•   DH-IPC-HDW3866TP-ZS-AUS Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• DH-IPC-HFW3666EP-AS-AUS Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

DH-IPC-HFW3666TP-ZAS-AUS Dahua 6MP Bullet Motorised Camera

> 6MP 1/2.7'' CMOS image sensor, excellent low luminance performance and high definition of images.
> Outputs max. 6 MP (3072 x 2048) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 60 m.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply, easy for installation.
> IP67 protection.
> SMD 4.0, AI SSA.

• DH-IPC-HFW3666TP-ZAS-AUS Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

DH-IPC-HFW3866EP-AS-AUS-BLK Dahua 8MP (4K) Bullet Fixed Camera

> 8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
> Outputs max. 8MP (3840 x 2160) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 40 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only - ZAS supports); audio: 1 in, 1 out (Only - ZAS supports); max. 256 G Micro SD card; built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67, IK10 protection.
> SMD 4.0, AI SSA.

• DH-IPC-HFW3866EP-AS-AUS-BLK Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

DH-IPC-HFW3866EP-AS-AUS Dahua 8MP (4K) Bullet Fixed Camera

• DH-IPC-HFW3866EP-AS-AUS Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

DH-IPC-HFW3866TP-ZAS-AUS-BLK Dahua 8MP (4K) Bullet Motorised Camera

> 8MP 1/2.8'' CMOS image sensor, excellent low luminance performance and high definition of images.
> Outputs max. 8MP (3840 x 2160) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 40 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only - ZAS supports); audio: 1 in, 1 out (Only - ZAS supports); max. 256 G Micro SD card; built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67, IK10 protection.
> SMD 4.0, AI SSA.

• DH-IPC-HFW3866TP-ZAS-AUS-BLK Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

DH-IPC-HFW3866TP-ZAS-AUS Dahua 8MP (4K) Bullet Motorised Camera

> 8MP 1/2.7'' CMOS image sensor, excellent low luminance performance and high definition of images.
> Outputs max. 6 MP (3072 x 2048) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 60 m.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply, easy for installation.
> IP67 protection.
> SMD 4.0, AI SSA.

• DH-IPC-HFW3866TP-ZAS-AUS Specification  :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

DH-XVR5104HS-4KL-X Dahua 4K HD-CVI 4CH DVR

• 4K HD-CVI 4CH DVR
• 1TB HDD installed
•  H.265+/H.265 dual-stream video compression
• Supports HDCVI/AHD/TVI/CVBS/IP video inputs
• Max 6 channels IP camera inputs, each channel up to 8MP
• Max 24Mbps Incoming Bandwidth
• Smart Search and Intelligent Video System
• Product Specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

ARA14-W2
Wireless Intercom Siren

• Two-way talk via RF transmission.
• High-decibel alarm sound for effective alerts.
• Multiple alarm sounds: Fire, medical, intrusion, panic, and more.
• Configurable arming/disarming prompt sound and LED indicator.
• Supports panic button for emergency situations.
• Voice talk support through the app and SIP.

Specifications

Port

• Microphone: Yes

Video & Audio

• Two-way Audio: Yes

Function

• Button: 1 × panic button, 1 × power button
• Buzzer: Yes
• Remote Update: Cloud update
• Low Battery Detection: Yes
• Tamper: Yes

Technical

• LED Indicator: Red, blue, and green indicators
• Scenario: Indoor
• Operating Current:
  • Battery (3V): 1.5 A (Max), 20 µA (Standby)
  • DC (12V): 0.4 A (Max), 1.5 mA (Standby)
• Sound and Light Alarm: Yes

Wireless

• Carrier Frequency: 433.1 MHz–434.6 MHz
• Communication Mechanism: Two-way
• Communication Distance:
  • Alarm transmission: 1200 m
  • Intercom: 800 m
• Encryption Mode: AES128
• Frequency Hopping: Yes

