• 8MP 1/2.7'' CMOS image sensor, low luminance, and high-definition image
• Outputs max. 8 MP (3840 x 2160) @ 25/30 fps
• H.265 codec for high compression and ultra-low bit rate
• Built-in multi-core light, max. IR distance: 30 m; max. warm light distance: 30 m
• ROI, SMART H.264+/H.265+, AI H.264/H.265 for flexible coding in various bandwidth and storage environments
• Rotation mode, WDR, 3D NR, HLC, BLC, and digital watermarking for different monitoring scenes
• Intelligent monitoring: Intrusion, tripwire (supports classification and accurate detection of vehicles and humans)
• Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
• Supports max. 512 GB Micro SD card; built-in mic
• 12 VDC/PoE power supply
• IP67 protection
• SMD 4.0
• Supports AI SSA
• SMD area can be configured in warm light areas to trigger alarms

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• 8MP 1/2.7'' CMOS image sensor, low luminance, and high-definition image
• Outputs max. 8 MP (3840 x 2160) @ 25/30 fps
• H.265 codec for high compression and ultra-low bit rate
• Built-in multi-core light, max. IR distance: 30 m; max. warm light distance: 30 m
• ROI, SMART H.264+/H.265+, AI H.264/H.265 for flexible coding in various bandwidth and storage environments
• Rotation mode, WDR, 3D NR, HLC, BLC, and digital watermarking for different monitoring scenes
• Intelligent monitoring: Intrusion, tripwire (supports classification and accurate detection of vehicles and humans)
• Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
• Supports max. 512 GB Micro SD card; built-in mic
• 12 VDC/PoE power supply
• IP67 protection
• SMD 4.0
• Supports AI SSA
• SMD area can be configured in warm light areas to trigger alarms

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• 8MP 1/2.7'' CMOS image sensor, low luminance, and high-definition image
• Outputs max. 8 MP (3840 x 2160) @ 25/30 fps
• H.265 codec, high compression rate, ultra-low bit rate
• Built-in IR LED and warm light, max. IR illumination distance: 30 m; max. warm light distance: 30 m
• ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding for various bandwidth and storage environments
• Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking for diverse monitoring scenarios
• Intelligent monitoring: Intrusion, tripwire (with classification and accurate detection of vehicles and humans)
• Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
• Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card; built-in mic
• 12 VDC/PoE power supply
• IP67 and IK10 protection
• SMD 4.0
• Supports AI SSA
• SMD area can be set in warm light areas that support triggering alarms

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• 8MP 1/2.7'' CMOS image sensor, low luminance, and high-definition image
• Outputs max. 8 MP (3840 x 2160) @ 25/30 fps
• H.265 codec, high compression rate, ultra-low bit rate
• Built-in IR LED and warm light, max. IR illumination distance: 30 m; max. warm light distance: 30 m
• ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding for various bandwidth and storage environments
• Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking for diverse monitoring scenarios
• Intelligent monitoring: Intrusion, tripwire (with classification and accurate detection of vehicles and humans)
• Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
• Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card; built-in mic
• 12 VDC/PoE power supply
• IP67 and IK10 protection
• SMD 4.0
• Supports AI SSA
• SMD area can be set in warm light areas that support triggering alarms

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

8MP Smart Dual Light Vari-focal Bullet WizSense Network Camera

Key Features

• 8 MP 1/2.7" CMOS image sensor with low-luminance performance

• Maximum resolution: 3840 × 2160 at 25/30 fps

• H.265 video compression with ultra-low bit rate

• Built-in multi-core dual light (IR + warm light), illumination distance up to 60 m

• Smart Codec: Smart H.265+ / Smart H.264+

• AI coding: AI H.265 / AI H.264

• SMD 4.0 with human and vehicle classification

• Supports AI SSA (Scene Self-Adaptation)

• Intelligent perimeter protection

• Supports Micro SD card up to 512 GB

• 12 VDC or PoE power supply

• IP67 weather protection

• Datasheet

Camera

• Image sensor: 1/2.7" CMOS

• Scanning system: Progressive

• Maximum resolution: 3840 (H) × 2160 (V)

• ROM: 256 MB

• RAM: 1 GB

• Electronic shutter: Auto / Manual, 1/3 s to 1/100,000 s

• Minimum illumination:

  • 0.007 lux @ F1.4 (Color, 30 IRE)

