide-tele)

  • Vertical: 33° to 1.4° (wide-tele)

  • Diagonal: 61.5° to 2.8° (wide-tele)

Focus

• Semi-auto, manual, auto

Aperture

• Bullet Channel: F1.0

• PTZ Channel: F1.6

Zoom Speed

• PTZ Channel: Approx. 3.6 s

Illuminator

Supplement Light Type

• PTZ Channel: IR

• Bullet Channel: White Light

Supplement Light Range

• PTZ Channel: Up to 100 m

• Bullet Channel: Up to 30 m

Smart Supplement Light

• Yes

PTZ (Pan/Tilt/Zoom)

Movement Range

• Pan: 360°

• Tilt: -15° to 90° (auto flip)

Pan Speed

• Configurable from 0.1° to 80°/s; preset speed: 80°/s

Tilt Speed

• Configurable from 0.1° to 80°/s; preset speed: 80°/s

Proportional Pan

• Yes

Presets

• 300

Preset Freezing

• Yes

Patrol Scan

• 8 patrols, up to 32 presets for each patrol

Pattern Scan

• 4 pattern scans

Park Action

• Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan

3D Positioning

• Yes

PTZ Status Display

• Yes

Scheduled Task

• Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output

Power-off Memory

• Yes

Video

Main Stream

• Bullet Channel:

  • 50 Hz: 25 fps (3632 × 1632, 3680 × 1656)

  • 60 Hz: 30 fps (3632 × 1632, 3680 × 1656)

• PTZ Channel:

  • 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

  • 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

Sub-Stream

• Bullet Channel:

  • 50 Hz: 25 fps (1200 × 536, 960 × 432)

  • 60 Hz: 30 fps (1200 × 536, 960 × 432)

• PTZ Channel:

  • 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)

  • 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

Third Stream

• PTZ Channel:

  • 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)

  • 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

Video Compression

• H.265, H.264, MJPEG

Video Bit Rate

• 32 kbps to 16384 kbps

H.264 Type

• Baseline profile, main profile, high profile

H.265 Type

• Main profile

Scalable Video Coding (SVC)

• Supported for H.264 and H.265 encoding

Region of Interest (ROI)

• 8 fixed regions for each stream

Audio

Audio Compression

• G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC, MP3

Audio Bit Rate

• MP2L2: 16 kHz, 32 kHz, 48 kHz

• AAC-LC: 16 kHz, 32 kHz, 48 kHz

• PCM: 8 kHz, 16 kHz, 32 kHz, 48 kHz

• MP3: 8 kHz, 16 kHz, 32 kHz, 48 kHz

Audio Sampling Rate

• MP2L2: 32 Kbps, 40 Kbps, 48 Kbps, 56 Kbps, 64 Kbps, 80 Kbps, 96 Kbps, 112 Kbps, 128 Kbps, 144 Kbps, 160 Kbps, 192 Kbps

• AAC-LC: 16 Kbps, 32 Kbps, 64 Kbps

• MP3: 8 Kbps, 16 Kbps, 24 Kbps, 32 Kbps, 40 Kbps, 48 Kbps, 56 Kbps, 64 Kbps, 80 Kbps, 96 Kbps, 112 Kbps, 128 Kbps, 160 Kbps, 192 Kbps, 224 Kbps, 256 Kbps, 320 Kbps

Environment Noise Filtering

• Yes

Network

Protocols

• IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets

Simultaneous Live View

• 20

API

• ISAPI, SDK, ISUP, ONVIF

User/Host

• 32

Security

• Authenticated username and password, MAC address binding, HTTPS encryption, 802.1X authenticated access, IP address filter

Network Storage

• NAS (NFS, SMB/CIFS), ANR

Client

• iVMS-4200, Hik-Connect

Web Browser Compatibility

• IE11+, Chrome57+, Firefox52+, Safari12+, Edge79.0.309.65+

Image Settings

• Sharpness, saturation, brightness, contrast

Day/Night Switch

• Day, night, auto, scheduled-switch

Wide Dynamic Range (WDR)

• 120 dB

Signal-to-Noise Ratio (SNR)

• ≥ 52 dB

Defog

• Digital defog

Image Stabilization

• EIS

Image Enhancement

• BLC, HLC, 3D DNR

Privacy Mask

• Bullet Channel: 8 programmable polygon privacy masks

• PTZ Channel: 24 programmable polygon privacy masks (mask color or mosaic configurable)

Regional Focus

• Yes

Regional Exposure

• Yes

Interface

Ethernet Interface

• RJ45, self-adaptive 10M/100M Ethernet port

On-board Storage

• Built-in memory card slot, supports Micro SD/Micro SDHC/Micro SDXC, up to 256 GB

Audio

• 1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%

• 1 audio output, line level, impedance: 600 Ω

Alarm

• 1 alarm input, 1 alarm output

Reset

• Yes

Event Detection

Basic Events

• PTZ Channel: Motion detection, video tampering alarm

• Bullet & PTZ Channels: Alarm input and output, exception events (IP address conflict, HDD full, illegal login, HDD error, network disconnected, abnormal reboot)

Smart Events

• Bullet & PTZ Channels: Audio exception detection, line crossing detection, intrusion detection, region entrance detection, region exiting detection

Linkage

• Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, PTZ actions (preset, patrol scan, pattern scan)

Smart Linkage

• Panorama Linkage

Deep Learning Functions

• Face Capture: Detects up to 5 faces simultaneously, supports detecting, tracking, capturing, grading, selecting faces in motion, and outputs the best face picture

• Regional People Counting: Yes

General Specifications

Power

• 12VDC, PoE+

Dimensions

• Ø 166 mm × 375 mm (Ø 6.5" × 14.7")

Weight

• Approx. 2.4 kg (13.2 lb.)

Material

• ADC12

Operating Conditions

• Temperature: -30℃ to 65℃ (-22°F to 149°F)

• Humidity: < 90% RH

Demist

• Demist by heating the glass

Power Consumption and Current

• Max. 24 W, including Max. 2.6 W for heater and Max. 11 W for supplement light

Protection

• IP66 Standard, 6000 V Lightning Protection, Surge Protection, and Voltage Transient Protection

• Captures a large area and great details at the same time
• High quality imaging with 4 MP resolution
• Excellent low-light performance with powered-by-DarkFighter technology
• Secures an expansive area with 4× optical zoom and 16× digital zoom
• Supports WDR, HLC, BLC, 3D DNR, defog, regional exposure, regional focus
• Supports 12V DC & PoE+
• Support Human and Vehicle Detection
• Datasheet

Camera Specifications

Camera

• Image Sensor:

  • Bullet channel: 1/2.8" Progressive Scan CMOS

  • PTZ channel: 1/2.8" Progressive Scan CMOS

• Min. Illumination:

  • Bullet channel: Color: 0.01 Lux @ (F1.6, AGC ON); B/W: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with IR

  • PTZ channel: Color: 0.01 Lux @ (F1.5, AGC ON); B/W: 0.005 Lux @ (F1.5, AGC ON), 0 Lux with IR

• Shutter Speed: 1 s to 1/30,000 s

• Slow Shutter: Yes

• Day & Night: ICR

• Zoom:

  • PTZ channel: 4× optical, 16× digital

• Max. Resolution:

  • Bullet channel: 2560 × 1440

  • PTZ channel: 2560 × 1440

Lens

• Focus: Auto, Manual, Semi-auto

• Focal Length:

  • Bullet channel: 2.8 mm

  • PTZ channel: 2.8 to 12 mm (4× optical)

• Zoom Speed:

  • PTZ channel: Approx. 3.3 s

• Field of View (FOV):