General

• Power Supply: 12 VDC / 4 × CR123A battery
• Battery Model: CR123A
• Standby Time: 3 years (triggered once every 2 weeks, alarms for 120 sec)
• Power Consumption: 4.5 W (Max), 0.4 mW (Standby)
• Operating Temperature: -10 °C to +55 °C (+14 °F to +131 °F) (indoor)
• Operating Humidity: 10%–90% RH
• Product Dimensions: 133.0 mm × 133.0 mm × 35.5 mm (5.24" × 5.24" × 1.40")
• Net Weight: 377 g (0.83 lb)
• Gross Weight: 507 g (1.12 lb)
• Installation: Wall mount
• Casing Material: PC + ABS
• Appearance Color: White
• Certifications: CE
• Anti-corrosion Level: Basic Protection
• Storage Temperature: -10 °C to +55 °C (+14 °F to +131 °F)
• Storage Humidity: 10%–90% RH
• Packaging Dimensions: 170 mm × 166 mm × 55 mm (6.69" × 6.54" × 2.71")

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Wireless keyfob

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Wireless keyfob

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

ARA43-W2

Alarm Repeater

• Connects up to 32 peripherals for expanded coverage.
• Two-way RF communication ensures reliable signal transmission.
• LED indicator displays device status.
• Supports manual and auto pairing, extending RF distance for your security system.
• Auto-switching dual antennas reduce blind spots.
• Cloud update with auto recovery in case of update failure.
• Built-in battery backup keeps the device running for over 35 hours during power failures.

Specifications

Input/Output

• Wireless Zone: Supports up to 32 wireless peripherals

Port

• Storage Battery: Built-in lithium battery
• Indicator Light: 1 LED for pairing and working status
• Power Switch: 1 × power switch

Function

• Pairing Mode: Auto / Manual
• Tamper Alarm: Yes
• Remote Update: Cloud update
• Power Failure Protection: Retains configured parameters
• External Power Disconnection Detection: Yes
• Low Battery Alarm: Yes
• Signal Strength Detection: Yes

Wireless

• Carrier Frequency: 433.1 MHz–434.6 MHz
• Transmitter Power (EIRP): Limit 10 mW
• Communication Distance: Up to 1000 m (3280.84 ft) in open space
• Communication Mechanism: Two-way
• Encryption Mode: AES128
• Frequency Hopping: Yes

General

• Power Supply: 12 VDC, 1.5 A
• Battery Life: Standby time: 35 hours
• Operating Temperature: –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
• Operating Humidity: 10%–90% RH
• Product Dimensions: 163.0 mm × 163.0 mm × 32.0 mm (6.42" × 6.42" × 1.26")
• Packaging Dimensions: 219.0 mm × 187.0 mm × 91.0 mm (8.62" × 7.36" × 3.58")
• Installation: Wall mount / Desktop
• Net Weight: 0.32 kg (0.71 lb)
• Gross Weight: 0.74 kg (1.63 lb)
• Certifications: CE
• Casing Material: PC + ABS

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

ARC3800H-FW2

Dahua Wireless Alarm Hub 2

• Supports alarm video verification through IPC integration with the hub.
• Quick image transfer from the PIR-Cam to the device for remote monitoring.
• Voice call alarm feature for enhanced security notifications.
• Flexible network configuration: Supports wired and AP modes for easy app integration and network switching.
• Multi-network redundancy: Ensures a stable connection with Ethernet, Wi-Fi, and 4G support.
• Reliable two-way communication with frequency hopping for stable wireless peripheral connections.
• Cloud update support: Remotely update the device and peripherals via the mobile app.
• Dual backup system with auto recovery in case of update failure.