  • 0.0007 lux @ F1.4 (B/W, 30 IRE)

  • 0 lux (illuminator on)

• S/N ratio: >56 dB

Illumination

• IR illumination distance: up to 60 m

• Warm light illumination distance: up to 60 m

• Illuminator control: Auto / Manual

• Illuminators: 4 × multi-core (IR + warm light)

Lens

• Lens type: Motorized vari-focal

• Lens mount: φ14

• Focal length: 2.7 mm to 13.5 mm

• Maximum aperture: F1.4

• Field of view:

  • Horizontal: 114° to 32°

  • Vertical: 58° to 17°

  • Diagonal: 138° to 36°

• Iris control: Fixed

• Close focus distance: 0.1 m

Angle Adjustment

• Pan: 0° to 360°

• Tilt: 0° to 90°

• Rotation: 0° to 360°

DORI Performance

• Wide end (2.7 mm):

  • Detect: 85.3 m

  • Observe: 34.0 m

  • Recognize: 17.1 m

  • Identify: 8.5 m

• Tele end (13.5 mm):

  • Detect: 280.0 m

  • Observe: 112.0 m

  • Recognize: 56.0 m

  • Identify: 28.0 m

• DORI values are based on EN-62676-4 and do not represent intelligent analytics distances

Intelligence

• Perimeter protection: intrusion and tripwire with human and vehicle classification

• SMD: SMD 4.0

• AcuPick: deep-learning based target search for people and motor vehicles

• AI SSA: automatic image parameter optimisation based on scene conditions

• Smart search: works with Smart NVR for refined intelligent search and event extraction

Video

• Video compression: H.265, H.264, H.264H, H.264B, MJPEG (sub-stream only)

• Smart codec: Smart H.265+, Smart H.264+

• AI coding: AI H.265, AI H.264

• Frame rate:

  • Main stream: 3840 × 2160 at 1–25/30 fps

  • Sub stream: 1920 × 1080 at 1–25/30 fps

  • Third stream: 1920 × 1080 at 1–25/30 fps

• Stream capability: 3 streams

• Supported resolutions: 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 720p, D1, VGA, CIF

• Bit rate control: VBR, CBR, ABR

• Video bit rate:

  • H.264: 3 kbps to 16,384 kbps

  • H.265: 3 kbps to 16,384 kbps

Image Features

• Day/Night mode: Auto (ICR), Color, B/W

• Wide dynamic range: 120 dB

• BLC and HLC supported

• 3D noise reduction

• Electronic image stabilisation (EIS)

• Region of interest: up to 4 areas

• Smart illumination and smart dual light

• Defog supported

• AFSA supported

• Image rotation: 0°, 90°, 180°, 270°

• Mirror mode supported

• Privacy masking: up to 8 areas

Audio

• Built-in microphone

• Audio compression: G.711a, G.711Mu, PCM, G.726, G.723

Alarm & Events

• Alarm input: 1 channel (wet contact, 3–5 VDC)

• Alarm output: 1 channel (wet contact, 12 VDC)

• Event types: motion detection, video tampering, intrusion, tripwire, scene changing, audio detection, defocus detection, voltage detection, SMD events, SD card events, network and security exceptions

Network

• Network port: RJ-45 (10/100 Base-T)

• ONVIF: Profile S, G, T and M

• Supported protocols: IPv4, IPv6, HTTP, TCP, UDP, RTSP, FTP, SFTP, SMTP, DHCP, DNS, DDNS, NTP, SNMP, QoS, UPnP, Multicast, P2P

• Maximum simultaneous users: 20

• SDK and API supported

Storage

• Micro SD card support up to 512 GB

• FTP, SFTP and NAS storage supported

Power

• Power supply: 12 VDC or PoE (802.3af)

• Power consumption:

  • Typical: 3.8 W (12 VDC), 5.3 W (PoE)

  • Maximum: 9.9 W (12 VDC), 12.5 W (PoE)

• Dual power backup supported

Environment

• Operating temperature: –30 °C to +60 °C

• Operating humidity: ≤95% RH (non-condensing)

• Storage temperature: –40 °C to +60 °C

• Storage humidity: ≤95% RH (non-condensing)

