Warranty: 3 Year Dahua ANZ Manufacturer Warranty

VTM59D - Desktop Support

Features:

• Made from aluminium alloy with a paint-coated surface.
• Compatible with 7" indoor monitors.
• Supports multiple indoor monitor models, including Model D, E, F, G, H, and K.

Basic Specifications

• Surface Treatment: Paint spraying
• Product Type: Desktop bracket
• Casing Material: Aluminium alloy
• Inclined Angle: 47°
• Bracket Height: Unadjustable

General Specifications

• Appearance Color: Silver
• Product Dimensions:
  • 115.6 mm × 139.8 mm × 103.3 mm (4.55" × 5.50" × 4.07") (L × W × H)
• Packaging Dimensions:
  • 135.0 mm × 155.0 mm × 120.0 mm (5.31" × 4.72" × 6.10") (L × W × H)
• Operating Temperature: –10°C to +55°C (+14°F to +131°F)
• Operating Environment: Indoor
• Net Weight: 190 g (0.42 lb)
• Gross Weight: 265 g (0.58 lb)

Installation & Compatibility

• Installation: Desk Mount
• Applicable Product Models: Model D, E, F, G, H, K

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

PFA107

Adapter Plate of PT Network Camera

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• 4MP CVI IR Eyeball Camera
• 120dB True WDR, 3DNR
• Max 4MP real-time
• HD and SD dual-output
• 2.8mm fixed lens
• Max. IR length 50m, Smart IR
• IP67, DC12V

• User Manual Click on the PDF Icon :-

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• DH-IPC-HDBW3466EP-AS-AUS Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• 4MP 1/3'' CMOS image sensor, excellent low luminance performance and high definition of images.
• Outputs max. 4 MP (2688 x 1520) @25/30 fps.
• H.265 codec, high compression rate, ultra-low bit rate.
• Built-in IR LED, max. IR distance: 30 m.
• ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.
• Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
• Intelligent detection: Intrusion, tripwire (support the classification and vaccurate detection of vehicle and human).
• Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
• Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
• 12 VDC/PoE power supply facilitates installation.
• IP67, IK10 protection.
• SMD 4.0, AI SSA.

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• DH-IPC-HDBW3466RP-ZAS-AUS Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• DH-IPC-HDBW3666EP-AS-AUS Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• DH-IPC-HDBW3666RP-ZAS-AUS Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

DH-IPC-HDBW3866EP-AS-AUS-BLK Dahua 8MP (4K) Dome Fixed Black Camera

> 8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
> Outputs max. 8 MP (3840 x 2160) @25/30 fps.
> H.265 codec allows high compression ratio and ultra-low bit rate.
> Built-in IR LED, max. IR distance: 30 m.
> ROI, SMART H.264 +/H.265+,AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67, IK10 protection.
> SMD 4.0, AI SSA.

• DH-IPC-HDBW3866EP-AS-AUS-BLKSpecification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• DH-IPC-HDBW3866EP-AS-AUS Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

DH-IPC-HDBW3866RP-ZAS-AUS-BLK Dahua 8MP (4K) Dome Motorised Camera

> 8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
> Outputs max. 8MP (3840 x 2160) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 40 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only - ZAS supports); audio: 1 in, 1 out (Only - ZAS supports); max. 256 G Micro SD card; built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67, IK10 protection.
> SMD 4.0, AI SSA.

• DH-IPC-HDBW3866RP-ZAS-AUS-BLK Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• DH-IPC-HDBW3866RP-ZAS-AUS Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

5MP IR Fixed-Focal Eyeball WizSense Network Camera

Key Features

• 5 MP 1/2.7" CMOS image sensor delivering high-definition images with excellent low-light performance

• Maximum resolution up to 5 MP (2960 × 1668) at 20 fps

• Supports 2688 × 1520 resolution at 25/30 fps

• H.265 compression for high efficiency and ultra-low bitrate

• Built-in IR LED with illumination distance up to 30 m

• Smart codec support: Smart H.264+ and Smart H.265+

• ROI support for optimized bandwidth and storage usage

• Advanced image functions including rotation mode, WDR, 3D NR, HLC, BLC, and digital watermarking

• Intelligent perimeter protection: intrusion and tripwire with accurate human and vehicle classification

• Abnormality detection including motion detection, video tampering, audio detection, SD card issues, network disconnection, IP conflict, illegal access, and voltage detection

• Supports Micro SD card up to 256 GB

• Built-in microphone

• Power supply via 12 VDC or PoE

• IP67 weatherproof protection

• SMD Plus supported

• Datasheet

Camera

• Image Sensor: 1/2.7" CMOS

• Max. Resolution: 2960 (H) × 1688 (V)

• ROM: 128 MB

• RAM: 256 MB

• Scanning System: Progressive

• Electronic Shutter Speed: Auto / Manual, 1/3 s to 1/100,000 s

• Minimum Illumination:

  • 0.007 lux @ F1.6 (Color, 30 IRE)

  • 0.0007 lux @ F1.6 (B/W, 30 IRE)

  • 0 lux (IR on)

• Signal-to-Noise Ratio: >56 dB

• IR Illumination Distance: Up to 30 m

• IR Control: Auto or Manual

• IR LED Quantity: 1

• Angle Adjustment:

  • Pan: 0° to 360°

  • Tilt: 0° to 78°

  • Rotation: 0° to 360°

Lens

• Lens Type: Fixed-focal

• Lens Mount: M12

• Focal Length Options: 2.8 mm or 3.6 mm

• Max. Aperture: F1.6

• Field of View:

  • 2.8 mm: Horizontal 111°, Vertical 58°, Diagonal 132°

  • 3.6 mm: Horizontal 92°, Vertical 45°, Diagonal 110°

• Iris Control: Fixed

• Close Focus Distance:

  • 2.8 mm: 1.1 m

  • 3.6 mm: 1.7 m

DORI Performance

• 2.8 mm Lens:

  • Detect: 63.6 m

  • Observe: 25.4 m

  • Recognize: 12.7 m

  • Identify: 6.4 m

• 3.6 mm Lens:

  • Detect: 85.4 m

  • Observe: 34.2 m

  • Recognize: 17.1 m

  • Identify: 8.5 m

DORI values are based on EN-62676-4 standards and do not represent intelligent analytics distances.

Intelligence

• Perimeter Protection (IVS): Intrusion and tripwire with human and vehicle classification

• Smart Search: Works with Smart NVR for intelligent event search and playback

Video

• Video Compression: H.265, H.264, H.264H, H.264B, MJPEG (sub-stream only)

• Smart Codec: Smart H.265+, Smart H.264+

• Stream Capability: Dual stream

• Frame Rate:

  • Main stream:

    • 2960 × 1668 at 1–20 fps

    • 2688 × 1520 at 1–25/30 fps

  • Sub-stream:

    • 704 × 576 at 1–25 fps

    • 704 × 480 at 1–30 fps

• Supported Resolutions:

  • 5 MP, 4 MP, 3 MP, 1080p, 1.3 MP, 720p, D1, VGA, CIF

• Bit Rate Control: CBR / VBR

• Video Bit Rate:

  • H.264: 32 kbps to 8192 kbps

  • H.265: 12 kbps to 8192 kbps

• Day/Night Mode: Auto (ICR), Color, B/W

• WDR: 120 dB

• Image Enhancements: BLC, HLC, 3D NR

• White Balance: Auto, natural, street lamp, outdoor, manual, regional custom

• Gain Control: Auto or Manual

• Motion Detection: On/Off (4 configurable regions)

• ROI: Supported (4 areas)

• Image Rotation: 0°, 90°, 180°, 270°

• Mirror: Supported

• Privacy Masking: Up to 4 areas

Audio

• Built-in Microphone: Yes

• Audio Compression: G.711a, G.711Mu, PCM, G.726

Alarm Events

• Motion detection

• Video tampering

• Tripwire and intrusion

• Audio detection

• Voltage detection

• SD card error, full, or missing

• Network disconnection

• IP conflict

• Illegal access

• SMD events

• Security exceptions

Network

• Ethernet Port: RJ-45 (10/100 Base-T)

• Network Protocols: IPv4, IPv6, HTTP, HTTPS, TCP, UDP, RTSP, RTP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, Bonjour, P2P

• Interoperability: ONVIF Profile S, G, and T; CGI

• Max Users: 20

• Total Bandwidth: 48 Mbps

Storage

• Storage Options: Micro SD card (up to 256 GB), FTP, SFTP, NAS

Software & Compatibility

• Browsers: Internet Explorer, Chrome, Firefox

• Management Software: SmartPSS Lite, DSS, DMSS

• Mobile App: iOS and Android

Cyber Security

• Configuration encryption and video encryption

• Secure boot and trusted upgrade

• Firmware encryption

• Account lockout and security logs

• HTTPS, 802.1X, IP/MAC filtering

• X.509 certificate generation and import

Power

• Power Supply: 12 VDC or PoE (802.3af)

• Power Consumption:

  • Basic: 2.2 W (12 VDC), 2.9 W (PoE)

  • Max: 4.1 W (12 VDC), 5.0 W (PoE)

Environment

• Operating Temperature: –40 °C to +60 °C

• Operating Humidity: ≤95%

• Storage Temperature: –40 °C to +60 °C

• Storage Humidity: ≤95%

Protection

• IP67 weatherproof rating

Physical

• Casing Material:

  • Inner core: Metal

  • Cover: Metal

  • Decoration ring: Plastic

  • Mounting plate: Metal

• Product Dimensions: 99.1 mm × Φ121.9 mm

• Net Weight: 0.48 kg

• Gross Weight: 0.68 kg

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

•   DH-IPC-HDW3666EMP-S-AUS Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

DH-IPC-HDW3666EMP-S-AUS-BLK Dahua 6MP Turret Fixed Camera

> 6MP 1/2.7'' CMOS image sensor, excellent low luminance performance and high definition of images.
> Outputs max. 6 MP (3072 x 2048) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 50 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply, easy for installation.
> IP67 protection.
> SMD 4.0, AI SSA.