Specifications

Port

• Wireless Zone: Supports up to 150 wireless peripherals
  • 6 sirens
  • 64 PIR cameras (only 8 indoor PIR cameras)
  • 64 keyfobs
  • 8 keypads
  • 4 repeaters
• Network Mode: Ethernet, Wi-Fi, and Cellular (dual SIM support, one active at a time)
• Network Port: 1 × RJ-45, 10/100 Mbps Ethernet
• Storage Battery: Built-in 4,750 mAh rechargeable lithium battery

Video & Audio

• Video Input: 8-channel IPC (supports only alarm video uploads)
• Audio Output: 1 channel
• Volume Control: Yes
• Voice Broadcast: Supports telephone and local speaker

Function

• Indicator Light: Displays status for alarms, arming/disarming, network connection, and device failure
• Buttons: Reset button, voltage button, AP switch button
• SMS & Phone Call: Supports up to 5 phone numbers
• Video Linkage: Yes
• Offline Cache: Stores up to 50 alarm messages
• Arm & Disarm Methods: App, keyboard, remote control, card, scheduled arming/disarming
• Remote Update: Cloud update support
• Low Battery Detection: Yes
• Tamper Protection: Yes
• User Management:
  • 33 app users (31 general users, 1 admin, 1 installer)
  • 32 keypad users
• Logs Storage: Up to 5,000 entries
• Transmission Protocol: SIA, SoftGuard

Wireless

• Carrier Frequency: 433.1–434.6 MHz
• Transmitter Power (EIRP): Max 10 mW
• Communication Mechanism: Two-way
• Communication Distance: Up to 1,400 m (4593.18 ft) in open space
• Encryption Mode: AES128
• Frequency Hopping: Yes

General

• Supported Languages:
  • SMS: English, Spanish (Latin America), French, Italian, Arabic, Turkish, Danish (English is the default)
  • Alarm voice message & local speaker: English only
• Power Supply: 100–240 VAC, 50/60 Hz
• Standby Time: Up to 12 hours (when fully charged, connected to Wi-Fi, linked to alarm center, heartbeat interval of 1,800 sec, and connected to 8 peripherals & cloud)
• Power Consumption:
  • Max: 220 VAC 80 mA
  • Standby: 220 VAC 40 mA
• Operating Temperature:
  • Without battery charging: –10 °C to +55 °C (+14 °F to +131 °F)
  • With battery charging: 0 °C to +45 °C (+32°F to +113 °F)
• Operating Humidity: 10%–90% RH
• Product Dimensions: 174.8 × 174.8 × 38.3 mm (6.88" × 6.88" × 1.51")
• Net Weight: 510 g (1.12 lb)
• Gross Weight: 860 g (1.90 lb)
• Installation: Supports wall mount & desktop mount
• Casing Material: PC + ABS
• Certifications: CE
• Anti-Corrosion Level: Basic Protection
• Storage Temperature: –10 °C to +55 °C (+14 °F to +131 °F)
• Storage Humidity: 10%–90% RH
• Packaging Dimensions:
  • Inner Box: 254 × 211 × 61 mm (10.00" × 8.31" × 2.40")
  • Protective Case: 524 × 508 × 442 mm (20.63" × 20.00" × 17.40")

Wi-Fi

• Standard: IEEE 802.11b/g/n
• Frequency Range: 2400–2483.5 MHz
• Power Transmission: ≤20 dBm@2400-2483.5 MHz

Cellular Network

• Transmitter Power (EIRP):

  • EU:
    • 4G: Power class3: 23 dBm ±2 dB
    • 3G: Power class3: 24 dBm +1/-3 dB
    • 2G: Power class0: 30 dBm ±3 dB (GSM900)
    • 2G: Power class5: 33 dBm ±3 dB (GSM1800)
  • LM:
    • 4G: Power class3: 23 dBm ±2 dB
    • 3G: Power class3: 24 dBm +1/-3 dB
    • 2G: Power class0: 30 dBm ±3 dB (GSM850/900)
    • 2G: Power class5: 33 dBm ±3 dB (GSM1800/1900)

• Network Standard: GSM / WCDMA / LTE

• Frequency Range:

  • EU:
    • 4G:
      • FDD-LTE: B1/B3/B7/B8/B20/B28A
      • TDD-LTE: B38/B40/B41
    • 3G:
      • WCDMA: B1/B8
    • 2G:
      • GSM: 1800/900 MHz
  • LM:
    • 4G:
      • FDD-LTE: B1/B2/B3/B4/B5/B7/B8/B28
      • TDD-LTE: B40
    • 3G:
      • WCDMA: B1/B2/B4/B5/B8
    • 2G:
      • GSM: 850/900/1800/1900 MHz