• Ingress protection: IP67

Physical

• Casing material: Metal

• Dimensions: 238.5 × 90.7 × 90.7 mm

• Net weight: 835 g

• Gross weight: 1090 g

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• Dahua 8MP Starlight HD-CVI Bullet Camera
• Starlight, 120dB True WDR, 3DNR
• Max. 4K resolution
• HD/SD switchable
• Audio in interface, built-in mic
• 3.7-11mm motorized lens
• Max. IR length 80m, Smart IR
• IP67, AC24V/DC12V±30%
• Specification Click on the PDF Icon :-

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• Dahua 8MP Starlight HD-CVI Turret Camera
• Starlight, 120dB True WDR, 3DNR
• Max. 4K resolution
• HD/SD switchable
• Audio in interface, built-in mic
• 3.7-11mm motorized lens
• Max. IR length 80m, Smart IR
• IP67, AC24V/DC12V±30%
• Specification Click on the PDF Icon :-

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• IPC-HFW3849T1-AS-PV-S3_datasheet_20210713PDF
• Dahua Bullet Network Camera_QSG_V1.0.2PDF
• Bullet Network Camera Installation Guide_V1.0.0PDF
• Dahua Network Camera Web 3.0_OperationManual_V2.1.3

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• IPC-HFW3849T1-AS-PV_datasheet_20220826PDF
• Bullet Network Camera Installation Guide_V1.0.0PDF
• Dahua Bullet Network Camera_Quick Start Guide_V1.0.2PDF
• Dahua Network Camera Web 5.0_Operation Manual_V1.0.5PDF
• Dahua Network Camera Web 3.0_OperationManual_V2.1.5

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• datasheetPDF
• Dahua Eyeball Network Camera_QSG_V1.0.2PDF
• Dahua Network Camera Web 3.0 Operation Manual_V2.1.1PDF
• DH-IPC-HDW3849HP-AS-PV-0280B-S3_DIMENSIONSPDF
• DH-IPC-HDW3849HP-AS-PV-0280B-S3_INSTALLATION_METHOD_EN

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• IPC-HFW3849T1-AS-PV-ANZ_datasheetPDF
• Bullet Network Camera Installation Guide_V1.0.0PDF
• Dahua Bullet Network Camera_Quick Start Guide_V1.0.2PDF
• Dahua Network Camera Web 5.0_Operation Manual_V1.0.5PDF
• Dahua Network Camera Web 3.0_OperationManual_V2.1.5

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• datasheetPDF
• Dahua Eyeball Network Camera_QSG_V1.0.2PDF
• Dahua Network Camera Web 3.0 Operation Manual_V2.1.1PDF
• DH-IPC-HDW3849HP-AS-PV-0280B-S3_DIMENSIONSPDF
• DH-IPC-HDW3849HP-AS-PV-0280B-S3_INSTALLATION_METHOD_EN

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• IPC-HDBW3849R1-ZAS-PV_S0_datasheet_20221207PDF
• Dahua Dome Network Camera_QSG_V1.0.1PDF
• Dome Network Camera Installation Guide_V1.0.0PDF
• Dahua Network Camera Web 5.0_Operation Manual_V1.0.5PDF
• Dahua Network Camera Web 3.0_OperationManual_V2.1.5

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• IPC-HDW3849H-AS-PV_datasheet_20220827PDF
• Dahua Eyeball Network Camera Installation Guide_V1.0.2PDF
• Dahua Eyeball Network Camera_Quick Start Guide_V1.0.4PDF
• Dahua Network Camera Web 5.0_Operation Manual_V1.0.5PDF
• Dahua Network Camera Web 3.0_OperationManual_V2.1.5

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• 5MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
• Outputs max. 5MP (2592 × 1944) @20 fps, and supports 4MP (2688 × 1520) @25/30 fps
• H.265 codec, high compression rate, low bit rate
• Built-in warm illuminator, and the max. illumination distance: 30 m
• ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
• Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
• Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)
• Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
• Supports sound and light alarm linkage. When an alarm is triggered, the camera links sound alarm and light flashing.
• Supports one-tap disarming. You can disarm the events of alarm output, sending email, audio, and light in the configured period.
• Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and spearker
• 12V DC/PoE power supply
• IP67 protection
• SMD Plus
• Red and blue flashlight alarm

•  DH-IPC-HFW3849T1-AS-PV-S3 Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

8MP Smart Dual Light Active Deterrence Fixed-focal Bullet WizSense Network Camera

• Image Sensor and Quality

  • 8-MP 1/2.7" CMOS image sensor for low luminance and high-definition images.
  • Outputs a maximum resolution of 8 MP (3840 × 2160) at 25/30 fps.

