DH-PFS3005-4ET-60 Dahua 4 Port POE Switch (unmanaged)

•  Layer two commercial switch
• Supports PoE power management

• Supports wall-mount installation

• Supports anti-theft lock hole

• MAC auto learning and aging, MAC address capacity is 1K

• Supports IEEE802.3, IEEE802.3u and IEEE802.3X standards

• RJ45 port supports 10/100Mbps self-adaptation

• Supports 250 meters long distance PoE transmission
• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• Dahua 4K HD-CVI 16CH DVR
• 3TB HDD installed
• H.265+/H.265 dual-stream video compression
• Supports HDCVI/AHD/TVI/CVBS/IP video inputs
• Max 12/24 channels IP camera inputs, each channel up to 8MP
• Max 48/96Mbps Incoming Bandwidth
• Smart Search and Intelligent Video System

• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• Dahua 4K HD-CVI 16CH DVR
• 3TB HDD installed
• H.265+/H.265 dual-stream video compression
• Supports HDCVI/AHD/TVI/CVBS/IP video inputs
• Max 16 channels IP camera inputs, each channel up to 8MP
• Max 64Mbps Incoming Bandwidth
• Smart Search and Intelligent Video System

• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• Dahua 4K HD-CVI 32CH DVR
• 3TB HDD installed
• H.265+/H.265 dual-stream video compression
• Supports HDCVI/AHD/TVI/CVBS/IP video inputs
• Max 32 channels IP camera inputs, each channel up to 8MP
• Max 128Mbps Incoming Bandwidth
• Smart Search and Intelligent Video System

• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

DH-XVR5108H-4KL-X Dahua 4K HD-CVI 8CH DVR

• Dahua 4K HD-CVI 8CH DVR
• 2TB HDD installed
• H.265+/H.265 dual-stream video compression
• Supports HDCVI/AHD/TVI/CVBS/IP video inputs
• Max 12 channels IP camera inputs, each channel up to 8MP
• Max 48Mbps Incoming Bandwidth
• Smart Search and Intelligent Video System

• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

4MP 4× Starlight IR WizSense Network PTZ Camera

Key Features

• 1/2.8" 4 MP CMOS image sensor

• 4× optical zoom

• Starlight low-light technology

• Max. 25/30 fps @ 4 MP

• IR illumination up to 20 m

• Perimeter protection (IVS)

• Face detection

• SMD 3.0

• Built-in microphone

• IP66 weatherproof, IK08 vandal-resistant

• Datasheet

Camera

Image Sensor

• Sensor Type: 1/2.8" CMOS

• Effective Pixels: 4 MP

• Max. Resolution: 2560 (H) × 1440 (V)

• Scanning System: Progressive

• Electronic Shutter: 1 s–1/30,000 s

• ROM: 256 MB

• RAM: 512 MB

Minimum Illumination

• Color: 0.005 lux @ F1.8 (30 IRE)

• B/W: 0.0005 lux @ F1.8 (30 IRE)

• 0 lux (IR on)

Illumination

• IR Distance: Up to 20 m (65.62 ft)

• IR LEDs: 3

• IR Control: Manual / SmartIR / Off

Lens

• Focal Length: 2.8 mm–12 mm

• Optical Zoom: 4×

• Max. Aperture: F1.8–F2.7

• Field of View:

  • Horizontal: 96.9°–31.6°

  • Vertical: 51.4°–17.8°

  • Diagonal: 116.2°–36.4°

• Focus Control: Auto / Semi-auto / Manual

• Close Focus Distance: 0.2 m–0.5 m

• Iris Control: Fixed

DORI Performance (EN-62676-4)

• Detect: 240 m (787.40 ft)

• Observe: 94.8 m (311.02 ft)

• Recognize: 48 m (157.48 ft)

• Identify: 24 m (78.74 ft)

DORI values do not represent intelligent function distances.