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Features

• Anti-Masking Detection: Prevents blocking or covering of the sensor
• Moving Detection: Detects attempts to move or detach the device
• PIR-Cam Compatibility: Supports the installation of camera modules for video verification
• Pet Immunity: Up to 80 cm, 40 kg
• Temperature Monitoring: Monitors environmental temperature
• Stable Communication: Two-way communication & frequency hopping for reliable connectivity with alarm hub
• Cloud Update: Supports remote updates via the mobile app
• Dual Backup System: Auto recovery in case of update failure

Specifications

Function

• Indicator Light: 1 × Green alarm indicator
• Buttons:
  • 1 × Power switch
  • 1 × Detection range adjustment switch
• Remote Update: Cloud update support
• Low Battery Detection: Yes
• Tamper Protection: Tamper alarm
• Moving Detection: Yes

Technical

• Detection Mode: PIR + Microwave
• Sensitivity: PIR - 3 adjustable levels
• Detection Range:
  • Angle: 90°
  • Range: 15 m (49.21 ft) (installation height: 1 m / 3.28 ft)
• Detection Speed: 0.3 m/s – 2 m/s
• Microwave Frequency: 24 GHz
• Pet Immunity: <80 cm (2.62 ft), about 40 kg (88.19 lb)
• White Light Resistance: 10,000 lux
• Anti-Masking: Yes
• Two-Way Digital Temperature Compensation: Yes

Scenario

• Usage: Outdoor, indoor
• Operating Current: 20 uA
• Alarm Current:
  • Without Camera: 26mA (Avg); 250mA (Max)
  • With Camera (Night Mode): 380mA (Avg); 1.5A (Max)

Wireless

• Carrier Frequency: 433.1 MHz–434.6 MHz
• Transmitter Power (EIRP): Limit 10 mW
• Communication Mechanism: Two-way
• Communication Distance:
  • RF: Up to 1,200 m (3,937.01 ft) in open space
• Encryption Mode: AES128
• Frequency Hopping: Yes

General

• Power Supply: 4 × CR123A batteries
• Battery Life:
  • Without Camera: 5 years (triggers 10 alarms/day)
  • With Camera: 3.5 years (triggers alarms twice/week)
• Operating Temperature: –25 °C to +60 °C (–13 °F to +140 °F)
• Operating Humidity: 10%–90% (RH)
• Product Dimensions: 211 mm × 106 mm × 94 mm (8.31" × 4.17" × 3.7")
• Installation Height: 0.8 – 1.3 m
• Net Weight: 651 g (1.44 lb)
• Gross Weight: 890 g (1.96 lb)
• Installation Options: Wall mount, pole mount
• Casing Material: PC + GF

Protection & Certifications

• IP Rating: IP66
• Certifications: CE
• Anti-Corrosion Level: Basic Protection

Storage & Packaging

• Storage Temperature: –25 °C to +60 °C (–13 °F to +140 °F)
• Packaging Dimensions: 251 mm × 116 mm × 119 mm (9.88" × 4.57" × 4.69”)

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

ARD2251E-W2(V) – Dahua Wireless External PIR-Camera
(Compatible only with ARC3800H series)

• Anti-Masking Detection – Prevents tampering attempts.
• Motion Detection – Alerts if the device is moved or detached.
• Video Verification – Captures visual evidence of events.
• IR Night Vision – 15m illumination range.
• Pet Immunity – Ignores pets up to 80 cm tall and 40 kg.
• Temperature Monitoring – Tracks environmental conditions.
• Stable Communication – Two-way communication with frequency hopping for reliability.
• Cloud Updates – Remotely update the device via mobile app.
• Dual Backup System – Auto-recovery ensures updates never fail.
• Compatibility – Works only with ARC3800H series (Not compatible with ARC3000H or ARA43 series).