• Video Compression and Codec

  • H.265 codec for high compression with ultra-low bit rate.
  • Supports ROI, SMART H.264+/H.265+, and AI-enhanced H.264/H.265 for optimized bandwidth and storage.

• Illumination

  • Built-in warm light and IR LED with up to 30 m illumination range for both.

• Advanced Features

  • Rotation mode, WDR, 3D NR, HLC, BLC, and digital watermarking for flexible monitoring across various scenes.
  • Intelligent monitoring with intrusion and tripwire detection, including human/vehicle classification.

• Abnormality Detection

  • Detects motion, privacy masking, scene changes, and audio anomalies.
  • Monitors SD card issues (missing, full, or error) and network issues (disconnection, IP conflict, illegal access).
  • Includes voltage detection for power-related abnormalities.

• Alarm and Audio Capabilities

  • 1 alarm input and output; 1 audio input and output.
  • Built-in dual microphones and 1-channel speaker for two-way audio communication.

• Storage and Power

  • Supports up to 256 GB Micro SD card.
  • 12 VDC or PoE power supply for flexible installation.

• Protection and Alarms

  • IP67-rated for weather resistance.
  • Equipped with sound and light alarms featuring red and blue lights.

• AI Features and Controls

  • Supports SMD 4.0 for precise motion detection.
  • AI SSA and one-tap arming/disarming functionality.
  • Configurable SMD areas within warm light zones to trigger alarms.
• Datasheet

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

8MP Smart Dual Light Active Deterrence Fixed-focal Bullet WizSense Network Camera

• Image Sensor and Quality

  • 8-MP 1/2.7" CMOS image sensor for low luminance and high-definition images.
  • Outputs a maximum resolution of 8 MP (3840 × 2160) at 25/30 fps.

• Video Compression and Codec

  • H.265 codec for high compression with ultra-low bit rate.
  • Supports ROI, SMART H.264+/H.265+, and AI-enhanced H.264/H.265 for optimized bandwidth and storage.

• Illumination

  • Built-in warm light and IR LED with up to 30 m illumination range for both.

• Advanced Features

  • Rotation mode, WDR, 3D NR, HLC, BLC, and digital watermarking for versatile monitoring.
  • Intelligent monitoring with intrusion and tripwire detection, including human/vehicle classification.

• Abnormality Detection

  • Detects motion, privacy masking, scene changes, and audio anomalies.
  • Monitors SD card issues (missing, full, or error) and network issues (disconnection, IP conflict, illegal access).
  • Includes voltage detection for power-related abnormalities.

• Alarm and Audio Capabilities

  • 1 alarm input and output; 1 audio input and output.
  • Built-in dual microphones and 1-channel speaker for two-way audio communication.

• Storage and Power

  • Supports up to 256 GB Micro SD card.
  • 12 VDC or PoE power supply for flexible installation.

• Protection and Alarms

  • IP67-rated for weather resistance.
  • Equipped with sound and light alarms featuring red and blue lights.

• AI Features and Controls

  • Supports SMD 4.0 for precise motion detection.
  • AI SSA and one-tap arming/disarming functionality.
  • Configurable SMD areas within warm light zones to trigger alarms.
• Datasheet

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

8MP Smart Dual Light Active Deterrence Vari-focal Bullet WizSense Network Camera

• Image Sensor and Quality

  • 8-MP 1/2.8" CMOS image sensor for low luminance and high-definition images.
  • Outputs a maximum resolution of 8 MP (3840 × 2160) at 25/30 fps.

• Video Compression and Codec

  • H.265 codec for high compression with ultra-low bit rate.
  • Supports ROI, SMART H.264+/H.265+, and AI-enhanced H.264/H.265 for optimized bandwidth and storage.

• Illumination

  • Built-in warm light and IR LED with up to 50 m IR range and 40 m warm light range.

• Advanced Features

  • Rotation mode, WDR, 3D NR, HLC, BLC, and digital watermarking for versatile monitoring across various scenes.
  • Intelligent monitoring with intrusion and tripwire detection, including human/vehicle classification.