  • Bullet channel: H: 114.9°, V: 62.4°, D: 130.7°

  • PTZ channel: H: 98°–34.2°, V: 52°–19.2°, D: 111°–39°

• Aperture:

  • Bullet channel: F1.6

  • PTZ channel: F1.5 to F2.9

Illuminator

• Supplement Light Type:

  • Bullet channel: Hybrid (IR and White Light)

  • PTZ channel: IR

• Smart Supplement Light: Yes

• Supplement Light Range:

  • PTZ channel IR: Up to 40 m

  • Bullet channel IR: Up to 30 m, White Light: Up to 30 m

PTZ

• Movement Range:

  • Pan: 0° to 350°

  • Tilt: Bullet channel: 7° to 17° (manual); PTZ channel: -5° to 90°

• Pan Speed: 0.1°–30°/s (configurable), Preset speed: 30°/s

• Tilt Speed: 0.1°–30°/s (configurable), Preset speed: 30°/s

• Proportional Pan: Yes

• Presets: 300

• Patrol Scan: 8 patrols (up to 32 presets each)

• Power-off Memory: Yes

• Park Action: Preset, Patrol Scan

• 3D Positioning: Yes

• PTZ Status Display: Yes

• Preset Freezing: Yes

• Scheduled Tasks: Dome reboot, preset, patrol scan, dome adjust, aux output

Video

• Region of Interest (ROI): 1 fixed region for main stream

• Main Stream:

  • Bullet & PTZ channel:

    • 50 Hz: 25 fps (2560×1440, 1920×1080, 1280×720)

    • 60 Hz: 30 fps (2560×1440, 1920×1080, 1280×720)

• Sub-Stream:

  • 50 Hz: 25 fps (640×480, 640×360)

  • 60 Hz: 30 fps (640×480, 640×360)

• Third Stream:

  • 50 Hz: 25 fps (1280×720, 640×480, 640×360)

  • 60 Hz: 30 fps (1280×720, 640×480, 640×360)

• Video Compression: H.265, H.264, MJPEG

• Video Bit Rate: 32 kbps to 16384 kbps

• H.264 Type: Main profile, Baseline profile, High profile

• H.265 Type: Main profile

• Scalable Video Coding (SVC): Yes

Audio

• Audio Compression: G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC

• Audio Bit Rate:

  • MP2L2: 32–160 kbps

  • AAC: 16, 32, 64 kbps

  • MP3: 8–160 kbps

• Audio Sampling Rate:

  • MP2L2: 16 kHz

  • AAC-LC: 16 kHz

  • PCM: 8/16 kHz

  • MP3: 8/16 kHz

• Environment Noise Filtering: Yes

Network

• API: ONVIF (Profile S, G, T), ISAPI, SDK, ISUP

• Network Storage: NAS (NFS, SMB/CIFS), ANR

• Protocols: TCP/IP, SMTP, RTSP, FTP, WebSockets, IGMP, WebSocket, QoS, RTCP, HTTPS, PPPoE, SNMP, NTP, RTP, UDP, DNS, HTTP, DHCP, Bonjour, 802.1X, IPv4/IPv6, DDNS, ICMP, UPnP

• Simultaneous Live View: 20

• Users/Hosts: 32

• Security Features: 802.1X authenticated access, MAC address binding, username/password authentication, IP filter, HTTPS encryption

• Client Software: iVMS-4200, Hik-Connect

• Web Browser Compatibility: IE8+, Chrome 31–44, Firefox 30–51, Safari 8.0+


• Settings: Sharpness, Saturation, Brightness, Contrast

• Wide Dynamic Range (WDR): 120 dB

• SNR: ≥ 52 dB

• Defog: Digital Defog

• Day/Night Switch: Day, Night, Auto, Scheduled Switch

• Image Enhancement: BLC, HLC, 3D DNR

• Privacy Mask:

  • Bullet & PTZ: 24 programmable polygon masks

• Regional Focus:

  • Bullet: No

  • PTZ: Yes

• Regional Exposure:

  • Bullet: No

  • PTZ: Yes

• Image Parameters Switch: Yes

Interface

• Ethernet Interface: RJ45, 10M/100M self-adaptive Ethernet port

• On-board Storage: Micro SD/SDHC/SDXC (up to 512 GB)

• Reset Button: Yes

Events

• Basic Events: Motion detection, video tampering, exception, alarm input/output

• Smart Events: Line crossing detection, intrusion detection, region entrance/exit detection, audio exception

• Event Linkage:

  • Bullet & PTZ channel: Upload to FTP/NAS/Memory Card, Notify Surveillance Center, Send Email, Trigger Alarm Output, Trigger Recording, PTZ Actions (Preset, Patrol, Pattern Scan)

General

• General Functions: Mirror, Watermark, IP Address Filter, Password Protection

• Power Supply: 12 VDC, PoE+

• Operating Conditions: -30°C to 50°C (-22°F to 122°F), Humidity ≤ 95% (non-condensing)

• Demist: Heated Glass

• Material: PC

• Dimensions: 311.5 × 223.5 × 156 mm (12.26" × 8.80" × 6.14")

• Weight: Approx. 1.37 kg (3.02 lb.)

• Approvals: IP66 Standard, Surge Protection, Voltage Transient Protection

• Captures a large area and great details at the same time
• High quality imaging with 4 MP resolution
• Excellent low-light performance with powered-by-DarkFighter technology
• Secures an expansive area with 4× optical zoom and 16× digital zoom
• Supports WDR, HLC, BLC, 3D DNR, defog, regional exposure, regional focus
• Supports 12V DC & PoE+
• Support Human and Vehicle Detection
• Datasheet

Camera Specifications

Camera

• Image Sensor:

  • Bullet channel: 1/2.8" Progressive Scan CMOS

  • PTZ channel: 1/2.8" Progressive Scan CMOS

• Min. Illumination:

  • Bullet channel: Color: 0.01 Lux @ (F1.6, AGC ON); B/W: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with IR

  • PTZ channel: Color: 0.01 Lux @ (F1.5, AGC ON); B/W: 0.005 Lux @ (F1.5, AGC ON), 0 Lux with IR

• Shutter Speed: 1 s to 1/30,000 s

• Slow Shutter: Yes

• Day & Night: ICR

• Zoom:

  • PTZ channel: 4× optical, 16× digital

• Max. Resolution:

  • Bullet channel: 2560 × 1440

  • PTZ channel: 2560 × 1440

Lens

• Focus: Auto, Manual, Semi-auto

• Focal Length:

  • Bullet channel: 2.8 mm

  • PTZ channel: 2.8 to 12 mm (4× optical)

• Zoom Speed:

  • PTZ channel: Approx. 3.3 s

• Field of View (FOV):

  • Bullet channel: H: 114.9°, V: 62.4°, D: 130.7°

  • PTZ channel: H: 98°–34.2°, V: 52°–19.2°, D: 111°–39°

• Aperture:

  • Bullet channel: F1.6

  • PTZ channel: F1.5 to F2.9

Illuminator

• Supplement Light Type:

  • Bullet channel: Hybrid (IR and White Light)

  • PTZ channel: IR

• Smart Supplement Light: Yes

• Supplement Light Range:

  • PTZ channel IR: Up to 40 m

  • Bullet channel IR: Up to 30 m, White Light: Up to 30 m

PTZ

• Movement Range:

  • Pan: 0° to 350°

  • Tilt: Bullet channel: 7° to 17° (manual); PTZ channel: -5° to 90°

• Pan Speed: 0.1°–30°/s (configurable), Preset speed: 30°/s

• Tilt Speed: 0.1°–30°/s (configurable), Preset speed: 30°/s

• Proportional Pan: Yes

• Presets: 300

• Patrol Scan: 8 patrols (up to 32 presets each)