Specifications

Video & Audio

• Field of View: 110° (H), 60° (V)
• Image Type: JPEG
• Resolution: 1280 × 960, 640 × 480, 320 × 240, 160 × 120
• Frame Rate: 2 FPS
• Illumination Mode: Infrared Light
• Day/Night Switch: Color / Black & White

Functionality

• Indicator Light: 1 × Green alarm indicator
• Buttons:
  • 1 × Power switch
  • 1 × Detection range adjustment switch
• Remote Update: Cloud update
• Low Battery Detection: Yes
• Tamper Protection: Tamper alarm
• Motion Detection: Yes

Technical Specifications

• Detection Mode: PIR + Microwave
• Sensitivity: PIR – 3 levels adjustable
• Detection Range:
  • Angle: 90°
  • Range: 15 m (49.21 ft) at 1 m (3.28 ft) installation height
• Detection Speed: 0.3 m/s – 2 m/s
• Microwave Frequency: 24 GHz
• Pet Immunity Level: <80 cm (2.62 ft), approx. 40 kg (88.19 lb)
• White Light Resistance Level: 10,000 lux
• Anti-Masking: Yes
• Two-Way Digital Temperature Compensation: Yes

Installation & Power

• Scenario: Outdoor, indoor
• Operating Current: 20 µA
• Alarm Current:
  • Without Camera: Avg. 26 mA, Max 250 mA
  • With Camera (Night): Avg. 380 mA, Max 1.5 A
• Power Supply: CR123A × 4
• Battery Life:
  • Without Camera: Up to 5 years (10 alarms/day)
  • With Camera: Up to 3.5 years (2 alarms/week)
• Operating Temperature: –25 °C to +60 °C (–13 °F to +140 °F)
• Operating Humidity: 10%–90% RH
• Installation Height: 0.8 m–1.3 m (2.62 ft–4.27 ft)
• Installation Options: Wall mount, pole mount

Wireless Communication

• Carrier Frequency: 433.1 MHz–434.6 MHz
• Transmitter Power (EIRP): Max 10 mW
• Communication Mechanism: Two-way
• Communication Distance:
  • RF: Up to 1,200 m (3,937.01 ft) in open space
  • RF-HD: Up to 1,000 m (3,280.84 ft) in open space
• Encryption Mode: AES128
• Frequency Hopping: Yes

Physical & Protection

• Product Dimensions: 263 mm × 106 mm × 94 mm (10.35" × 4.17" × 3.70")
• Net Weight: 0.76 kg (1.68 lb)
• Gross Weight: 1.06 kg (2.34 lb)
• Casing Material: PC + GF
• Protection Level: IP66
• Certifications: CE
• Anti-Corrosion Level: Basic Protection
• Storage Temperature: –25 °C to +60 °C (–13 °F to +140 °F)
• Storage Humidity: 10%–90% RH
• Packaging Dimensions: 297 mm × 146 mm × 120 mm (11.69" × 5.75" × 4.72")

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

ARD323-W2(S) Wireless Door Detector

• Signal Strength Detection
• Low Battery Alarm
• Temperature Measurement
• Frequency Hopping & Two-Way Communication – Ensures stable communication.
• Cloud Update & Auto-Recovery – Prevents update failures.


Specifications

Port & Indicators

• Indicator Light: 1 × Green Alarm Indicator
• Button: 1 × Power Button

Functions

• Tamper Alarm: Yes
• Remote Upgrade: Cloud Update
• Low Battery Alarm: Yes
• Test Mode: Yes
• Signal Strength Detection: Yes

Wireless Communication

• Carrier Frequency: 433.1 MHz–434.6 MHz
• Communication Distance: Up to 1,000 m (3,280.84 ft) in open space
• Communication Mechanism: Two-way
• Frequency Hopping: Yes
• Encryption Mode: AES128

Power & Consumption

• Power Supply: CR123A Battery
• Power Consumption: Max. 70 mW

Environmental Conditions

• Operating Temperature: –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
• Operating Humidity: 10%–90% (RH)