• Abnormality Detection

  • Detects motion, privacy masking, scene changes, and audio anomalies.
  • Monitors SD card issues (missing, full, or error) and network issues (disconnection, IP conflict, illegal access).
  • Includes voltage detection for power-related abnormalities.

• Alarm and Audio Capabilities

  • 1 alarm input and output; 1 audio input and output.
  • Built-in dual microphone and 1-channel speaker for two-way audio communication.

• Storage and Power

  • Supports up to 512 GB Micro SD card.
  • 12 VDC or PoE power supply for flexible installation.

• Protection and Alarms

  • IP67-rated for weather resistance.
  • Equipped with sound and light alarms featuring red and blue lights.

• AI Features and Controls

  • Supports SMD 4.0 for precise motion detection.
  • AI SSA and one-tap arming/disarming functionality.
  • Configurable SMD areas within warm light zones to trigger alarms.
• Datasheet

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

8MP Smart Dual Light Active Deterrence Vari-focal Dome WizSense Network Camera

• Image Sensor and Quality

  • 8-MP 1/2.8" CMOS image sensor for low luminance and high-definition images.
  • Outputs a maximum resolution of 8 MP (3840 × 2160) at 25/30 fps.

• Video Compression and Codec

  • H.265 codec for high compression with ultra-low bit rate.
  • Supports ROI, SMART H.264+/H.265+, and AI-enhanced H.264/H.265 for optimized bandwidth and storage.

• Illumination

  • Built-in warm light and IR LED with up to 50 m IR range and 40 m warm light range.

• Advanced Features

  • Rotation mode, WDR, 3D NR, HLC, BLC, and digital watermarking for adaptable monitoring across scenarios.
  • Intelligent monitoring with intrusion and tripwire detection, including human/vehicle classification.

• Abnormality Detection

  • Detects motion, privacy masking, scene changes, and audio anomalies.
  • Monitors SD card issues (missing, full, or error) and network issues (disconnection, IP conflict, illegal access).
  • Includes voltage detection for power-related abnormalities.

• Alarm and Audio Capabilities

  • 1 alarm input and output; 1 audio input and output.
  • Built-in dual microphone and 1-channel speaker for two-way audio communication.

• Storage and Power

  • Supports up to 512 GB Micro SD card.
  • 12 VDC or PoE power supply for flexible installation.

• Protection and Alarms

  • IP67-rated for weather resistance and IK10-rated for vandal resistance.
  • Equipped with sound and light alarms featuring red and blue lights.

• AI Features and Controls

  • Supports SMD 4.0 for precise motion detection.
  • AI SSA and one-tap arming/disarming functionality.
  • Configurable SMD areas within warm light zones to trigger alarms.
• Datasheet

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

8MP Smart Dual Light Active Deterrence Network Camera

• Image Sensor and Quality

  • 8-MP 1/1.8" CMOS image sensor for low luminance and high-definition images.
  • Outputs a maximum resolution of 8 MP (3840 × 2160) at 25/30 fps.

• Video Compression and Codec

  • H.265 codec for high compression with ultra-low bit rate.
  • Supports ROI, SMART H.264+/H.265+, and AI-enhanced H.264/H.265 for optimized bandwidth and storage.

• Illumination

  • Built-in multi-core light with up to 30 m IR range and 30 m warm light range.

• Advanced Features

  • Rotation mode, WDR, 3D NR, HLC, BLC, and digital watermarking for adaptable monitoring across various scenes.
  • Intelligent monitoring with intrusion and tripwire detection, including human/vehicle classification.

• Abnormality Detection

  • Detects motion, privacy masking, scene changes, and audio anomalies.
  • Monitors SD card issues (missing, full, or error) and network issues (disconnection, IP conflict, illegal access).
  • Includes voltage detection for power-related abnormalities.

• Alarm and Audio Capabilities

  • 1 alarm input and output; 1 audio input and output.
  • Built-in dual microphone and 1-channel speaker for two-way audio communication.

• Storage and Power

  • Supports up to 512 GB Micro SD card.
  • 12 VDC or PoE power supply for flexible installation.

• Protection and Alarms

  • IP67-rated for weather resistance.
  • Equipped with sound and light alarms featuring red and blue lights.

• AI Features and Controls

  • Supports SMD 4.0 for precise motion detection.
  • AI SSA and one-tap arming/disarming functionality.
  • Configurable SMD areas within warm light zones to trigger alarms.