PTZ

• Pan Range: 0°–355°

• Tilt Range: 5°–90°

Speed

• Manual Pan: 0.1°/s–70°/s

• Manual Tilt: 0.1°/s–30°/s

• Preset Pan: 0.1°/s–80°/s

• Preset Tilt: 0.1°/s–40°/s

Functions

• Presets: 300

• Tours: 8 (up to 32 presets per tour)

• Power-off Memory: Yes

• Idle Motion: Preset / Tour

• PTZ Protocol: DH-SD

• PTZ Lock: Yes

Intelligent Functions

IVS (Perimeter Protection)

• Tripwire

• Intrusion

• Crossing fence

• Loitering detection

• Abandoned/missing object

• Fast moving

• Parking detection

• People gathering

• Human classification

Face Detection

• Face detection, snapshot, enhancement

• Face cutout: Face / one-inch photo

• Capture modes: Real-time / Quality priority

People Counting

• Line crossing counting

• Area counting

• Queue management

• Reporting supported for line crossing only

SMD

• SMD 3.0 supported

Video

Compression

• H.264H / H.264B / H.264

• H.265

• Smart H.264+ / Smart H.265+

• MJPEG (sub-stream)

Streaming

• Triple stream

Resolution

• 4M (2560 × 1440)

• 3M (2304 × 1296)

• 1080p, 1.3M, 720p

• D1, VGA, CIF

Frame Rate

• Main Stream: up to 25/30 fps

• Sub Stream 1: D1/VGA/CIF @ 25/30 fps

• Sub Stream 2: 720p @ 25/30 fps

Bit Rate

• Control: CBR / VBR

• H.264: 96 Kbps–14,848 Kbps

• H.265: 38 Kbps–8,960 Kbps

Image Processing

• Day/Night: ICR / Electronic (Color / B/W / Auto)

• WDR: 120 dB

• BLC / HLC: Supported

• White Balance: Auto, Indoor, Outdoor, Tracking, Manual, Sodium Lamp, Natural Light, Street Lamp

• Gain Control: Auto / Manual / Gain Priority

• Noise Reduction: 2D NR / 3D NR

• Motion Detection: Yes

• ROI: Yes

• EIS: Supported

• Defog: Electronic

• Digital Zoom: 16×

• Image Rotation: 180°

• S/N Ratio: ≥55 dB

• Privacy Masking: Up to 24 areas (8 per view, 8 colors)

Audio

• Compression: PCM, G.711A/U, G.726, MPEG-2 Layer II, G.722.1

• Audio I/O: 1 in / 1 out

• Built-in Mic: Yes (shared with audio input)

Network

• Ethernet: RJ-45 (10/100 Base-T)

• Protocols: IPv4/IPv6, TCP/IP, HTTP/HTTPS, RTSP, RTP, FTP, NTP, SNMP, QoS, DHCP, DDNS, ONVIF, and more

• Interoperability: ONVIF (Profile S/G/T), CGI, SDK

• Max Users: 20 (64 Mbps total bandwidth)

Storage

• Micro SD Card: Up to 512 GB

• Network Storage: FTP / SFTP / NAS

Software & Compatibility

• Web Browsers: IE9+, Chrome 41+, Firefox 52+, Safari 10+

• Management Software: DMSS, DSS Pro

• Mobile App: iOS / Android

Alarm & Events

• Alarm Actions: Snapshot, recording, email, preset, tour

• Events: Motion, tampering, audio detection, network disconnection, IP conflict, SD card status

Power

• Power Supply: 12 VDC ±10%, 2 A

• PoE: IEEE 802.3af

• Power Consumption:

  • Typical: 4 W

  • Max: 13 W (IR on)

Environment

• Operating Temperature: –30 °C to +60 °C

• Operating Humidity: ≤95%

• Protection: IP66, IK08, TVS 6000 V lightning protection, surge & transient protection

Physical

• Dimensions: 65.7 mm × Ø128.0 mm

• Net Weight: 0.5 kg

• Gross Weight: 0.7 kg

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• DH-SD3E405DB-GNY-A-PV1 :

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

4MP IR Fixed-focal Wi-Fi Bullet Network Camera

Overview

• 4 MP 1/3" CMOS image sensor with low luminance and high-definition imaging

• Maximum output: 4 MP (2560 × 1440) @ 20 fps

• Also supports: 3 MP (2304 × 1296) @ 25/30 fps

• H.265 video compression with high compression ratio and ultra-low bitrate

• Built-in IR LED for night visibility

• Smart encoding: Smart H.264+ / Smart H.265+

• Image features: DWDR, 3D NR, BLC, digital watermarking

• Abnormality detection: motion, video tampering, audio detection, SD card exceptions, network exceptions, illegal access

• Built-in 2.4 GHz Wi-Fi antenna, up to 80 m wireless range in open area (environment dependent)

• Supports Micro SD card up to 256 GB (sold separately)