Physical Dimensions & Weight

• Product Dimensions: 100.2mm × 20.8mm × 20.3mm (3.94” × 0.82” × 0.80”) (L × W × H)
• Packaging Dimensions: 135.0mm × 98.5mm × 27.8mm (5.31" × 3.88" × 1.09") (L × W × H)
• Installation: Bracket Mount
• Net Weight: 70 g (0.15 lb)
• Gross Weight: 115 g (0.25 lb)

Certifications & Battery Life

• Certifications: CE
• Battery Life:
  • 4 years (External input type: NO)
  • 2 years (External input type: NC or Pulse)

Casing Material

• Material: PC + ABS

Temperature Measurement

• Measuring Range: –15 °C to +65 °C (+5 °F to +149 °F) (indoor)
• Precision: ±1 °C (±1.8 °F)
• Resolution: 1 °C (33.8 °F)

Detection & Installation

• Sensor: Reed Switch
• Recommended Scenario: Non-metal doors
• Movement Distance: < 40 mm (1.57")

Peripherals

• External Zone: 1-channel dry contact input

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Key Features:

• Glass Break Detection:
  Accurately detects broken glass and triggers alarms for various types of glass, including:
  Tempered, Double-Glazed, Laminated, Wired, Plate, and Float Glass

• Dual-Frequency Sound Detection:
  Identifies both high and low frequency sound waves simultaneously, reducing false alarms through intelligent algorithms

• Alarm Inputs:
  Two-channel alarm input for enhanced flexibility

• Cloud Update Support:
  Enables remote firmware updates with automatic recovery in case of update failure

• Secure Communication:
  Uses two-way wireless encrypted communication to ensure data security and communication stability

• Frequency Hopping Technology:
  Automatically switches to alternative frequency bands in the event of interference, ensuring uninterrupted and stable communication

• Datasheet

Ports

• Alarm Input: 2 inputs (NO/NC)

• Microphone: Highly-sensitive omnidirectional microphone

Functions

• Power Button: 1 × power button

• Remote Update: Cloud update

• Low Battery Detection: Yes

• Tamper Detection: Yes

• Test Mode: Yes

• LED Indicator: 1 × green alarm indicator

Glass Detection Specifications

• Detection Range: Up to 9 m (29.53 ft)

• Supported Glass Types: Tempered, Double-Glazed, Laminated, Wired, Plate, Float

• Glass Thickness: 2.4 mm – 6.4 mm (0.09" – 0.25")

• Glass Size: 0.3 × 0.3 m to 3 × 3 m (0.98 × 0.98 ft to 9.84 × 9.84 ft)

Technical

• Scenario: Indoor

• Operating Current: 45 μA

• Alarm Current: 50 mA

Wireless

• Carrier Frequency: 433.1 MHz – 434.6 MHz

• Communication Mechanism: Two-way

• Communication Distance: Up to 1,200 m (3,937.01 ft) in open space

• Encryption Mode: AES128

• Frequency Hopping: Yes

Power

• Power Supply: 1 × CR123A battery

• Battery Model: CR123A

• Battery Life:

  • Up to 3 years (external input type: NO)

  • Up to 1 year (both external sensors enabled, input type: NC)

• Power Consumption: Max. 150 mW

Environmental

• Operating Temperature: –10 °C to +55 °C (+14 °F to +131 °F), indoor

• Operating Humidity: 10% – 90% RH

• Anti-Corrosion Level: Basic protection

Physical

• Product Dimensions: 107.8 × 34.5 × 24.8 mm (4.24" × 1.36" × 0.98")

• Packaging Dimensions: 95 × 43 × 139 mm (3.74" × 1.69" × 5.47")

• Net Weight: 45 g (0.10 lb)

• Gross Weight: 130 g (0.29 lb)

• Installation Method: Surface mount

• Casing Material: PC and ABS

• Color: White

Certifications

• CE Certified

Warranty: 3 Year Dahua ANZ Manufacturer Warranty