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

8MP Smart Dual Light Active Deterrence Vari-focal Eyeball WizSense Network Camera

• Image Sensor and Quality

  • 8-MP 1/2.8" CMOS image sensor for low luminance and high-definition images.
  • Outputs a maximum resolution of 8 MP (3840 × 2160) at 25/30 fps.

• Video Compression and Codec

  • H.265 codec for high compression with ultra-low bit rate.
  • Supports ROI, SMART H.264+/H.265+, and AI-enhanced H.264/H.265 for optimized storage and bandwidth.

• Illumination

  • Built-in warm light and IR LED with up to 50 m IR range and 40 m warm light range.

• Advanced Features

  • Rotation mode, WDR, 3D NR, HLC, BLC, and digital watermarking for flexible monitoring across different scenarios.
  • Intelligent monitoring with intrusion and tripwire detection, including human/vehicle classification.

• Abnormality Detection

  • Detects motion, privacy masking, scene changes, and audio anomalies.
  • Monitors SD card issues (missing, full, or error) and network issues (disconnection, IP conflict, illegal access).
  • Includes voltage detection for power-related abnormalities.

• Alarm and Audio Capabilities

  • 1 alarm input and output; 1 audio input and output.
  • Built-in dual microphone and 1-channel speaker for two-way audio communication.

• Storage and Power

  • Supports up to 512 GB Micro SD card.
  • 12 VDC or PoE power supply for installation flexibility.

• Protection and Alarms

  • IP67-rated for weather resistance.
  • Equipped with sound and light alarms featuring red and blue lights.

• AI Features and Controls

  • Supports SMD 4.0 for precise motion detection.
  • AI SSA and one-tap arming/disarming functionality.
  • Configurable SMD areas within warm light zones to trigger alarms.
• Datasheet

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

8MP WizColor TiOC PRO Fixed-focal Bullet WizSense Network Camera

Key Features

• 8 MP 1/1.8" CMOS image sensor with ultra-low illumination

• Maximum resolution: 3840 × 2160 at 25/30 fps

• H.265 / H.264 video compression with Smart Codec (AI H.265 / AI H.264)

• Built-in multi-core dual light (IR + warm light), illumination distance up to 50 m

• Sound and light active deterrence with red and blue warning lights

• SMD 4.0 with human and vehicle classification

• AI SSA (Scene Self-Adaptation)

• One-tap arming and disarming

• Built-in dual microphones and speaker with two-way audio

• Supports Micro SD card up to 512 GB

• IP67 weather protection

• Datasheet

Camera

• Image sensor: 1/1.8" CMOS

• Scanning system: Progressive

• Electronic shutter: Auto / Manual, 1/3 s to 1/100,000 s

• Minimum illumination:

  • 0.0004 lux @ F1.0 (Color, 30 IRE)

  • 0.0002 lux @ F1.0 (B/W, 30 IRE)

  • 0 lux (illuminator on)

• S/N ratio: >56 dB

Illumination

• IR illumination distance: up to 50 m

• Warm light illumination distance: up to 50 m

• Illuminator control: Auto / Manual

• Illuminators: 4 × multi-core (IR + warm light)

Lens

• Lens type: Fixed-focal

• Lens mount: M16

• Focal length options: 2.8 mm, 3.6 mm

• Maximum aperture: F1.0

• Field of view:

  • 2.8 mm: Horizontal 109°, Vertical 59°, Diagonal 131°

  • 3.6 mm: Horizontal 93°, Vertical 50°, Diagonal 111°

• Close focus distance:

  • 2.8 mm: 3.2 m

  • 3.6 mm: 4.4 m

Angle Adjustment

• Pan: 0° to 360°

• Tilt: 0° to 90°

• Rotation: 0° to 360°

DORI Performance

• 2.8 mm lens:

  • Detect: 82.0 m

  • Observe: 32.8 m

  • Recognize: 16.4 m

  • Identify: 8.2 m

• 3.6 mm lens:

  • Detect: 100.0 m

  • Observe: 40.2 m

  • Recognize: 20.0 m

  • Identify: 10.0 m

• DORI values are based on EN-62676-4 and do not represent intelligent analytics distances

Intelligence

• Perimeter protection: intrusion, tripwire, stay detection, loitering detection (human and vehicle classification)

