HiLook 4 MP Network IR Turret Camera, 2.8mm, 4MP(2560×1440):20fps, ICR, 3D DNR, BLC, H.265 , 30m IR, IP67, PoE, DC12V

• High quality imaging with 4 MP resolution
• Efficient H.265+ compression technology to save bandwidth and storage
• Clear imaging against strong back light due to 120 dB true WDR technology
• Water and dust resistant (IP67)
• 3D DNR technology delivers clean and sharp images
• Easy installation with Power over Ethernet (PoE) technology

Camera

• Image Sensor1/3″ progressive scan CMOS
• Min. IlluminationColor: 0.01 Lux @(F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON)
• Shutter Speed1/3 s to 1/100, 000 s
• Slow ShutterYes
• Wide Dynamic Range120 dB
• Angle AdjustmentPan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
• DNR3D DNR
• Day & NightIR cut filter

Lens

• ApertureF2.0
• FocusFixed
• FOV

  2.8 mm, horizontal FOV 98°, vertical FOV 53°, diagonal FOV 115°

  4 mm, horizontal FOV 77°, vertical FOV 42°, diagonal FOV 91°

• Lens MountM12
• Focal Length2.8 mm, 4 mm

Network

• Alarm TriggerMotion detection, video tampering, exception (network disconnected, IP address conflict, illegal login, HDD error)
• ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, UDP, Bonjour
• APIOpen Network Video Interface (Profile S), ISAPI, SDK
• Simultaneous Live ViewUp to 6 channels
• User/HostUp to 32 users. 3 levels: Administrator, Operator and User
• ClientiVMS-4200, Hik-Connect, iVMS-5200
• Web Browser

  Plug-in required live view: IE 10, IE 11

  Local service: Chrome 57.0+, Firefox 52.0+

• General FunctionAnti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
• Firmware VersionV5.5.111


• Image EnhancementHLC, BLC, 3D DNR
• Image SettingSaturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
• Day/Night SwitchAuto/Schedule/Day/Night
• Max. Resolution2560 × 1440
• Main Stream

  50Hz: 20 fps (2560 × 1440)

  25 fps (2304 × 1296, 1920 × 1080, 1280 × 720)

  60Hz: 20 fps (2560 × 1440)

  30 fps (2304 × 1296, 1920 × 1080, 1280 × 720)

• Sub Stream

  50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)

  60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)

IR

• IR RangeUp to 30 m
• Wavelength850 nm

Interface

• Communication Interface1 RJ45 10M/100M self-adaptive Ethernet port

General

• Power Supply

  12 VDC ± 25%, 5.5 mm coaxial power plug

  PoE (802.3af, Class 3)

• Power Consumption And Current

  12 VDC, 0.4 A, max. 5 W

  PoE (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 6.5 W

• Material Camera body: metal, bottom base: plastic
• Dimensions

  Camera: Ø112 mm × 81.5 mm (Ø4.41″ × 3.21\”)

  With package: 150 mm × 150 mm × 141 mm (5.9 × 5.9\” × 5.6\”)”

• Camera: approx. 320 g

  With package: approx. 556 g

• Protection LevelIP67 (IEC 60529-2013),TVS 2000V lightning protection, surge protection and voltage transient protection
• Operating Condition-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
• Web Client LanguageEnglish, Ukrainian

Compression Standard

• H.264+Main stream supports
• H.265+Main stream supports
• H.264 TypeBaseline Profile/Main Profile/High Profile
• Video Compression

  Main stream: H.265/H.264

  Sub-stream: H.265/H.264/MJPEG

• H.265 TypeMain Profile
• Video Bit Rate32 Kbps to 8 Mbps

Smart Feature-Set

• Region Of Interest1 fixed region for main stream
