• Datasheet of DH-IPC-HFW5541TP-SE-0280BPDF
• Installation Guide of DH-IPC-HFW5541TP-SE-0280BPDF
• Quick Start Guide of DH-IPC-HFW5541TP-SE-0280BPDF
• Dimension of DH-IPC-HFW5541TP-SE-0280B

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• Datasheet of DH-IPC-HDBW5541RP-ASE-0280BPDF
• Quick Start Guide of DH-IPC-HDBW5541RP-ASE-0280BPDF
• Installation Guide of DH-IPC-HDBW5541RP-ASE-0280BPDF
• Dimension of DH-IPC-HDBW5541RP-ASE-0280B

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• Datasheet of DH-IPC-HDBW5541EP-ZEPDF
• Quick Start Guide of DH-IPC-HDBW5541EP-ZEPDF
• Installation Guide of DH-IPC-HDBW5541EP-ZEPDF
• Dimension of DH-IPC-HDBW5541EP-ZE

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• Datasheet of DH-IPC-HDW5541TMP-ASE-0280BPDF
• Installtion Guide of DH-IPC-HDW5541TMP-ASE-0280BPDF
• Quick Start Guide of DH-IPC-HDW5541TMP-ASE-0280BPDF
• Dimension of DH-IPC-HDW5541TMP-ASE-0280B

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Dahua Access ANPR Camera

• Image Sensor and Processing

  • High-performance CMOS image sensor and processor for continuous metadata extraction 24/7.

• Intelligent Recognition

  • Equipped with deep learning algorithms to recognize unlicensed vehicles, as well as detect vehicle type, brand, and color.

• Ports and Control

  • Built-in signal, data, and communication ports for integration with external devices like entry and exit barriers.
  • Remote controllers available for enhanced control options.

• Illumination and Installation

  • Built-in LED for simplified installation and setup.

• Design and Power Efficiency

  • All-in-one structure with junction box and bracket, designed for low power consumption.

• Protection

  • IP67-rated for dust and water resistance and IK10-rated for vandal resistance.

• Intrusion and Loitering Detection

  • Detects intrusion and loitering, triggering light and voice alarms to actively deter targets.
  • Customizable audio options allow for imported and edited sounds.

• Lens Adaptability

  • Motorized vari-focal lens for flexibility across different scenarios.
• Datasheet

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

ARC3000H-FW2(868)
Alarm Hub

• Supports up to 150 wireless peripherals: 6 sirens, 64 wireless keyfobs, 4 repeaters, 8 keypads, 8 PIR cameras

• Displays peripheral status: signal strength, battery level, temperature, program version

• Network connection via wired, Wi-Fi, 4G, 3G, or GPRS

• Dual SIM, single standby

• Supports Automatic Network Replenishment (ANR)

• Video linkage available through the mobile app

• Frequency hopping and two-way communication ensure stable transmission

• Supports cloud updates with automatic recovery from update failure

Video Input

• 4-channel IPC

Input/Output

• Wireless Zone
  Supports up to 150 wireless peripherals:
  6 sirens, 64 wireless keyfobs, 4 repeaters, 8 keypads, 8 PIR cameras

• Port
  1 × RJ-45 10M/100M Ethernet port

• Network Mode
  Ethernet, Wi-Fi, and cellular network
  (Supports dual SIM cards, only one active at a time)

Power & Indicators

• Storage Battery
  Built-in lithium battery (12-hour standby)

• Indicator Light
  1 multi-status LED (alarm, arming, disarming, networking, malfunction)

• Buttons
  1 × Reset
  1 × Power
  1 × AP

• Buzzer
  Built-in

Functionality

• Tamper Alarm: Yes

• SMS Notifications: Yes (up to 5 phone numbers)

• Calling Alarm: Yes (up to 5 phone numbers)

• Video Linkage: Supported

• Network Protocols: TCP/IP, PPTP, L2TP, DHCP, UPNP, NTP

• Remote Upgrade: Cloud update

• Arm/Disarm Methods: App, keyfob, schedule

• Parameter Retention During Power Failure: Yes

• User Management: App user sharing supported

• Cache: Max. 50 entries (ANR)

• Low Battery Alarm: Yes

• Search Functions: Push messages, device status, firmware version, signal strength