• Face detection (full image): face capture, snapshot optimisation, face enhancement, face angle filtering, multiple snapshot strategies

• SMD: SMD 4.0

• Smart search: works with Smart NVR for refined event search

• AcuPick: deep-learning based target search for people and motor vehicles

• AI SSA: automatic image optimisation based on scene conditions

Video

• Video compression: H.265, H.264, H.264H, H.264B, MJPEG (sub-stream only)

• AI coding: AI H.265, AI H.264, Smart H.265+, Smart H.264+

• Frame rate:

  • Main stream: 3840 × 2160 at 1–25/30 fps

  • Sub stream: 1920 × 1080 at 1–25/30 fps

  • Third stream: 1920 × 1080 at 1–25/30 fps

• Stream capability: 3 streams

• Supported resolutions: 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 720p, D1, VGA, CIF

• Bit rate control: VBR, CBR, ABR

• Video bit rate:

  • H.264: 3 kbps to 16,384 kbps

  • H.265: 3 kbps to 16,384 kbps

Image Features

• Day/Night mode: Auto (ICR), Color, B/W

• Wide dynamic range: 120 dB

• BLC and HLC supported

• 3D noise reduction

• Smart dual light and smart illumination

• Defog supported

• Image rotation: 0°, 90°, 180°, 270°

• Privacy masking: up to 8 areas

• Region of interest: up to 4 areas

• Lens distortion correction supported

Audio

• Built-in dual microphones

• Built-in speaker with maximum sound level of 110 dB at 10 cm

• Two-way audio supported

• Audio compression: PCM, G.711a, G.711Mu, G.726, G.723

Alarm & Events

• Alarm input: 1 channel (wet contact, 3–5 VDC)

• Alarm output: 1 channel (wet contact, 12 VDC)

• Event types: motion detection, video tampering, intrusion, tripwire, stay detection, loitering detection, face detection, audio detection, scene changing, voltage detection, SMD events, SD card events, network and security exceptions

Network

• Network port: RJ-45 (10/100 Base-T)

• ONVIF: Profile S, G, T and M

• Supported protocols: IPv4, IPv6, HTTP, HTTPS, TCP, UDP, RTSP, FTP, SMTP, DHCP, DNS, NTP, SNMP, QoS, UPnP, P2P, Bonjour, Multicast

• Maximum simultaneous users: 20

• SDK and API supported

Storage

• Micro SD card support up to 512 GB

• FTP, SFTP and NAS storage supported

Power

• Power supply: 12 VDC or PoE+ (802.3at)

• Power consumption:

  • Typical: 4.3 W (12 VDC), 6.2 W (PoE)

  • Maximum: 11.8 W (12 VDC), 15.1 W (PoE)

• Dual power backup supported

Environment

• Operating temperature: –40 °C to +60 °C

• Operating humidity: ≤95% RH (non-condensing)

• Ingress protection: IP67

Physical

• Casing material: Metal and plastic

• Dimensions: 288.4 × 94.4 × 84.7 mm

• Net weight: 1.0 kg

• Gross weight: 1.3 kg

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Product Specifications

• Panorama:
  • Outputs 180° wide-angle spliced image

Camera & Optics

• Image Sensor: 1/2.8" 4 Megapixel STARVIS™ CMOS
• Zoom: 10x optical zoom
• Low-light Technology: Starlight technology for enhanced night performance
• Resolution & Frame Rate: Max. 25/30 fps @ 8 MP

Illumination & Range

• IR Distance: Up to 70 m
• Warm Light Illumination: Effective range up to 30 m

Smart Features

• Active Deterrence: Built-in capability for proactive threat response
• Tracking: Auto Tracking Lite for efficient target following
• Perimeter Protection: Advanced detection of boundary breaches
• Face Detection: Identifies and analyzes facial data
• SMD 4.0: Smart Motion Detection for more accurate event filtering

Protection & Durability

• Enclosure Rating: IP66, providing robust weather resistance
• Lighting Modes: Smart dual-light for optimized illumination based on scene conditions



Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• dh-ipc-hdw5442tp-ze datasheetPDF
• dahua eyeball network camera qsgPDF
• eyeball network camera installation guidePDF
• dahua network camera web 3.0 operation manual

Warranty: 3 Year Dahua ANZ Manufacturer Warranty