• Power-off Memory: Yes

• Park Action: Preset, Patrol Scan

• 3D Positioning: Yes

• PTZ Status Display: Yes

• Preset Freezing: Yes

• Scheduled Tasks: Dome reboot, preset, patrol scan, dome adjust, aux output

Video

• Region of Interest (ROI): 1 fixed region for main stream

• Main Stream:

  • Bullet & PTZ channel:

    • 50 Hz: 25 fps (2560×1440, 1920×1080, 1280×720)

    • 60 Hz: 30 fps (2560×1440, 1920×1080, 1280×720)

• Sub-Stream:

  • 50 Hz: 25 fps (640×480, 640×360)

  • 60 Hz: 30 fps (640×480, 640×360)

• Third Stream:

  • 50 Hz: 25 fps (1280×720, 640×480, 640×360)

  • 60 Hz: 30 fps (1280×720, 640×480, 640×360)

• Video Compression: H.265, H.264, MJPEG

• Video Bit Rate: 32 kbps to 16384 kbps

• H.264 Type: Main profile, Baseline profile, High profile

• H.265 Type: Main profile

• Scalable Video Coding (SVC): Yes

Audio

• Audio Compression: G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC

• Audio Bit Rate:

  • MP2L2: 32–160 kbps

  • AAC: 16, 32, 64 kbps

  • MP3: 8–160 kbps

• Audio Sampling Rate:

  • MP2L2: 16 kHz

  • AAC-LC: 16 kHz

  • PCM: 8/16 kHz

  • MP3: 8/16 kHz

• Environment Noise Filtering: Yes

Network

• API: ONVIF (Profile S, G, T), ISAPI, SDK, ISUP

• Network Storage: NAS (NFS, SMB/CIFS), ANR

• Protocols: TCP/IP, SMTP, RTSP, FTP, WebSockets, IGMP, WebSocket, QoS, RTCP, HTTPS, PPPoE, SNMP, NTP, RTP, UDP, DNS, HTTP, DHCP, Bonjour, 802.1X, IPv4/IPv6, DDNS, ICMP, UPnP

• Simultaneous Live View: 20

• Users/Hosts: 32

• Security Features: 802.1X authenticated access, MAC address binding, username/password authentication, IP filter, HTTPS encryption

• Client Software: iVMS-4200, Hik-Connect

• Web Browser Compatibility: IE8+, Chrome 31–44, Firefox 30–51, Safari 8.0+


• Settings: Sharpness, Saturation, Brightness, Contrast

• Wide Dynamic Range (WDR): 120 dB

• SNR: ≥ 52 dB

• Defog: Digital Defog

• Day/Night Switch: Day, Night, Auto, Scheduled Switch

• Image Enhancement: BLC, HLC, 3D DNR

• Privacy Mask:

  • Bullet & PTZ: 24 programmable polygon masks

• Regional Focus:

  • Bullet: No

  • PTZ: Yes

• Regional Exposure:

  • Bullet: No

  • PTZ: Yes

• Image Parameters Switch: Yes

Interface

• Ethernet Interface: RJ45, 10M/100M self-adaptive Ethernet port

• On-board Storage: Micro SD/SDHC/SDXC (up to 512 GB)

• Reset Button: Yes

Events

• Basic Events: Motion detection, video tampering, exception, alarm input/output

• Smart Events: Line crossing detection, intrusion detection, region entrance/exit detection, audio exception

• Event Linkage:

  • Bullet & PTZ channel: Upload to FTP/NAS/Memory Card, Notify Surveillance Center, Send Email, Trigger Alarm Output, Trigger Recording, PTZ Actions (Preset, Patrol, Pattern Scan)

General

• General Functions: Mirror, Watermark, IP Address Filter, Password Protection

• Power Supply: 12 VDC, PoE+

• Operating Conditions: -30°C to 50°C (-22°F to 122°F), Humidity ≤ 95% (non-condensing)

• Demist: Heated Glass

• Material: PC

• Dimensions: 311.5 × 223.5 × 156 mm (12.26" × 8.80" × 6.14")

• Weight: Approx. 1.37 kg (3.02 lb.)

• Approvals: IP66 Standard, Surge Protection, Voltage Transient Protection

• Heatmap: based on deep learning algorithms, the camera counts people and presents an intuitive map
• Multi dewarping modes: the image can be dewarped to normal image for viewing intuitively
• Built-in mic and speaker: the camera supports two-way audio for real-time audio security monitoring and communication
• Built-in IR light: an IR range of 15 meters provides good visibility in low or even zero-light environments
• High resolution 9 MP: capturing clear images even when dewarped into 4-image PTZ mode
• Each image is clear and detailed
• Water and dust resistant (IP67) and vandal resistant (IK10)
• Datasheet

Camera Specifications

Camera

• Image Sensor: 1/1.8" Progressive Scan CMOS

• Max. Resolution: 3024 × 3024

• Min. Illumination:

  • Color: 0.01 Lux @ (F2.25, AGC ON)

  • B/W: 0.005 Lux @ (F2.25, AGC ON)

  • B/W: 0 Lux with IR

• Shutter Time: 1 s to 1/100,000 s

• Day & Night: IR cut filter

Lens

• Lens Type: Fixed focal lens, 2 mm

• Focal Length & FOV: 2 mm, 360° panoramic view

• Iris Type: Fixed

• Aperture: F2.25

• Depth of Field: 0.2 m to ∞

DORI Distance

• Detect: 23.2 m

• Observe: 9.2 m

• Recognize: 4.6 m

• Identify: 2.3 m

Illuminator

• Supplement Light Type: IR

• Supplement Light Range: Up to 15 m

• Supplement Light Number: 3

• IR Wavelength: 850 nm

• Smart Supplement Light: Yes

HEOP (Hikvision Embedded Open Platform)

• Open Resources: Memory: 41 MB, Smart RAM: 180 MB

• Computing Power: 2 TOPS

• Open Capability: HEOP 2.0 OpendevSDK

• Deep Learning Structure: Caffe, TensorFlow, PyTorch

• Programming Language: C, C++

Video

• Main Stream (50 Hz: 25 fps / 60 Hz: 30 fps):

  • Fisheye View: 3024 × 3024, 2560 × 2560, 2048 × 2048

  • 180 Panorama View: 3072 × 2304, 2048 × 1536

  • 180 Dual Channel Panorama View: 3072 × 1152

  • Panorama View: 3072 × 2304, 2048 × 1536

  • 4PTZ View: 1600 × 1200

  • Fisheye + 3PTZ View: 2560 × 2560 / 2048 × 2048 / 1280 × 1280 (main) + 1600 × 1200 (PTZ)

  • 4PTZ Fusion View: 3200 × 2400, 2048 × 1536

• Sub-Stream:

  • Fisheye View: 720 × 720, 480 × 480

  • 180 Panorama View: 640 × 480, 320 × 240

  • 180 Dual Channel Panorama View: 640 × 480, 320 × 240

  • Panorama View: 640 × 360, 320 × 240

  • 4PTZ View: 640 × 480, 320 × 240

• Video Compression:

  • Main Stream: H.265+/H.265/H.264+/H.264

  • Sub-Stream: H.265/H.264/MJPEG

• Video Bit Rate: 32 Kbps to 16 Mbps

• H.264 Type: Baseline/Main/High Profile

• H.265 Type: Main Profile

• Bit Rate Control: CBR, VBR

• SVC: H.264 and H.265 encoding

• ROI: 4 fixed regions per stream

Fisheye Display

• Mount Type: Wall, table, ceiling

• Decoding Mode: Hardware and software decoding

• Display Modes: 20 total (fisheye view, 180° panorama, 360° panorama + PTZ, multiple PTZs, hemisphere, cylinder, etc.)