• Event Logs: Up to 5,000 entries

Wireless

• Carrier Frequency: 868.0 MHz – 868.6 MHz

• Transmitter Power (EIRP): ≤25 mW

• Communication Distance: Up to 2,000 m (6,561.68 ft) in open space

• Communication Mechanism: Two-way

• Encryption: AES128

• Frequency Hopping: Supported

Wi-Fi

• Standards: IEEE 802.11b/g/n

• Frequency Range: 2400 – 2483.5 MHz

• Transmit Power: ≤20 dBm @ 2400–2483.5 MHz

Cellular Network

• Network Standards: GSM / WCDMA / LTE

• Frequency Bands:

  • 4G: FDD-LTE (B1/B3/B7/B8/B20), TDD-LTE (B38/B40/B41)

  • 3G: WCDMA (B1/B5/B8)

  • 2G: GSM 900 / 1800 MHz

• Transmit Power (EIRP):

  • 4G: 23 dBm ±2 dB

  • 3G: 24 dBm (+1/–3 dB)

  • 2G:

    • GSM900: 30 dBm ±3 dB

    • GSM1800: 33 dBm ±3 dB

General

• Power Supply: 12 V DC, 1.5 A (optional EU/UK/US adapters)

• Operating Temperature: –10 °C to +50 °C (+14 °F to +122 °F) (indoor)

• Operating Humidity: 10% – 90% RH

• Installation: Wall mount / Desktop

• Casing Material: PC + ABS

• Battery Life: 12-hour standby

Dimensions & Weight

• Product Dimensions: 163.0 × 163.0 × 32.0 mm (6.42" × 6.42" × 1.26")

• Packaging Dimensions: 219.0 × 187.0 × 91.0 mm (8.62" × 7.36" × 3.58")

• Net Weight: 0.38 kg (0.84 lb)

• Gross Weight: 0.8 kg (1.76 lb)

Certifications

• CE Certified

• EN 50131-1:2006 + A1:2009 + A2:2017 + A3:2020

• EN 50131-3:2009

• EN 50131-5-3:2017

• EN 50131-6:2017

• EN 50131-10:2014

• EN 50136-2:2013

• Security Grade: 2

• Environmental Class: II

• ATS Category: SP2 / DP2

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

ARC3000H-FW2(868)
Alarm Hub

• Supports up to 150 wireless peripherals: 6 sirens, 64 wireless keyfobs, 4 repeaters, 8 keypads, 8 PIR cameras

• Displays peripheral status: signal strength, battery level, temperature, program version

• Network connection via wired, Wi-Fi, 4G, 3G, or GPRS

• Dual SIM, single standby

• Supports Automatic Network Replenishment (ANR)

• Video linkage available through the mobile app

• Frequency hopping and two-way communication ensure stable transmission

• Supports cloud updates with automatic recovery from update failure

Video Input

• 4-channel IPC

Input/Output

• Wireless Zone
  Supports up to 150 wireless peripherals:
  6 sirens, 64 wireless keyfobs, 4 repeaters, 8 keypads, 8 PIR cameras

• Port
  1 × RJ-45 10M/100M Ethernet port

• Network Mode
  Ethernet, Wi-Fi, and cellular network
  (Supports dual SIM cards, only one active at a time)

Power & Indicators

• Storage Battery
  Built-in lithium battery (12-hour standby)

• Indicator Light
  1 multi-status LED (alarm, arming, disarming, networking, malfunction)

• Buttons
  1 × Reset
  1 × Power
  1 × AP

• Buzzer
  Built-in

Functionality

• Tamper Alarm: Yes

• SMS Notifications: Yes (up to 5 phone numbers)

• Calling Alarm: Yes (up to 5 phone numbers)

• Video Linkage: Supported

• Network Protocols: TCP/IP, PPTP, L2TP, DHCP, UPNP, NTP

• Remote Upgrade: Cloud update

• Arm/Disarm Methods: App, keyfob, schedule

• Parameter Retention During Power Failure: Yes

• User Management: App user sharing supported

• Cache: Max. 50 entries (ANR)

• Low Battery Alarm: Yes

• Search Functions: Push messages, device status, firmware version, signal strength

• Event Logs: Up to 5,000 entries

Wireless

• Carrier Frequency: 868.0 MHz – 868.6 MHz

• Transmitter Power (EIRP): ≤25 mW

• Communication Distance: Up to 2,000 m (6,561.68 ft) in open space

• Communication Mechanism: Two-way

• Encryption: AES128

• Frequency Hopping: Supported

Wi-Fi

• Standards: IEEE 802.11b/g/n

• Frequency Range: 2400 – 2483.5 MHz

• Transmit Power: ≤20 dBm @ 2400–2483.5 MHz

Cellular Network

• Network Standards: GSM / WCDMA / LTE

• Frequency Bands:

  • 4G: FDD-LTE (B1/B3/B7/B8/B20), TDD-LTE (B38/B40/B41)

  • 3G: WCDMA (B1/B5/B8)

  • 2G: GSM 900 / 1800 MHz

• Transmit Power (EIRP):

  • 4G: 23 dBm ±2 dB

  • 3G: 24 dBm (+1/–3 dB)

  • 2G:

    • GSM900: 30 dBm ±3 dB

    • GSM1800: 33 dBm ±3 dB

General

• Power Supply: 12 V DC, 1.5 A (optional EU/UK/US adapters)

• Operating Temperature: –10 °C to +50 °C (+14 °F to +122 °F) (indoor)

• Operating Humidity: 10% – 90% RH

• Installation: Wall mount / Desktop

• Casing Material: PC + ABS

• Battery Life: 12-hour standby

Dimensions & Weight

• Product Dimensions: 163.0 × 163.0 × 32.0 mm (6.42" × 6.42" × 1.26")

• Packaging Dimensions: 219.0 × 187.0 × 91.0 mm (8.62" × 7.36" × 3.58")

• Net Weight: 0.38 kg (0.84 lb)

• Gross Weight: 0.8 kg (1.76 lb)

Certifications

• CE Certified

• EN 50131-1:2006 + A1:2009 + A2:2017 + A3:2020

• EN 50131-3:2009

• EN 50131-5-3:2017

• EN 50131-6:2017

• EN 50131-10:2014

• EN 50136-2:2013

• Security Grade: 2

• Environmental Class: II

• ATS Category: SP2 / DP2

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

ARD324-W2(S)
Wireless Door Detector Plus

• Displays ambient temperature and supports overheating alarm

• Utilizes frequency hopping and two-way communication for stable performance

• Supports cloud updates with automatic recovery on update failure

• Equipped with jamming detection and encrypted communication

• Detects tilt and shock events, triggering alarms accordingly

Input/Output

• Alarm Input:
  1 (Normally Closed / Normally Open / Impulse Count)

Functionality

• Indicator Light:
  1 × Green alarm indicator

• Button:
  1 × Power switch

• Remote Update:
  Cloud update supported

• Low Battery Detection:
  Yes

• Tamper Protection:
  Yes

• Temperature Measuring Range:
  Indoor: –15 °C to +65 °C (+5 °F to +149 °F)

• Measuring Accuracy:
  ±1 °C (±1.8 °F)

Technical

• Sensors:
  Triaxial accelerometer, reed switch

• Movement Distance:
  < 40 mm (1.57")

• Shock Detection Sensitivity:
  High, Normal, Low

• Tilt Detection:
  Up to 25°

• Test Mode:
  Supported

• Recommended Scenario:
  Non-metal doors

• Operating Current:
  12 µA

• Alarm Current:
  2.3 mA

Wireless Communication

• Carrier Frequency:
  433.1 MHz – 434.6 MHz

• Communication Mechanism:
  Two-way

• Communication Distance:
  Up to 1000 m (3280.84 ft) in open space

• Encryption Mode:
  AES128

• Frequency Hopping:
  Yes

General

• Power Supply:
  CR123A × 1

• Battery Life (70% Efficiency):

  • 3 years (External input: NO)

  • 1.5 years (External input: NC)

• Power Consumption:
  104 mW

• Operating Temperature:
  Indoor: –10 °C to +55 °C (+14 °F to +131 °F)

• Operating Humidity:
  10% – 90% RH

• Storage Temperature:
  –10 °C to +55 °C (+14 °F to +131 °F)