• DH-IPC-HDW3666EMP-S-AUS-BLK Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

•   DH-IPC-HDW3666TP-ZS-AUS Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

8MP Smart Dual Illumination Active Deterrence Fixed-focal Eyeball WizSense Network Camera

• Image Sensor and Quality

  • 8-MP 1/2.7" CMOS image sensor for low luminance and high-definition images.
  • Outputs a maximum resolution of 8 MP (3840 × 2160) at 25/30 fps.

• Video Compression and Codec

  • H.265 codec for high compression with ultra-low bit rate.
  • Supports ROI, SMART H.264+/H.265+, and AI-enhanced H.264/H.265 for optimized storage and bandwidth.

• Illumination

  • Built-in warm light and IR LED with up to 30 m illumination range for both.

• Advanced Features

  • Rotation mode, WDR, 3D NR, HLC, BLC, and digital watermarking for flexible monitoring across scenarios.
  • Intelligent monitoring with intrusion and tripwire detection, including human/vehicle classification.

• Abnormality Detection

  • Detects motion, privacy masking, scene changes, and audio anomalies.
  • Monitors SD card issues (missing, full, or error) and network issues (disconnection, IP conflict, illegal access).
  • Includes voltage detection for power-related abnormalities.

• Alarm and Audio Capabilities

  • 1 alarm input and output; 1 audio input and output.
  • Built-in dual microphone and 1-channel speaker for two-way audio communication.

• Storage and Power

  • Supports up to 256 GB Micro SD card.
  • 12 VDC or PoE power supply for flexible installation.

• Protection and Alarms

  • IP67-rated for weather resistance.
  • Equipped with sound and light alarms featuring red and blue lights.

• AI Features and Controls

  • Supports SMD 4.0 for accurate motion detection.
  • AI SSA and one-tap arming/disarming functionality.
  • Configurable SMD areas within warm light zones for alarm triggers.
• Datasheet

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

8MP Smart Dual Illumination Active Deterrence Fixed-focal Eyeball WizSense Network Camera

• Image Sensor and Quality

  • 8-MP 1/2.7" CMOS image sensor for low luminance and high-definition images.
  • Outputs a maximum resolution of 8 MP (3840 × 2160) at 25/30 fps.

• Video Compression and Codec

  • H.265 codec for high compression with ultra-low bit rate.
  • Supports ROI, SMART H.264+/H.265+, and AI-enhanced H.264/H.265 for optimized storage and bandwidth.

• Illumination

  • Built-in warm light and IR LED with up to 30 m illumination range for both.

• Advanced Features

  • Rotation mode, WDR, 3D NR, HLC, BLC, and digital watermarking for flexible monitoring across scenarios.
  • Intelligent monitoring with intrusion and tripwire detection, including human/vehicle classification.

• Abnormality Detection

  • Detects motion, privacy masking, scene changes, and audio anomalies.
  • Monitors SD card issues (missing, full, or error) and network issues (disconnection, IP conflict, illegal access).
  • Includes voltage detection for power-related abnormalities.

• Alarm and Audio Capabilities

  • 1 alarm input and output; 1 audio input and output.
  • Built-in dual microphone and 1-channel speaker for two-way audio communication.

• Storage and Power

  • Supports up to 256 GB Micro SD card.
  • 12 VDC or PoE power supply for flexible installation.

• Protection and Alarms

  • IP67-rated for weather resistance.
  • Equipped with sound and light alarms featuring red and blue lights.

• AI Features and Controls

  • Supports SMD 4.0 for accurate motion detection.
  • AI SSA and one-tap arming/disarming functionality.
  • Configurable SMD areas within warm light zones for alarm triggers.
• Datasheet

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

DH-IPC-HDW3866EMP-S-AUS-BLK Dahua 8MP (4K) Turret Fixed Camera

> 8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
> Outputs max. 8MP (3840 x 2160) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 30 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67 protection.
> SMD 4.0, AI SSA.

• DH-IPC-HDW3866EMP-S-AUS-BLK Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

DH-IPC-HDW3866TP-ZS-AUS-BLK Dahua 8MP (4K) Turret Motorised Camera

> 8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
> Outputs max. 8 MP (3840 x 2160) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 40 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67 protection.
> SMD 4.0, AI SSA.

• DH-IPC-HDW3866TP-ZS-AUS-BLK Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty
