• High quality imaging with 8 MP resolution
• Clear imaging against strong back light due to 120 dB WDR technology
• Efficient H.265+ compression technology
• Focus on human and vehicle classification based on deep learning
• Provide real-time security via built-in two-way audio
• Active strobe light and audio alarm to warn intruders off
• Support on-board storage up to 512 GB (SD card slot)
• Water and dust resistant (IP67)
• Audio and alarm interface available
• Datasheet

IMAGING

• Sensor: 1/1.8" Progressive Scan CMOS

• Resolution: 3840 × 2160 (4K)

• Min Illumination:

  • Color: 0.0008 Lux @ F1.0 (AGC ON)

  • B/W: 0 Lux (IR ON)

• Shutter: 1/3 s – 1/100,000 s

• Day/Night: IR Cut Filter

• SNR: ≥ 52 dB

• WDR: 120 dB

• Adjustment: Pan 0–360° / Tilt 0–75° / Rotate 0–360°

LENS & COVERAGE

• Lens: Fixed focal (2.8 mm / 4 mm)

• Mount: M16

• Iris: Fixed

• Aperture: F1.0

Field of View

• 2.8 mm: 105° (H) / 56° (V) / 130° (D)

• 4 mm: 90° (H) / 47° (V) / 111° (D)

Depth of Field

• 2.8 mm: 3.3 m – ∞

• 4 mm: 3.8 m – ∞

DORI RANGE

• 2.8 mm: Detect 89 m | Observe 35 m | Recognize 17 m | Identify 8 m

• 4 mm: Detect 109 m | Observe 43 m | Recognize 21 m | Identify 10 m

IR ILLUMINATION

• IR Type: Infrared

• Range: Up to 30 m

• Wavelength: 850 nm

• Smart IR: Yes

VIDEO STREAMS

Main Stream

• 50 Hz: 25 fps @ 4K / 3.2 MP / 4 MP / 1080p / 720p

• 60 Hz:

  • 24 fps @ 4K

  • 30 fps @ 3.2 MP / 4 MP / 1080p / 720p

Sub Stream

• 25 fps (50 Hz) / 30 fps (60 Hz) @ 720p / VGA / 360p

Third Stream*

• 10 fps @ 1080p / 720p / VGA / 360p

*Available under certain settings.

VIDEO ENCODING

• Main: H.265 / H.264 / H.265+ / H.264+

• Sub: H.265 / H.264 / MJPEG

• Third: H.265 / H.264

• Bit Rate: 32 Kbps – 16 Mbps

• Control: CBR / VBR

• Profiles: H.264 Baseline/Main/High, H.265 Main

• SVC: H.264 / H.265

• ROI: 1 fixed region (Main & Sub)

AUDIO

• Built-in: 2 microphones + speaker (105 dB @ 10 cm)

• Compression: G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC

• Bit Rate: 8 – 320 Kbps (codec dependent)

• Sampling: 8 / 16 / 32 / 48 kHz

• Noise Filtering: Yes

• Audio I/O: Line In / Line Out

NETWORK & SECURITY

• Protocols: TCP/IP, HTTP(S), FTP, DHCP, DNS, RTP/RTSP, NTP, SMTP, IPv4/IPv6, SNMP, QoS, SSL/TLS, PPPoE, WebSocket, SRTP, SFTP

• ONVIF: Profile S / T / G

• API: ONVIF, ISAPI, SDK, ISUP

• Live View: Up to 6 channels

• Users: Up to 32 (Admin / Operator / User)

• Security: HTTPS, 802.1X, IP filter, digest auth, watermark, TLS 1.1/1.2/1.3

STORAGE

• Edge Storage: microSD / SDHC / SDXC up to 512 GB

• Network Storage: NAS (NFS / SMB), ANR

EVENTS & AI

• Motion Detection: Human & Vehicle classification

• Tamper Alarm: Yes

• Smart Event: Scene change detection

• AI Functions:

  • Face Capture

  • Perimeter Protection (Line crossing, intrusion, entry, exit)

INTERFACES

• Ethernet: 1× RJ45 10/100 Mbps

• Alarm I/O: 1 In / 1 Out (24 VAC/VDC, 1 A)

• Reset Button: Yes

POWER

• DC: 12 VDC ±25%, Max 16 W

• PoE: IEEE 802.3at (Class 4), Max 18 W

BUILD & ENVIRONMENT

• Housing: Full metal

• Dimensions: Ø138.3 × 115.4 mm

• Weight: ~780 g (Net), ~1210 g (Packaged)

• Operating Temp: -30 °C to 60 °C

• Humidity: ≤ 95% (Non-condensing)

• Protection: IP67

SYSTEM

• Functions: Heartbeat, mirror, flash log, anti-banding, pixel counter, email reset

• Languages: 33 supported

• Flashing Light:

  • /SRB: Red & Blue

  • /SL: White

COMPLIANCE

• EMC: CE, RCM, IC, KC

• Safety: UL / IEC / EN 62368-1

• Environment: RoHS, WEEE, REACH