• Built-in microphone

• Power via 12 VDC

• IP67 weather protection

• Datasheet

Camera

• Image Sensor: 1/3" CMOS

• Max. Resolution: 2560 (H) × 1440 (V)

• Scanning System: Progressive

• Electronic Shutter Speed: Auto/Manual, 1/3 s – 1/100,000 s

• Min. Illumination:

  • 0.03 lux @ F2.0 (Color, 30 IRE)

  • 0.003 lux @ F2.0 (B/W, 30 IRE)

  • 0 lux (Illuminator on)

• S/N Ratio: > 56 dB

• ROM: 16 MB

• RAM: 64 MB

IR Illumination

• IR Distance: Up to 30 m (98.43 ft)

• IR Control: Auto / Manual

• IR LED Quantity: 1

Angle Adjustment

• Pan: 0° – 360°

• Tilt: 0° – 90°

• Rotation: 0° – 360°

Lens

• Lens Type: Fixed-focal

• Lens Mount: M12

• Focal Length Options: 2.8 mm, 3.6 mm

• Max. Aperture: F2.0

• Iris Control: Fixed

Field of View

• 2.8 mm: Horizontal 90°, Vertical 50°, Diagonal 107°

• 3.6 mm: Horizontal 76°, Vertical 40°, Diagonal 92°

Close Focus Distance

• 2.8 mm: 1.0 m (3.28 ft)

• 3.6 mm: 1.4 m (4.59 ft)

DORI Performance

• 2.8 mm:

  • Detect: 68 m (223.10 ft)

  • Observe: 27.2 m (89.24 ft)

  • Recognize: 13.6 m (44.62 ft)

  • Identify: 6.8 m (22.31 ft)

• 3.6 mm:

  • Detect: 85.2 m (279.53 ft)

  • Observe: 34.1 m (111.88 ft)

  • Recognize: 17.0 m (55.77 ft)

  • Identify: 8.5 m (27.89 ft)

Video

• Video Compression: H.265, H.264H, H.264, H.264B

• Smart Codec: Smart H.265+, Smart H.264+

• Video Frame Rate:

  • Main Stream: 2560 × 1440 @ 1–20 fps

  • Sub Stream: 640 × 480 @ 1–25 fps / 1–30 fps

• Stream Capability: 2 streams

• Supported Resolutions: 2560 × 1440, 2304 × 1296, 1080p, 1.3M, 720p

• Bit Rate Control: CBR / VBR

• Video Bit Rate:

  • H.264: 24 kbps – 4096 kbps

  • H.265: 9 kbps – 4096 kbps


• Day/Night Mode: Auto (ICR) / Color / B/W

• WDR: DWDR

• BLC: Supported

• White Balance: Auto, natural, street lamp, outdoor, manual, regional custom

• Gain Control: Auto

• Noise Reduction: 3D NR

• Motion Detection: On/Off (4 rectangular areas)

• Region of Interest: 4 configurable areas

• Smart Illumination: Yes

• Image Rotation: 0° / 180°

• Mirror: Supported

Audio

• Built-in Microphone: Yes

Alarm

• Alarm Events: No SD card, SD card full/error, network disconnection, IP conflict, illegal access, motion detection, video tampering, audio detection, intensity change

Network & Wi-Fi

• Network Port: RJ-45 (10/100 Base-T)

• Wi-Fi Standard: IEEE 802.11 b/g/n (2.4–2.4835 GHz)

• Wireless Range: Up to 80 m (varies by environment)

• Network Protocols: IPv4, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, DHCP, DNS, NTP, Multicast

• Interoperability: ONVIF (Profile S / Profile G), CGI, P2P

• Max Users: 6 (total bandwidth 36 Mbps)

• SDK / API: Supported

Cyber Security

• Video encryption, configuration encryption

• Digest, WSSE, account lockout, security logs

• X.509 certificate generation/import

• HTTPS

• Trusted boot, trusted execution, trusted upgrade

Storage

• Micro SD Card: Supports up to 256 GB (sold separately)

Software & Access

• Browser: IE, Chrome, Firefox

• Management Software: Smart PSS, DSS, DMSS

• Mobile Client: iOS, Android

Certification

• CE-LVD: EN 62368-1

• CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

• CE-RED: Radio Equipment Directive 2014/53/EU

• FCC: 47 CFR Part 15 Subpart B

• FCC ID: FCC Part 15C

Power

• Power Supply: 12 VDC

• Power Consumption:

  • Basic: 2 W (12 VDC)

  • Max (H.265 + IR intensity): 4.1 W (12 VDC)

Environment & Physical

• Operating Temperature: –40 °C to +60 °C (–40 °F to +140 °F)

• Operating Humidity: ≤ 95%

• Storage Temperature: –30 °C to +70 °C (–22 °F to +158 °F)

• Protection Rating: IP67

• Casing: Metal

• Dimensions: 166.2 mm × 70.0 mm × 128.6 mm

• Net Weight: 477.9 g

• Gross Weight: 696.5 g

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• 7" TFT display

• Color video & audio intercom

• 2 indicator lights

• Sufrace mounted

• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• 7" TFT display

• Color video & audio intercom

• 2 indicator lights

• Surface mounted

• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• Screen dimension: 7 inch

• Indoor monitor function: Unlock, video call

• Volume adjustment, and doorway monitoring

• Max quantity of outdoor station: 2 outdoor station

• Max quantity of indoor station: 3 indoor monitor

• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• 5MP CVI IR Eyeball Camera
• 120dB True WDR, 3DNR
• Max 5MP
• HD and SD dual-output
• 2.8mm fixed lens
• Max. IR length 50m, Smart IR
• IP67, DC12V

• User Manual Click on the PDF Icon :-

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

5MP Starlight HDCVI IR Bullet Camera

Note: The parameters and datasheets below apply exclusively to the 2501-POC-S2 series.

• Firmware Requirement: To use the 5MP 16:9 HDCVI camera, ensure the XVR firmware is upgraded to V4.001.0000001.0.R.200908 or later.

Features

• Resolution: Max 25 fps @ 5MP (16:9 video output)
• Image Quality: Starlight, 120 dB true WDR, 3D NR
• Compatibility: CVI/CVBS/AHD/TVI switchable
• Lens Options: 3.6 mm fixed lens (6 mm and 8 mm options available)
• Audio: Built-in microphone
• Infrared: Max IR length 80 m, Smart IR technology
• Protection: IP67 rated, PoC (CVI only) / 12V DC ±30%
• Datasheet

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

5MP Starlight HDCVI IR Bullet Camera

Note: The parameters and datasheets below apply exclusively to the 2501-S2 series.

• Firmware Requirement: To use the 5MP 16:9 HDCVI camera, ensure the XVR firmware is upgraded to V4.001.0000001.0.R.200908 or later.

Features

• Resolution: Max. 25 fps @ 5MP (16:9 video output)
• Image Quality: Starlight, 120 dB true WDR, 3D NR
• Compatibility: CVI/CVBS/AHD/TVI switchable
• Audio: Built-in microphone
• Lens: 2.7 mm–13.5 mm motorized lens
• Infrared: Max IR length 80 m, Smart IR technology
• Protection: IP67 rated, 24V AC / 12V DC
• Datasheet

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

5MP Starlight HDCVI IR Dome Camera

Note: The parameters and datasheets below apply exclusively to the 2501-S2 series.

• Firmware Requirement: To use the 5MP 16:9 HDCVI camera, ensure the XVR firmware is upgraded to V4.001.0000001.0.R.200908 or later.

Features

• Resolution: Max 25 fps @ 5MP (16:9 video output)
• Image Quality: Starlight, 120 dB true WDR, 3D NR
• Compatibility: CVI/CVBS/AHD/TVI switchable
• Lens Options: 3.6 mm fixed lens (2.8 mm option available)
• Infrared: Max IR length 30 m, Smart IR technology
• Protection: IP67 and IK10 rated, DC12V ±30%
• Datasheet

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

5MP Starlight HDCVI IR Dome Camera

Note: The parameters and datasheets below apply exclusively to the 2501-S2 series.

• Firmware Requirement: To use the 5MP 16:9 HDCVI camera, the XVR firmware must be updated to V4.001.0000001.0.R.200908 or a later version.

Features

• Resolution: Max 25 fps @ 5MP (16:9 video output)
• Image Quality: Starlight, 120 dB true WDR, 3D NR
• Compatibility: CVI/CVBS/AHD/TVI switchable
• Lens: 2.7 mm–13.5 mm motorized lens
• Infrared: Max IR length 30 m, Smart IR technology
• Protection: IP67 and IK10 rated, 12V DC ±30%
• Datasheet

Warranty: 3 Year Dahua ANZ Manufacturer Warranty
