• High quality imaging with 8 MP resolution
• Excellent low-light performance via powered-by-DarkFighter technology
• Efficient H.265+ compression technology
• Clear imaging against strong back light due to 120 dB true WDR technology
• Focus on human and vehicle targets classification based on deep learning
• Built-in microphone for real-time audio security (-SU)
• Audio and alarm interface available(-SU)
• Water and dust resistant (IP67) and vandal resistant (IK10)
• Datasheet

Camera

• Image Sensor: 1/1.8" Progressive Scan CMOS
• Max. Resolution: 3840 × 2160
• Min. Illumination:
  • Color: 0.003 Lux @ (F1.6, AGC ON)
  • B/W: 0 Lux with IR
• Shutter Time: 1/3 s to 1/100,000 s
• Day & Night: IR cut filter
• Angle Adjustment:
  • Pan: 0° to 355°
  • Tilt: 0° to 75°
  • Rotate: 0° to 355°

Lens

• Lens Type: Fixed focal lens, 2.8 and 4 mm optional
• Focal Length & FOV:
  • 2.8 mm: Horizontal FOV 111°, Vertical FOV 59°, Diagonal FOV 131°
  • 4 mm: Horizontal FOV 87°, Vertical FOV 47°, Diagonal FOV 102°
• Lens Mount: M12
• Iris Type: Fixed
• Aperture: F1.6

DORI (Detect, Observe, Recognize, Identify)

• 2.8 mm:
  • Detect: 89.2 m
  • Observe: 35.4 m
  • Recognize: 17.8 m
  • Identify: 8.9 m
• 4 mm:
  • Detect: 99.4 m
  • Observe: 39.4 m
  • Recognize: 19.9 m
  • Identify: 9.9 m

Illuminator

• Supplement Light Type: IR
• Supplement Light Range: Up to 30 m
• Smart Supplement Light: Yes
• IR Wavelength: 850 nm

Video

• Main Stream:
  • 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
  • 60 Hz: 24 fps (3840 × 2160), 30 fps (other resolutions)
• Sub-Stream:
  • 50 Hz: 25 fps (640 × 480, 640 × 360)
  • 60 Hz: 30 fps (640 × 480, 640 × 360)
• Third Stream: 10 fps across resolutions (Under certain settings)
• Video Compression:
  • Main: H.265/H.264/H.264+/H.265+
  • Sub-stream: H.265/H.264/MJPEG
  • Third Stream: H.265/H.264
• Bit Rate: 32 Kbps to 16 Mbps
• Region of Interest (ROI): 1 fixed region

Audio

• Audio Type: -U: Mono sound
• Audio Compression:
  • G.711ulaw, G.711alaw, G.722.1, G.726, MP2L2, PCM, MP3, AAC
• Sampling Rate: 8/16/32/44.1/48 kHz
• Noise Filtering: Yes

Network

• Protocols: TCP/IP, HTTP, HTTPS, FTP, RTP, RTSP, NTP, SNMP, and more
• Simultaneous Live View: Up to 6 channels
• User/Host: Up to 32 users with 3 levels (administrator, operator, user)
• Security Features: Password protection, HTTPS encryption, IP filtering

Image Settings

• Wide Dynamic Range (WDR): 120 dB
• SNR: ≥ 52 dB
• Image Enhancements: BLC, HLC, 3D DNR

Interface

• Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive port
• On-Board Storage: Up to 256 GB (MicroSD/SDHC/SDXC card)
• Built-in Microphone: -U model only

Event Detection

• Basic Events: Motion detection, video tampering, exceptions
• Smart Events: Scene change detection, intrusion detection, and more
• Linkage: Email, FTP upload, memory card, and NAS storage

General

• Power Supply:
  • 12 VDC ± 25%
  • PoE: 802.3af, Class 3
• Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), ≤ 95% humidity
• Protection: IP67, IK10
• Certifications: CE, FCC, RoHS