Audio

• Audio Compression: G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC

• Audio Bit Rate: 8 to 320 Kbps depending on codec

• Audio Sampling Rate: 8/16/32/48 kHz

• Environment Noise Filtering: Yes

Network

• Protocols: TCP/IP, ICMP, HTTP/HTTPS, FTP/SFTP, DHCP, DNS, RTP/RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, ISUP, WebSocket, SIP

• Simultaneous Live View: Up to 20 channels

• API: ONVIF (Profile S, G, T), ISAPI, SDK, SIP support

• User/Host: Up to 32 users with 3 levels (admin/operator/user)

• Security Features: Password protection, HTTPS, 802.1X, watermark, IP filter, authentication methods, TPM 2.0 (FIPS 140-2 Level 2)

• Network Storage: NAS (NFS, SMB/CIFS), ANR support, Hikvision memory card encryption/health detection

• Client Software: iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect

• Web Browsers:

  • Plugin required: IE 10/11

  • Plugin free: Chrome 57+, Firefox 52+, Edge 89+, Safari 11+


• Image Parameters Switch: Yes

• Settings: Saturation, brightness, contrast, sharpness, white balance, AGC

• Day/Night Switch: Auto, schedule, alarm-triggered

• Wide Dynamic Range: Digital WDR

• Enhancements: BLC, HLC, 3D DNR, distortion correction, defog

• Privacy Mask: 8 programmable regions

• Picture Overlay: LOGO (128 × 128 bmp)

Interfaces

• Ethernet: 1 × RJ45 10/100 Mbps

• On-Board Storage: MicroSD/SDHC/SDXC up to 512 GB

• Built-in Microphone: 2

• Built-in Speaker: 1

• Audio I/O:

  • 1 input (line in, 3.5mm)

  • 1 output (line out, 3.5mm)

• Alarm I/O: 1 input, 1 output (max 24 VDC, 1 A)

• RS-485: 1 port (half duplex)

• Reset Key: Yes

Events

• Basic Events: Motion detection, video tampering, alarm I/O, network exceptions

• Smart Events: Line crossing, intrusion detection, region entrance/exiting, scene change, audio exception, defocus, object removal, unattended baggage

• Linkage: Upload to FTP/NAS/memory card, notify surveillance center, email, trigger alarms/recordings/captures

Deep Learning

• Heat Map:

  • Visit and dwell time based

  • Space/time reports available

General

• Power Supply:

  • 12 VDC ± 20%, 0.8 A, max 9.6 W

  • PoE: IEEE 802.3af, Class 3, max 9.6 W

• Material: Metal

• Dimensions: Ø140.3 mm × 59.4 mm (Ø5.5" × 2.3")

• Package Dimensions: 260 × 230 × 135 mm (10.2" × 9.1" × 5.3")

• Weight: Approx. 715 g (1.58 lb)

• Weight with Package: Approx. 1206 g (2.66 lb)

• Operating/Storage Conditions:

  • Temperature: -30 °C to 60 °C (-30 °F to 140 °F)

  • Humidity: 95% or less (non-condensing)

• Languages: 33 supported (including English, Russian, French, Spanish, Korean, etc.)

• Functions: Heartbeat, flash log, password reset via email, anti-banding, one-key reset

• Cable Length: 0.31 m (1.02 ft.)

Certifications

• EMC: CE-EMC, RCM, ICES-003, KC

• Safety: UL, CB, CE-LVD, BIS

• Environment: CE-RoHS, WEEE, REACH

• Protection: IP67, IK10

• High quality imaging with 5 MP resolution
• Efficient H.265+ compression technology
• 180° fisheye view
• Clear imaging against strong back light due to 120 dB true WDR technology
• Audio and alarm interface available
• Datasheet

Camera

• Image Sensor: 1/2.7" Progressive Scan CMOS

• Max. Resolution: 2560 × 1920

• Min. Illumination:

  • Color: 0.017 Lux @ (F2.25, AGC ON)

  • B/W: 0 Lux with IR

• Shutter Time: 1/3 s to 1/100,000 s

• Day & Night: IR cut filter

Lens

• Lens Type: Fixed focal lens

• Focal Length: 1.05 mm

• Field of View:

  • Horizontal: 180°

  • Vertical: 180°

  • Diagonal: 180°

• Focus: Fixed

• Lens Mount: M12

• Iris Type: Fixed

• Aperture: F2.25

• Depth of Field: 0.1 m to ∞

DORI Distance

• Detection (D): 21 m

• Observation (O): 8 m

• Recognition (R): 4 m

• Identification (I): 2 m

Illuminator

• Supplement Light Type: IR

• Light Range: Up to 8 m

• Smart Supplement Light: Yes

• IR Wavelength: 850 nm

Video

• Main Stream:

  • 50 Hz: 25 fps @ 2560 × 1920 / 2048 × 1536 / 1280 × 960

  • 60 Hz: 30 fps @ 2560 × 1920 / 2048 × 1536 / 1280 × 960

• Sub-Stream:

  • 50 Hz: 25 fps @ 640 × 480

  • 60 Hz: 30 fps @ 640 × 480

• Video Compression:

  • Main Stream: H.265+/H.265/H.264+/H.264

  • Sub-Stream: H.265/H.264/MJPEG

• Video Bit Rate: 32 Kbps to 16 Mbps

• H.264 Type: Baseline, Main, High Profile

• H.265 Type: Main Profile

• Region of Interest (ROI): 1 fixed region (main stream)

Fisheye Display

• Mounting: Wall, table, ceiling

• Display Modes: 14 modes (Fisheye View, 180° Panorama, 4PTZ, etc.)

Audio

• Audio Type: Mono

• Compression Formats: G.711ulaw/alaw, G.722.1, G.726, MP2L2, PCM, AAC-LC

• Audio Bit Rate:

  • 64 Kbps (G.711ulaw/alaw)

  • 16 Kbps (G.722.1, G.726)

  • 32–160 Kbps (MP2L2)

  • 16–64 Kbps (AAC-LC)

• Sampling Rate: 8 kHz / 16 kHz

• Environment Noise Filtering: Yes

Network

• Protocols Supported: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, SSL/TLS

• Simultaneous Live View: Up to 6 channels

• API Support: ONVIF (Profiles S, G, T), ISAPI

• User Management: Up to 32 users (administrator, operator, user)

• Client Software: iVMS-4200, Hik-Connect, Hik-Central

• Security Features: Password protection, HTTPS encryption, IP filtering, TLS 1.1/1.2, Security audit logs

• Web Browser Support:

  • Live view with plug-in: IE 10+

  • Local access: Chrome 57+, Firefox 52+

• Network Storage: NAS (NFS, SMB/CIFS)


• Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, white balance (adjustable via client or browser)

• Day/Night Switching: Day, Night, Auto, Schedule

• Image Enhancements: BLC, 3D DNR

• Wide Dynamic Range (WDR): 120 dB

Interface

• Ethernet Port: 1× RJ45 10M/100M self-adaptive

• On-Board Storage: microSD/microSDHC/microSDXC card up to 256 GB

• Built-in Microphone: Yes (-U models)

• Audio I/O:

  • 1 Input (line-in, max 3.3 Vpp, 4.7 KΩ impedance)

  • 1 Output (line-out, max 3.3 Vpp, 100 Ω impedance)

• Alarm I/O: 1 input, 1 output (max. 12 VDC, 30 A)

• Reset Button: Yes

• Power Output: 12 VDC, max. 100 mA

Event Management

• Basic Events: Motion detection, video tampering, exceptions

• Smart Events: Line crossing detection, intrusion detection

• Event Linkage: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording/capture/alarm output

General

• Power Supply:

  • 12 VDC ± 25%, 0.5 A, max. 6 W

  • PoE (IEEE 802.3af, Class 3), max. 7.5 W

• Material: ADC12

• Dimensions: Ø119.9 mm × 41.2 mm (Ø4.7" × 1.6")

• Package Dimensions: 150 mm × 125 mm × 99 mm (5.9" × 4.9" × 3.9")

• Weight: Approx. 320 g (0.7 lb)

• Package Weight: Approx. 500 g (1.1 lb)

• Languages Supported: 13 languages (including English, Turkish, Polish, etc.)