• Storage Humidity:
  10% – 90% RH

Physical

• Product Dimensions:
  100.2 mm × 20.8 mm × 20.3 mm (3.94" × 0.82" × 0.80")

• Packaging Dimensions:
  135.0 mm × 98.5 mm × 27.8 mm (5.32" × 3.87" × 1.09")

• Net Weight:
  70 g (0.15 lb)

• Gross Weight:
  115 g (0.25 lb)

• Installation Method:
  Bracket mount

• Casing Material:
  PC + ABS

Certifications

• CE Certified

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

ARD821-W2(868)
Wireless Panic Button

• Two-way RF communication

• Multi-color LED indicators for various statuses

• Supports cloud updates with automatic recovery on failure

• Designed to prevent accidental presses

• IP54-rated for dust and water resistance

Functionality

• Indicator Light: 1 LED for multiple statuses (pairing, communication, etc.)

• Remote Update: Cloud update supported

• Button: 1

• Signal Strength Detection: Yes

• Low Battery Detection: Yes

• Battery Level Display: Visible on mobile app

Wireless

• Carrier Frequency: 868.0 MHz – 868.6 MHz

• Communication Distance: Up to 1,200 m (3,937.01 ft) in open space

• Communication Mechanism: Two-way

• Encryption: AES128

• Frequency Hopping: Supported

Technical

• Operating Current: 28 mA

• Test Mode: Yes

General

• Operating Temperature: –10 °C to +55 °C (+14 °F to +131 °F) (indoor use)

• Operating Humidity: 10% – 90% RH

• Battery Type: CR2032

• Battery Life: Approx. 3 years (based on twice weekly usage)

• Installation: Wall mount or portable

• Casing Material: PC + ABS

• Protection Rating: IP54

Dimensions & Weight

• Product Dimensions: 55 × 36 × 14.2 mm (2.17" × 1.42" × 0.56")

• Packaging Dimensions: 95 × 59.5 × 30.5 mm (3.74" × 2.34" × 1.20")

• Net Weight: 18 g (0.04 lb)

• Gross Weight: 48 g (0.11 lb)

Certifications

• CE Certified

• EN 50131-1:2006 + A1:2009 + A2:2017 + A3:2020

• EN 50131-3:2009

• EN 50131-6:2017

• EN 50131-5-3:2017

• Security Grade: 2

• Environmental Class: II

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

PFA117

Ceiling Mount Bracket

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

PFB220C

Ceiling Mount Bracket

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

PFB300C

Ceiling Mount Bracket

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

PFA151

Corner Mount Bracket

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

6-Port Cloud Managed Desktop Switch with 4-Port PoE

Key Features

• Complies with IEEE 802.3, 802.3u, 802.3x, 802.3ab standards

• Supports IEEE 802.3af / 802.3at / Hi-PoE power supply standards

• Intelligent PoE with PoE power consumption management and remote PoE on/off

• Wide operating temperature range

• Fully enclosed metal housing, dust-proof design

• Datasheet

Hardware Specifications

General

• Included Power Adapter: Yes

• PoE Support: Yes

• Reset Button: 1

• Power Supply: External, 53 VDC / 1.226 A

Ports

• Total Ethernet Ports: 6

• PoE Ports:

  • Ports 1–4: 4 × RJ-45, 10/100 Mbps (PoE)

• Uplink Ports:

  • Ports 5–6: 2 × RJ-45, 10/100/1000 Mbps

Environmental Specifications

• Operating Temperature: –10 °C to +55 °C (+14 °F to +131 °F)

• Operating Humidity: 5%–95% RH (non-condensing)

• Storage Temperature: –40 °C to +70 °C (–40 °F to +158 °F)

• Storage Humidity: 5%–95% RH (non-condensing)

Power Consumption

• Idle: ≤ 3 W

• Full Load: 65 W

Performance

• Switching Layer: Layer 2

• Switching Capacity: 4.8 Gbps

• Packet Forwarding Rate: 3.57 Mpps

• Packet Buffer: 4 Mbit

• Jumbo Frame: 9216 Bytes

• MAC Address Table: 8K

• VLAN Support: Up to 32 VLANs

• MTBF: 232.62 years

PoE Specifications

• PoE Protocols: IEEE 802.3af / IEEE 802.3at / Hi-PoE

• PoE Output Power:

  • Port 1: ≤ 60 W

  • Ports 2–4: ≤ 30 W per port

  • Total PoE Budget: ≤ 60 W

• PoE Pin Assignment:

  • V+: 1, 2, 4, 5

  • V–: 3, 6, 7, 8

• Long-Distance PoE Transmission: Yes

Network & Management Features

• VLAN Type: Port-based VLAN

• Flow Control: IEEE 802.3x

• DHCP: DHCP Client

• Management:

  • Web Management

  • App Management

• Management Type: Smart Managed / Cloud Managed

Protection

• ESD Protection:

  • Air Discharge: 8 kV

  • Contact Discharge: 6 kV

• Lightning Protection:

  • Common Mode: 4 kV

  • Differential Mode: 2 kV

Physical Specifications

• Net Weight: 0.28 kg (0.64 lb)

• Gross Weight: 0.92 kg (2.02 lb)

• Product Dimensions:

  • 130 × 90 × 26 mm (5.11" × 3.54" × 1.02")

• Packaging Dimensions:

  • 265 × 238 × 76 mm (10.43" × 9.37" × 2.99")

• Casing Material: Sheet metal

Installation

• Mounting Options: Desktop mount, Wall mount

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

6-Port Cloud Managed Desktop Gigabit Switch with 4-Port PoE

Key Features

• 4 × RJ45 Gigabit PoE ports, 2 × RJ45 Gigabit uplink ports

• 60 W total PoE budget

  • IEEE 802.3af/at on all PoE ports

  • Additional Hi-PoE support on Port 1 (orange port)

• DIP switch control for quick mode switching:

  • Cloud-Managed Mode

  • PoE Watchdog

  • Long-Distance PoE

• Wide operating temperature: –10 °C to +55 °C

• Supports VLAN and loop protection

• Web-managed and centralised cloud management via DoLynk App

• Easy configuration with auto network detection and setup

• Datasheet

Basic Specifications

• Switching Layer: Layer 2

• Switching Capacity: 12 Gbps

• Packet Forwarding Rate: 8.9 Mpps

Port Configuration

• Ports 1–4: 4 × RJ-45 10/100/1000 Mbps (PoE)

• Ports 5–6: 2 × RJ-45 10/100/1000 Mbps (Gigabit uplink)

Environmental Specifications

• Operating Temperature: –10 °C to +55 °C (+14 °F to +131 °F)

• Operating Humidity: 10%–90% RH (non-condensing)

• Storage Temperature: –40 °C to +70 °C (–40 °F to +158 °F)

• Storage Humidity: 5%–95% RH (non-condensing)

Power

• Power Supply: External, 53 VDC / 0.8 A

• Power Consumption:

  • Idle: ≤ 3 W

  • Full Load: 65 W

PoE Specifications

• PoE Support: Yes

• PoE Protocols: IEEE 802.3af / IEEE 802.3at / Hi-PoE

• PoE Output Power:

  • Port 1: ≤ 60 W

  • Ports 2–4: ≤ 30 W per port

  • Total PoE Budget: ≤ 60 W

• PoE Power Management:

  • PoE power consumption management

  • Remote PoE on/off

  • Automatic PoE shutdown on overload detection

• PoE Pin Assignment:

  • V+: 1, 2, 4, 5

  • V–: 3, 6, 7, 8

• Long-Distance PoE: Yes

Hardware Features

DIP Switch Functions

• Managed Mode:

  • ON (default): Local web + cloud management

  • OFF: Unmanaged mode

• PoE Watchdog:

  • Monitors ports 1–4

  • Automatically restarts PoE if no traffic is detected for 2 minutes

  • Only active when Managed Mode is OFF

• Extend Mode:

  • Ports 1–4 support up to 250 m transmission at 10 Mbps

  • Only active when Managed Mode is OFF

• Reset Button: 1

Performance

• MTBF: 232.62 years

• Packet Buffer: 4 Mbit

• Jumbo Frame: 9216 Bytes

• MAC Address Table: 2K

• Supported VLANs: 32

Network Standards

• IEEE Standards:

  • IEEE 802.3

  • IEEE 802.3u

  • IEEE 802.3x

  • IEEE 802.3ab

  • IEEE 802.3az

Network Features

• VLAN: IEEE 802.1Q VLAN

• Port Features:

  • IEEE 802.3x Flow Control

  • Unknown Unicast Suppression

  • Multicast Storm Control

  • Broadcast Storm Control

  • MAC + Port Binding

  • Loop Prevention

• Port Mirroring:

  • N:1 Mirroring

  • Local Port Mirroring

• LLDP Support: Yes

• DHCP: DHCP Client

• Security: Port Isolation

Management

• Management Methods:

  • Web Management

  • Cloud Management

• Monitoring & Maintenance:

  • Logs

  • Fault Alarms

Protection

• ESD Protection:

  • Air Discharge: 8 kV

  • Contact Discharge: 6 kV

• Lightning Protection:

  • Common Mode: 6 kV

Physical Specifications

• Net Weight: 0.2 kg (0.44 lb)

• Gross Weight: 0.76 kg (1.68 lb)

• Product Dimensions:

  • 115 × 84 × 27 mm (4.53" × 3.33" × 1.06")

• Packaging Dimensions:

  • 195 × 114 × 83 mm (7.68" × 4.49" × 3.27")

• Casing Material: Sheet metal

Installation

• Mounting Options: Desktop mount, Wall mount

Packing List

• 1 × Quick Start Guide

• 1 × Legal and Regulatory Information

• 1 × Power Adapter

• 1 × Power Cord

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

10-Port Cloud Managed Desktop Gigabit Switch with 8-Port PoE

Key Features

• 8 × RJ-45 Gigabit PoE ports, 2 × RJ-45 Gigabit uplink ports

• 110 W total PoE budget

  • IEEE 802.3af/at on all PoE ports

  • IEEE 802.3bt support on Ports 1–2 (red ports)

• DIP switch for fast mode switching:

  • Cloud-Managed / Unmanaged Mode

  • PoE Watchdog

  • Long-Distance PoE

• Wide operating temperature: –10 °C to +55 °C

• Supports VLAN, STP, RSTP, and link aggregation

• Web-managed and centralised cloud management via DoLynk App

• Easy configuration with auto network detection and system setup

• Datasheet

Basic Specifications

• Switching Layer: Layer 2

• Switching Capacity: 20 Gbps

• Packet Forwarding Rate: 14.88 Mpps

Port Configuration

• Ports 1–8: 8 × RJ-45 10/100/1000 Mbps (PoE)

• Ports 9–10: 2 × RJ-45 10/100/1000 Mbps (Gigabit uplink)

Environmental Specifications

• Operating Temperature: –10 °C to +55 °C (+14 °F to +131 °F)

• Operating Humidity: 10%–90% RH (non-condensing)

• Storage Temperature: –40 °C to +75 °C (–40 °F to +167 °F)

• Storage Humidity: 5%–95% RH (non-condensing)

Power

• Power Supply: External power adapter, 54 VDC / 2.22 A

• Power Consumption:

  • Idle: 5.7 W

  • Full Load: 115 W

PoE Specifications

• PoE Support: Yes

• PoE Protocols: IEEE 802.3af / IEEE 802.3at / Hi-PoE / IEEE 802.3bt

• PoE Output Power:

  • Ports 1–2: ≤ 90 W per port

  • Ports 3–8: ≤ 30 W per port

  • Total PoE Budget: ≤ 110 W

• PoE Power Management:

  • PoE power consumption management

  • PoE power on/off

  • Automatic PoE shutdown on overload detection

• PoE Pin Assignment:

  • Ports 1–2:

    • V+: 1, 2, 4, 5

    • V–: 3, 6, 7, 8

  • Ports 3–8:

    • V+: 1, 2

    • V–: 3, 6

• Long-Distance PoE: Yes

Hardware Features

DIP Switch Functions

• Managed Mode:

  • ON (default): Local web + cloud management

  • OFF: Unmanaged mode

• PoE Watchdog:

  • Monitors ports 1–8

  • Automatically restarts PoE if no traffic is detected for 2 minutes

  • Only active when Managed Mode is OFF

• Extend Mode:

  • Ports 1–8 support up to 250 m transmission at 10 Mbps

  • Only active when Managed Mode is OFF

• Reset Button: 1

Performance

• MTBF: 2,482,955 hours

• Packet Buffer: 4 Mbit

• Jumbo Frame: 15,360 Bytes

• MAC Address Table: 8K

• Supported VLANs: 32

Network Standards

• IEEE Standards:

  • IEEE 802.3

  • IEEE 802.3u

  • IEEE 802.3x

  • IEEE 802.3ab

  • IEEE 802.3az

  • IEEE 802.3ad

Network Features

• Ethernet Loop Protection: STP, RSTP

• VLAN: IEEE 802.1Q VLAN

• Link Aggregation: Static aggregation

• Port Features:

  • IEEE 802.3x Flow Control

  • Unknown Unicast Suppression

  • Multicast Storm Control

  • Broadcast Storm Control

  • MAC + Port Binding

  • Loop Prevention

• Port Mirroring:

  • Local Port Mirroring

  • N:1 Mirroring

• LLDP Support: Yes

• DHCP: DHCP Client

• Security: Port Isolation

Management

• Management Methods:

  • Web Management

  • Cloud Management

• Monitoring & Maintenance:

  • Logs

  • Fault Alarms

Protection

• ESD Protection:

  • Air Discharge: 8 kV

  • Contact Discharge: 6 kV

• Lightning Protection:

  • Common Mode: 6 kV

  • Differential Mode: 1 kV

Physical Specifications

• Net Weight: 0.36 kg (0.79 lb)

• Gross Weight: 1.13 kg (2.49 lb)

• Product Dimensions:

  • 184.6 × 103.3 × 27 mm (7.27" × 4.07" × 1.06")

• Packaging Dimensions:

  • 252 × 137 × 113 mm (9.92" × 5.39" × 4.45")

• Casing Material: Sheet metal

Installation

• Mounting Options: Desktop mount, Wall mount

Certifications

• CE

Packing List

• 1 × User Manual

• 1 × Legal and Regulatory Information

• 1 × Power Adapter

• 1 × Power Cord

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

20-Port Cloud-Managed Desktop Gigabit Switch with 16-Port PoE

Key Features

• 16 × Gigabit PoE RJ-45 ports, 2 × Gigabit RJ-45 uplink ports, 2 × Gigabit SFP uplink ports

• 190 W total PoE budget

  • IEEE 802.3af/at on all PoE ports

  • Additional IEEE 802.3bt / Hi-PoE support on red ports

• DIP switch for quick enable/disable of:

  • Cloud-Managed Mode

  • PoE Watchdog

  • Long Distance PoE

• Wide operating temperature: –10 °C to +55 °C

• Supports VLAN, STP, RSTP, and Link Aggregation

• Web-managed and centralized cloud management via DoLynk App

• Real-time network monitoring

• Plug-and-play auto detection and easy system setup

• Datasheet

Basic Specifications

Port Configuration

Environmental

Power

Protection

Physical

Certifications

• CE

PoE Specifications

PoE Pin Assignment

• Ports 1–2:

  • 1,2,4,5 (V+) / 3,6,7,8 (V−)

• Ports 3–16:

  • 1,2 (V+) / 3,6 (V−)

Hardware

DIP Switch Functions

• Managed Mode

  • ON (default): Local web + cloud management

  • OFF: Unmanaged mode

• PoE Watchdog

  • Monitors ports 1–16

  • Auto-restarts PoE after 2 minutes of no traffic

  • Only works when Managed Mode is OFF

• Extend Mode

  • Ports 1–16 up to 250 m @ 10 Mbps

  • Only works when Managed Mode is OFF

Performance

Network Features

Management

• Web Management

• Cloud Management

• Logs

• Fault Alarms

Package Contents

• 1 × User Manual

• 1 × Legal & Regulatory Information

• 1 × Power Cord

• 1 × Rack-Mounting Kit

Optional SFP Modules

PoE Transmission Performance

Switch power supply: 54 V | Cable: CAT6, DC resistance < 8 Ω / 100 m

IEEE 802.3bt (90 W)

Hi-PoE (60 W)

IEEE 802.3at (30 W)

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

28-Port Cloud-Managed Desktop Gigabit Switch with 24-Port PoE