• Storage Conditions: -10°C to 50°C, 95% humidity or less (non-condensing)

• Operating Conditions: -10°C to 50°C, 95% humidity or less (non-condensing)

• General Features: Heartbeat, anti-banding, mirror, password protection

Certifications

• EMC: CE-EMC, RCM, IC, KC

• Safety: UL, CB, CE-LVD, BIS, LOA

• Environment: CE-RoHS compliant

• HikAI-ISP for excellent noise reduction effect
• 24/7 colorful imaging via ColorVu technology
• Scene-adaptive WDR
• Focus on Person and Vehicle classification based on deep learning
• Built-in arrayed dual-microphone for real-time high quality audio security
• Provide real-time security via built-in two-way audio
• Anti-corrosion design, providing reliability and longevity compared to standard (NEMA4X)
• Smart Hybrid Light: Integrates IR and White lights, 3 supplemental lighting modes
• Water and dust resistant (IP67)
• Audio and alarm interface available
• Active strobe light and audio alarm to warn intruders off
• Datasheet

Camera Specifications

Image Sensor

• Type: 1/1.8" Progressive Scan CMOS

• Max. Resolution: 3840 × 2160

• Min. Illumination:

  • Color: 0.0005 Lux @ (F1.0, AGC ON)

  • 0 Lux with white light

• Shutter Time: 1 s to 1/100,000 s

• Day & Night: IR cut filter

• Angle Adjustment:

  • Pan: 0° to 360°

  • Tilt: 0° to 75°

  • Rotate: 0° to 360°

Lens

• Type: Fixed focal lens (2.8 mm and 4 mm options)

• Focal Length & FOV:

  • 2.8 mm: Horizontal FOV 108.8°, Vertical FOV 56.4°, Diagonal FOV 134.3°

  • 4 mm: Horizontal FOV 93.3°, Vertical FOV 47.2°, Diagonal FOV 114.2°

• Lens Mount: M16

• Iris Type: Fixed

• Aperture: F1.0

• Depth of Field:

  • 2.8 mm: 3.3 m to ∞

  • 4 mm: 3.8 m to ∞

DORI (Detect, Observe, Recognize, Identify)

• 2.8 mm: D: 89 m, O: 35 m, R: 17 m, I: 8 m

• 4 mm: D: 109 m, O: 43 m, R: 21 m, I: 10 m

Illuminator

• Supplement Light Type: White Light, IR

• Range: Up to 30 m

• Smart Supplement Light: Yes

• IR Wavelength: 850 nm

Video

• Main Stream:

  • 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

  • 60 Hz: 30 fps (same resolutions)

• Sub-Stream:

  • 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

  • 60 Hz: 30 fps (same resolutions)

• Third Stream:

  • 50/60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

  • Third stream supported under certain settings

• Compression:

  • Main: H.265/H.264/H.264+/H.265+

  • Sub: H.265/H.264/MJPEG

  • Third: H.265/H.264

• Bitrate: 32 Kbps to 16 Mbps

• H.264 Type: Baseline, Main, High Profile

• H.265 Type: Main Profile

• Bitrate Control: CBR, VBR

• SVC: H.264, H.265

• ROI: 1 fixed region (main stream)

Audio

• Type: Mono

• Compression: G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC

• Bit Rate:

  • G.711: 64 Kbps

  • G.722.1 / G.726: 16 Kbps

  • MP2L2: 32–192 Kbps

  • MP3: 8–320 Kbps

  • AAC-LC: 16–64 Kbps

• Sampling Rate: 8/16/32/48 kHz

• Noise Filtering: Yes

Network

• Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP

• Simultaneous Live View: Up to 6 channels

• API: ONVIF (Profiles S, G, T), ISAPI, SDK, ISUP

• Users: Up to 32 (Admin, Operator, User)

• Security:

  • HTTPS, 802.1X, IP filtering, watermark, audit logs

  • TLS 1.1/1.2/1.3, MAC address authentication

• Network Storage: NAS (NFS, SMB/CIFS), ANR

• Client Software: iVMS-4200, Hik-Connect, Hik-Central

• Web Browser Support:

  • Plug-in Free: Chrome 80+, Firefox 80+, Edge 89+

  • Local Service: Same


• Parameter Switch: Yes

• Settings: Rotation, saturation, brightness, contrast, sharpness, gain, white balance (via software/web browser)

• Day/Night Modes: Day, Night, Auto, Schedule

• Enhancements: BLC, HLC, 3D DNR

• SNR: ≥ 52 dB

• WDR: 130 dB

• Privacy Mask: 4 programmable polygonal areas

Interface

• Ethernet: 1 RJ45 10M/100M self-adaptive

• Storage: microSD/SDHC/SDXC up to 512 GB

• Speaker: Max. 2 W, SPL 110 dB @ 10 cm

• Microphone:

  • Arrayed dual-microphone (-2U)

  • 1 input (line in), max 3.3 Vpp, 4.7 KΩ

  • 1 output (line out), max 3.3 Vpp, 100 Ω

• Alarm I/O: 1 input, 1 output (max. 24 VDC/AC, 1 A)

• Reset Key: Yes

Events

• Basic Events:

  • Motion detection (human/vehicle targeting), tamper, exception

• Smart Events:

  • Scene change detection

• Linkage Methods:

  • FTP/NAS upload, email, alarm output, recording, snapshots, audible alerts, strobe light

Deep Learning Functions

• Face Capture: Supported

• Perimeter Protection:

  • Line crossing, intrusion, region entry/exit (human/vehicle detection)

General

• Power Supply:

  • 12 VDC ± 25%, 1.29 A, Max. 15.5 W (reverse polarity protected)

  • PoE: IEEE 802.3at, Class 4, Max. 17 W

• Material: Metal housing and cover

• Dimensions: Ø138.3 mm × 115.4 mm (Ø5.4" × 4.5")

• Package Size: 170 × 170 × 160 mm (6.7" × 6.7" × 6.3")

• Weight:

  • Net: ~820 g (1.8 lb)

  • With Package: ~1200 g (2.6 lb)

• Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), ≤ 95% RH (non-condensing)

• Storage Conditions: Same as operating

• General Features:

  • Heartbeat, mirror, flash log, email password reset, pixel counter, anti-banding

• Languages Supported: 33 (English, Russian, Spanish, French, Chinese, etc.)

Flashing Light (Model Specific)

• /SRB Model: Red & Blue Light

• /SL Model: White Light

Certifications

• EMC: CE, RCM, IC, KC

• Safety: UL, CB, CE-LVD

• Environmental: CE-RoHS

• Ingress Protection: IP67

• Anti-Corrosion: NEMA 4X

• HikAI-ISP for excellent noise reduction effect
• 24/7 colorful imaging via ColorVu technology
• Scene-adaptive WDR
• Focus on Person and Vehicle classification based on deep learning
• Built-in arrayed dual-microphone for real-time high quality audio security
• Provide real-time security via built-in two-way audio
• Anti-corrosion design, providing reliability and longevity compared to standard (NEMA4X)
• Smart Hybrid Light: Integrates IR and White lights, 3 supplemental lighting modes
• Water and dust resistant (IP67)
• Audio and alarm interface available
• Active strobe light and audio alarm to warn intruders off
• Datasheet

Camera Specifications

Image Sensor

• Type: 1/1.8" Progressive Scan CMOS

• Max. Resolution: 3840 × 2160

• Min. Illumination:

  • Color: 0.0005 Lux @ (F1.0, AGC ON)

  • 0 Lux with white light

• Shutter Time: 1 s to 1/100,000 s

• Day & Night: IR cut filter

• Angle Adjustment:

  • Pan: 0° to 360°

  • Tilt: 0° to 75°

  • Rotate: 0° to 360°

Lens

• Type: Fixed focal lens (2.8 mm and 4 mm options)

• Focal Length & FOV:

  • 2.8 mm: Horizontal FOV 108.8°, Vertical FOV 56.4°, Diagonal FOV 134.3°

  • 4 mm: Horizontal FOV 93.3°, Vertical FOV 47.2°, Diagonal FOV 114.2°

• Lens Mount: M16

• Iris Type: Fixed

• Aperture: F1.0

• Depth of Field:

  • 2.8 mm: 3.3 m to ∞

  • 4 mm: 3.8 m to ∞

DORI (Detect, Observe, Recognize, Identify)

• 2.8 mm: D: 89 m, O: 35 m, R: 17 m, I: 8 m

• 4 mm: D: 109 m, O: 43 m, R: 21 m, I: 10 m

Illuminator

• Supplement Light Type: White Light, IR

• Range: Up to 30 m

• Smart Supplement Light: Yes

• IR Wavelength: 850 nm

Video

• Main Stream:

  • 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

  • 60 Hz: 30 fps (same resolutions)

• Sub-Stream:

  • 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

  • 60 Hz: 30 fps (same resolutions)

• Third Stream:

  • 50/60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

  • Third stream supported under certain settings

• Compression:

  • Main: H.265/H.264/H.264+/H.265+

  • Sub: H.265/H.264/MJPEG

  • Third: H.265/H.264

• Bitrate: 32 Kbps to 16 Mbps

• H.264 Type: Baseline, Main, High Profile

• H.265 Type: Main Profile

• Bitrate Control: CBR, VBR

• SVC: H.264, H.265

• ROI: 1 fixed region (main stream)

Audio

• Type: Mono

• Compression: G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC

• Bit Rate:

  • G.711: 64 Kbps

  • G.722.1 / G.726: 16 Kbps

  • MP2L2: 32–192 Kbps

  • MP3: 8–320 Kbps

  • AAC-LC: 16–64 Kbps

• Sampling Rate: 8/16/32/48 kHz

• Noise Filtering: Yes

Network

• Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP

• Simultaneous Live View: Up to 6 channels

• API: ONVIF (Profiles S, G, T), ISAPI, SDK, ISUP

• Users: Up to 32 (Admin, Operator, User)

• Security:

  • HTTPS, 802.1X, IP filtering, watermark, audit logs

  • TLS 1.1/1.2/1.3, MAC address authentication

• Network Storage: NAS (NFS, SMB/CIFS), ANR

• Client Software: iVMS-4200, Hik-Connect, Hik-Central

• Web Browser Support:

  • Plug-in Free: Chrome 80+, Firefox 80+, Edge 89+

  • Local Service: Same


• Parameter Switch: Yes

• Settings: Rotation, saturation, brightness, contrast, sharpness, gain, white balance (via software/web browser)

• Day/Night Modes: Day, Night, Auto, Schedule

• Enhancements: BLC, HLC, 3D DNR

• SNR: ≥ 52 dB

• WDR: 130 dB

• Privacy Mask: 4 programmable polygonal areas

Interface

• Ethernet: 1 RJ45 10M/100M self-adaptive

• Storage: microSD/SDHC/SDXC up to 512 GB

• Speaker: Max. 2 W, SPL 110 dB @ 10 cm

• Microphone:

  • Arrayed dual-microphone (-2U)

  • 1 input (line in), max 3.3 Vpp, 4.7 KΩ

  • 1 output (line out), max 3.3 Vpp, 100 Ω

• Alarm I/O: 1 input, 1 output (max. 24 VDC/AC, 1 A)

• Reset Key: Yes

Events

• Basic Events:

  • Motion detection (human/vehicle targeting), tamper, exception

• Smart Events:

  • Scene change detection

• Linkage Methods:

  • FTP/NAS upload, email, alarm output, recording, snapshots, audible alerts, strobe light

Deep Learning Functions

• Face Capture: Supported

• Perimeter Protection:

  • Line crossing, intrusion, region entry/exit (human/vehicle detection)

General

• Power Supply:

  • 12 VDC ± 25%, 1.29 A, Max. 15.5 W (reverse polarity protected)

  • PoE: IEEE 802.3at, Class 4, Max. 17 W

• Material: Metal housing and cover

• Dimensions: Ø138.3 mm × 115.4 mm (Ø5.4" × 4.5")

• Package Size: 170 × 170 × 160 mm (6.7" × 6.7" × 6.3")

• Weight:

  • Net: ~820 g (1.8 lb)

  • With Package: ~1200 g (2.6 lb)

• Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), ≤ 95% RH (non-condensing)

• Storage Conditions: Same as operating

• General Features:

  • Heartbeat, mirror, flash log, email password reset, pixel counter, anti-banding

• Languages Supported: 33 (English, Russian, Spanish, French, Chinese, etc.)

Flashing Light (Model Specific)

• /SRB Model: Red & Blue Light

• /SL Model: White Light

Certifications

• EMC: CE, RCM, IC, KC

• Safety: UL, CB, CE-LVD

• Environmental: CE-RoHS

• Ingress Protection: IP67

• Anti-Corrosion: NEMA 4X

• HikAI-ISP for excellent noise reduction effect
• 24/7 colorful imaging via ColorVu technology
• Scene-adaptive WDR
• Focus on Person and Vehicle classification based on deep learning
• Built-in arrayed dual-microphone for real-time high quality audio security
• Provide real-time security via built-in two-way audio
• Anti-corrosion design, providing reliability and longevity compared to standard (NEMA4X)
• Smart Hybrid Light: Integrates IR and White lights, 3 supplemental lighting modes
• Water and dust resistant (IP67)
• Audio and alarm interface available
• Active strobe light and audio alarm to warn intruders off
• Datasheet

Camera Specifications

Image Sensor

• Type: 1/1.8" Progressive Scan CMOS

• Max. Resolution: 3840 × 2160

• Min. Illumination:

  • Color: 0.0005 Lux @ (F1.0, AGC ON)

  • 0 Lux with white light

• Shutter Time: 1 s to 1/100,000 s

• Day & Night: IR cut filter

• Angle Adjustment:

  • Pan: 0° to 360°

  • Tilt: 0° to 75°

  • Rotate: 0° to 360°

Lens

• Type: Fixed focal lens (2.8 mm and 4 mm options)

• Focal Length & FOV:

  • 2.8 mm: Horizontal FOV 108.8°, Vertical FOV 56.4°, Diagonal FOV 134.3°

  • 4 mm: Horizontal FOV 93.3°, Vertical FOV 47.2°, Diagonal FOV 114.2°

• Lens Mount: M16

• Iris Type: Fixed

• Aperture: F1.0

• Depth of Field:

  • 2.8 mm: 3.3 m to ∞

  • 4 mm: 3.8 m to ∞

DORI (Detect, Observe, Recognize, Identify)

• 2.8 mm: D: 89 m, O: 35 m, R: 17 m, I: 8 m

• 4 mm: D: 109 m, O: 43 m, R: 21 m, I: 10 m

Illuminator

• Supplement Light Type: White Light, IR

• Range: Up to 30 m

• Smart Supplement Light: Yes

• IR Wavelength: 850 nm

Video

• Main Stream:

  • 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

  • 60 Hz: 30 fps (same resolutions)

• Sub-Stream:

  • 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

  • 60 Hz: 30 fps (same resolutions)

• Third Stream:

  • 50/60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

  • Third stream supported under certain settings

• Compression:

  • Main: H.265/H.264/H.264+/H.265+

  • Sub: H.265/H.264/MJPEG

  • Third: H.265/H.264

• Bitrate: 32 Kbps to 16 Mbps

• H.264 Type: Baseline, Main, High Profile

• H.265 Type: Main Profile

• Bitrate Control: CBR, VBR

• SVC: H.264, H.265

• ROI: 1 fixed region (main stream)

Audio

• Type: Mono

• Compression: G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC

• Bit Rate:

  • G.711: 64 Kbps

  • G.722.1 / G.726: 16 Kbps

  • MP2L2: 32–192 Kbps

  • MP3: 8–320 Kbps

  • AAC-LC: 16–64 Kbps

• Sampling Rate: 8/16/32/48 kHz

• Noise Filtering: Yes

Network

• Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP

• Simultaneous Live View: Up to 6 channels

• API: ONVIF (Profiles S, G, T), ISAPI, SDK, ISUP

• Users: Up to 32 (Admin, Operator, User)

• Security:

  • HTTPS, 802.1X, IP filtering, watermark, audit logs

  • TLS 1.1/1.2/1.3, MAC address authentication

• Network Storage: NAS (NFS, SMB/CIFS), ANR

• Client Software: iVMS-4200, Hik-Connect, Hik-Central

• Web Browser Support:

  • Plug-in Free: Chrome 80+, Firefox 80+, Edge 89+

  • Local Service: Same


• Parameter Switch: Yes

• Settings: Rotation, saturation, brightness, contrast, sharpness, gain, white balance (via software/web browser)

• Day/Night Modes: Day, Night, Auto, Schedule

• Enhancements: BLC, HLC, 3D DNR

• SNR: ≥ 52 dB

• WDR: 130 dB

• Privacy Mask: 4 programmable polygonal areas

Interface

• Ethernet: 1 RJ45 10M/100M self-adaptive

• Storage: microSD/SDHC/SDXC up to 512 GB

• Speaker: Max. 2 W, SPL 110 dB @ 10 cm

• Microphone:

  • Arrayed dual-microphone (-2U)

  • 1 input (line in), max 3.3 Vpp, 4.7 KΩ

  • 1 output (line out), max 3.3 Vpp, 100 Ω

• Alarm I/O: 1 input, 1 output (max. 24 VDC/AC, 1 A)

• Reset Key: Yes

Events

• Basic Events:

  • Motion detection (human/vehicle targeting), tamper, exception

• Smart Events:

  • Scene change detection

• Linkage Methods:

  • FTP/NAS upload, email, alarm output, recording, snapshots, audible alerts, strobe light

Deep Learning Functions

• Face Capture: Supported

• Perimeter Protection:

  • Line crossing, intrusion, region entry/exit (human/vehicle detection)

General

• Power Supply:

  • 12 VDC ± 25%, 1.29 A, Max. 15.5 W (reverse polarity protected)

  • PoE: IEEE 802.3at, Class 4, Max. 17 W

• Material: Metal housing and cover

• Dimensions: Ø138.3 mm × 115.4 mm (Ø5.4" × 4.5")

• Package Size: 170 × 170 × 160 mm (6.7" × 6.7" × 6.3")

• Weight:

  • Net: ~820 g (1.8 lb)

  • With Package: ~1200 g (2.6 lb)

• Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), ≤ 95% RH (non-condensing)

• Storage Conditions: Same as operating

• General Features:

  • Heartbeat, mirror, flash log, email password reset, pixel counter, anti-banding

• Languages Supported: 33 (English, Russian, Spanish, French, Chinese, etc.)

Flashing Light (Model Specific)

• /SRB Model: Red & Blue Light

• /SL Model: White Light

Certifications

• EMC: CE, RCM, IC, KC

• Safety: UL, CB, CE-LVD

• Environmental: CE-RoHS

• Ingress Protection: IP67

• Anti-Corrosion: NEMA 4X

• 6 MP Smart Hybrid Light with ColorVu Fixed Turret Network Camera
• HikAI-ISP for excellent noise reduction effect
• 24/7 colorful imaging via ColorVu technology
• Scene-adaptive WDR
• Focus on Person and Vehicle classification based on deep learning
• Built-in arrayed dual-microphone for real-time high quality audio security
• Provide real-time security via built-in two-way audio
• Anti-corrosion design, providing reliability and longevity compared to standard (NEMA4X)
• Smart Hybrid Light: Integrates IR and White lights, 3 supplemental lighting modes
• Water and dust resistant (IP67)
• Audio and alarm interface available
• Active strobe light and audio alarm to warn intruders off
• Black Colour
• Datasheet

Camera Specifications

Camera

• Image Sensor: 1/1.8" Progressive Scan CMOS

• Max. Resolution: 3200 × 1800

• Min. Illumination:

  • Color: 0.0005 Lux @ (F1.0, AGC ON)

  • 0 Lux with light

• Shutter Time: 1 s to 1/100,000 s

• Day & Night: IR cut filter

• Angle Adjustment:

  • Pan: 0° to 360°

  • Tilt: 0° to 75°

  • Rotate: 0° to 360°

Lens

• Type: Fixed focal lens, 2.8 mm and 4 mm optional

• Focal Length & FOV:

  • 2.8 mm:

    • Horizontal: 108.8°

    • Vertical: 56.4°

    • Diagonal: 134.3°

  • 4 mm:

    • Horizontal: 93.3°

    • Vertical: 47.2°

    • Diagonal: 114.2°

• Mount: M16

• Iris Type: Fixed

• Aperture: F1.0

• Depth of Field:

  • 2.8 mm: 3.3 m to ∞

  • 4 mm: 3.8 m to ∞

DORI (Detection, Observation, Recognition, Identification)

• 2.8 mm: D: 89 m, O: 35 m, R: 17 m, I: 8 m

• 4 mm: D: 109 m, O: 43 m, R: 21 m, I: 10 m

Illuminator

• Supplement Light Type: White Light, IR

• Range: Up to 30 m

• Smart Supplement Light: Yes

• IR Wavelength: 850 nm

Video

• Main Stream:

  • 50 Hz: 25 fps (3200×1800, 2688×1520, 1920×1080, 1280×720)

  • 60 Hz: 30 fps (same resolutions)

• Sub-Stream:

  • 50 Hz: 25 fps

  • 60 Hz: 30 fps

• Third Stream:

  • 50/60 Hz: 10 fps (limited by settings)

• Compression:

  • Main: H.265/H.264/H.264+/H.265+

  • Sub: H.265/H.264/MJPEG

  • Third: H.265/H.264

• Bit Rate: 32 Kbps to 16 Mbps

• Profiles:

  • H.264: Baseline/Main/High

  • H.265: Main

• Control: CBR, VBR

• SVC: H.264 & H.265

• ROI: 1 fixed region for main stream

Audio

• Type: Mono sound

• Compression: G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC

• Bit Rate:

  • G.711: 64 Kbps

  • G.722.1 & G.726: 16 Kbps

  • MP2L2: 32–192 Kbps

  • MP3: 8–320 Kbps

  • AAC-LC: 16–64 Kbps

• Sampling Rate: 8/16/32/48 kHz

• Noise Filtering: Yes

Network

• Protocols: TCP/IP, HTTP/S, FTP, DHCP, DNS, RTP, RTSP, NTP, SMTP, SNMP, etc.

• Simultaneous Live View: Up to 6 channels

• API: ONVIF (S/G/T), ISAPI, SDK, ISUP

• Users: Up to 32 (admin/operator/user roles)

• Security:
  Password protection, HTTPS, 802.1X, TLS 1.1/1.2/1.3, IP filtering, etc.

• Network Storage: NAS (NFS, SMB/CIFS), ANR

• Client Software: iVMS-4200, Hik-Connect, Hik-Central

• Browser Support: Chrome 80+, Firefox 80+, Edge 89+


• Parameter Switch: Yes

• Settings: Saturation, brightness, contrast, gain, white balance, etc.

• Day/Night Switch: Day, Night, Auto, Schedule

• Enhancement: BLC, HLC, 3D DNR, Distortion Correction, Defog

• SNR: ≥ 52 dB

• WDR: 130 dB

• Stabilization: EIS

• Privacy Mask: 4 programmable polygon masks

Interface

• Ethernet: 1 × RJ45 10M/100M

• Storage: MicroSD/SDHC/SDXC (up to 512 GB)

• Speaker: Max 2 W, 110 dB @ 10 cm

• Microphone: Built-in dual mic

• Audio I/O:

  • Input: 1 (line-in), 3.3 Vpp max

  • Output: 1 (line-out), 3.3 Vpp max

• Alarm I/O: 1 input, 1 output (max 24 VDC/24 VAC, 1 A)

• Reset Key: Yes

Events

• Basic: Motion detection, video tampering, exceptions

• Smart: Scene change detection

• Linkage: Upload, alarm output, recording, capture, light/sound warning

Deep Learning Functions

• Face Capture: Yes

• Perimeter Protection: Line crossing, intrusion, region entrance/exiting

  • Human/vehicle classification supported

General

• Power:

  • 12 VDC ±25%, 1.29 A, max 15.5 W (Ø5.5 mm plug)

  • PoE: IEEE 802.3at, Class 4, max 17 W

• Material: Metal (cover and body)

• Dimensions: Ø138.3 mm × 115.4 mm (5.4" × 4.5")

• Package Dimensions: 170 × 170 × 160 mm (6.7" × 6.7" × 6.3")

• Weight: 820 g (1.8 lb), with package: 1200 g (2.6 lb)

• Operating/Storage Temp: -30 °C to 60 °C (-22 °F to 140 °F), ≤ 95% RH (non-condensing)

• General Features: Heartbeat, mirror, log, password reset via email, pixel counter, anti-banding

• Languages Supported: 33 (incl. English, Russian, German, Spanish, Chinese, etc.)

• Flashing Light:

  • /SRB model: Red & Blue

  • /SL model: White

Certifications & Protection

• EMC: CE, RCM, IC, KC

• Safety: UL, CB, CE-LVD

• Environmental: CE-RoHS

• Ingress Protection: IP67

• Anti-Corrosion: NEMA 4X

• 6 MP Smart Hybrid Light with ColorVu Fixed Turret Network Camera
• HikAI-ISP for excellent noise reduction effect
• 24/7 colorful imaging via ColorVu technology
• Scene-adaptive WDR
• Focus on Person and Vehicle classification based on deep learning
• Built-in arrayed dual-microphone for real-time high quality audio security
• Provide real-time security via built-in two-way audio
• Anti-corrosion design, providing reliability and longevity compared to standard (NEMA4X)
• Smart Hybrid Light: Integrates IR and White lights, 3 supplemental lighting modes
• Water and dust resistant (IP67)
• Audio and alarm interface available
• Active strobe light and audio alarm to warn intruders off
• Datasheet

Camera Specifications

Camera

• Image Sensor: 1/1.8" Progressive Scan CMOS

• Max. Resolution: 3200 × 1800

• Min. Illumination:

  • Color: 0.0005 Lux @ (F1.0, AGC ON)

  • 0 Lux with light

• Shutter Time: 1 s to 1/100,000 s

• Day & Night: IR cut filter

• Angle Adjustment:

  • Pan: 0° to 360°

  • Tilt: 0° to 75°

  • Rotate: 0° to 360°

Lens

• Type: Fixed focal lens, 2.8 mm and 4 mm optional

• Focal Length & FOV:

  • 2.8 mm:

    • Horizontal: 108.8°

    • Vertical: 56.4°

    • Diagonal: 134.3°

  • 4 mm:

    • Horizontal: 93.3°

    • Vertical: 47.2°

    • Diagonal: 114.2°

• Mount: M16

• Iris Type: Fixed

• Aperture: F1.0

• Depth of Field:

  • 2.8 mm: 3.3 m to ∞

  • 4 mm: 3.8 m to ∞

DORI (Detection, Observation, Recognition, Identification)

• 2.8 mm: D: 89 m, O: 35 m, R: 17 m, I: 8 m

• 4 mm: D: 109 m, O: 43 m, R: 21 m, I: 10 m

Illuminator

• Supplement Light Type: White Light, IR

• Range: Up to 30 m

• Smart Supplement Light: Yes

• IR Wavelength: 850 nm

Video

• Main Stream:

  • 50 Hz: 25 fps (3200×1800, 2688×1520, 1920×1080, 1280×720)

  • 60 Hz: 30 fps (same resolutions)

• Sub-Stream:

  • 50 Hz: 25 fps

  • 60 Hz: 30 fps

• Third Stream:

  • 50/60 Hz: 10 fps (limited by settings)

• Compression:

  • Main: H.265/H.264/H.264+/H.265+

  • Sub: H.265/H.264/MJPEG

  • Third: H.265/H.264

• Bit Rate: 32 Kbps to 16 Mbps

• Profiles:

  • H.264: Baseline/Main/High

  • H.265: Main

• Control: CBR, VBR

• SVC: H.264 & H.265

• ROI: 1 fixed region for main stream

Audio

• Type: Mono sound

• Compression: G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC

• Bit Rate:

  • G.711: 64 Kbps

  • G.722.1 & G.726: 16 Kbps

  • MP2L2: 32–192 Kbps

  • MP3: 8–320 Kbps

  • AAC-LC: 16–64 Kbps

• Sampling Rate: 8/16/32/48 kHz

• Noise Filtering: Yes

Network

• Protocols: TCP/IP, HTTP/S, FTP, DHCP, DNS, RTP, RTSP, NTP, SMTP, SNMP, etc.

• Simultaneous Live View: Up to 6 channels

• API: ONVIF (S/G/T), ISAPI, SDK, ISUP

• Users: Up to 32 (admin/operator/user roles)

• Security:
  Password protection, HTTPS, 802.1X, TLS 1.1/1.2/1.3, IP filtering, etc.

• Network Storage: NAS (NFS, SMB/CIFS), ANR

• Client Software: iVMS-4200, Hik-Connect, Hik-Central

• Browser Support: Chrome 80+, Firefox 80+, Edge 89+


• Parameter Switch: Yes

• Settings: Saturation, brightness, contrast, gain, white balance, etc.

• Day/Night Switch: Day, Night, Auto, Schedule

• Enhancement: BLC, HLC, 3D DNR, Distortion Correction, Defog

• SNR: ≥ 52 dB

• WDR: 130 dB

• Stabilization: EIS

• Privacy Mask: 4 programmable polygon masks

Interface

• Ethernet: 1 × RJ45 10M/100M

• Storage: MicroSD/SDHC/SDXC (up to 512 GB)

• Speaker: Max 2 W, 110 dB @ 10 cm

• Microphone: Built-in dual mic

• Audio I/O:

  • Input: 1 (line-in), 3.3 Vpp max

  • Output: 1 (line-out), 3.3 Vpp max

• Alarm I/O: 1 input, 1 output (max 24 VDC/24 VAC, 1 A)

• Reset Key: Yes
