Key Features:

• Slim & Lightweight Design

• IR Illumination & Night Vision

• Two-Way Audio & App Voice Call

• Remote Management

  • Manage via platform

  • Voice call between App and door station

• Multiple Unlock Methods

  • Card unlock

  • Indoor monitor unlock

  • Remote unlock via App

• Weather Resistance

  • IP65 rated (Silicone sealant required—refer to quick start guide)

• Card Support

  • Stores up to 10,000 cards

• Power & Connectivity

  • Standard PoE power supply

  • Wireless network supported

• Lock Control

  • Supports control of 2 locks

• Datasheet

System

• Main Processor: Embedded Processor

• Operating System: Embedded Linux OS

• Button Type: Mechanical

• Number of Buttons: 1

• Interoperability: ONVIF, CGI

• Network Protocols: IPv4, RTSP, UDP, DNS, P2P, RTP, TCP, SIP

Basic

• Camera: 1/2.8" 2MP CMOS (low illumination, WDR, color, IR)

• Field of View:

  • Horizontal: 125°

  • Vertical: 71°

  • Diagonal: 142°

• WDR: 120 dB

• Noise Reduction: 3D NR

• Video Compression: H.264, H.265

• Video Resolution:

  • Main stream: 720p, WVGA, D1, CIF

  • Sub stream: 1080p, WVGA, D1, QVGA, CIF

• Video Frame Rate:

  • PAL: 25 fps

  • NTSC: 30 fps

• Video Bit Rate: 256 Kbps – 8 Mbps

• Light Compensation: Auto IR

• Day/Night Mode: Auto (ICR) / Color / B/W

Audio

• Compression: G.711a, G.711u, PCM

• Audio Input: 1

• Audio Output: Built-in speaker

• Audio Mode: Two-way audio

• Audio Enhancement: Echo suppression, digital noise reduction

• Audio Bit Rate: 16 KHz, 16 Bit

Functions

• Communication Mode: Full digital

• Unlock Methods: Card, App, Indoor Monitor

• Card Type: IC Card

• Auto Snapshot: Supported

• Leave Videos: Yes (with SD card in door station or indoor monitor)

• Wi-Fi: Supported

• Wireless Standards: IEEE 802.11b/g/n

• Frequency Range: 2.4 GHz

• Storage: Micro SD card (up to 256 GB)

• Web Configuration: Yes

Performance

• Card Reading Distance: 0 – 4.3 cm (0"–1.69")

• Local Card Issuance: Supported

• Casing Material: PC + Acrylic

Capacity

• Card Capacity: 10,000

Ports

• RS-485: 1

• Alarm Input: 1

• Alarm Output: 1

• Power Output: 1 port, 12 V / 200 mA

• Exit Button: 1

• Door Status Detection: 1

• Lock Control: 1 port (Normally Closed by default)

• Network Port: 1 × 10/100 Mbps

Alarm

• Tamper Alarm: Yes

General

• Appearance Color: Black plate with silvery frames

• Power Supply: 12 VDC, 1 A / Standard PoE

• Power Adapter: Optional

• Installation Method: Surface Mount

• Certifications: CE

• Included Accessories: Alarm power ribbon cable, brackets

Physical

• Dimensions: 150.0 mm × 100.0 mm × 25.4 mm (5.91" × 3.94" × 1.00")

• Protection Rating: IP65 (Silicone sealant required – see Quick Start Guide)

• Gross Weight: 510 g (1.12 lb)

• Anti-Corrosion Level: Basic Protection

Environmental

• Operating Temperature: –30 °C to +60 °C (–22 °F to +140 °F)

• Operating Humidity: 10%–90% RH (non-condensing)

• Environment: Outdoor

• Operating Altitude: Up to 3000 m (9842.52 ft)

• Power Consumption: ≤ 1 W (standby), ≤ 7 W (working)

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

ARA14-W2
Wireless Intercom Siren

• Two-way talk via RF transmission.
• High-decibel alarm sound for effective alerts.
• Multiple alarm sounds: Fire, medical, intrusion, panic, and more.
• Configurable arming/disarming prompt sound and LED indicator.
• Supports panic button for emergency situations.
• Voice talk support through the app and SIP.

Specifications

Port

• Microphone: Yes

Video & Audio

• Two-way Audio: Yes

Function

• Button: 1 × panic button, 1 × power button
• Buzzer: Yes
• Remote Update: Cloud update
• Low Battery Detection: Yes
• Tamper: Yes

Technical

• LED Indicator: Red, blue, and green indicators
• Scenario: Indoor
• Operating Current:
  • Battery (3V): 1.5 A (Max), 20 µA (Standby)
  • DC (12V): 0.4 A (Max), 1.5 mA (Standby)
• Sound and Light Alarm: Yes

Wireless

• Carrier Frequency: 433.1 MHz–434.6 MHz
• Communication Mechanism: Two-way
• Communication Distance:
  • Alarm transmission: 1200 m
  • Intercom: 800 m
• Encryption Mode: AES128
• Frequency Hopping: Yes

General

• Power Supply: 12 VDC / 4 × CR123A battery
• Battery Model: CR123A
• Standby Time: 3 years (triggered once every 2 weeks, alarms for 120 sec)
• Power Consumption: 4.5 W (Max), 0.4 mW (Standby)
• Operating Temperature: -10 °C to +55 °C (+14 °F to +131 °F) (indoor)
• Operating Humidity: 10%–90% RH
• Product Dimensions: 133.0 mm × 133.0 mm × 35.5 mm (5.24" × 5.24" × 1.40")
• Net Weight: 377 g (0.83 lb)
• Gross Weight: 507 g (1.12 lb)
• Installation: Wall mount
• Casing Material: PC + ABS
• Appearance Color: White
• Certifications: CE
• Anti-corrosion Level: Basic Protection
• Storage Temperature: -10 °C to +55 °C (+14 °F to +131 °F)
• Storage Humidity: 10%–90% RH
• Packaging Dimensions: 170 mm × 166 mm × 55 mm (6.69" × 6.54" × 2.71")

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

2-Wire IP Villa Door Station

• Anodized aluminum front panel.
• CMOS low illumination 2MP HD colorful 168.6° camera.
• Video intercom function.
• Provides 12 VDC, 600 mA power.
• Mobile phone app for talking to visitors or unlocking the door remotely.
• IK07 & IP65 rated (requires silicone sealant for the shell; refer to the quick start guide).
• Supports surface and flush mounting.
• Supports H.265 and H.264 video compression.
• Standard PoE power supply (if the VTO device with 12 V power output charges a load, it must be connected to a PSE switch compliant with the 802.3.at standard).
• Datasheet

System

• Main Processor: Embedded Processor
• Operating System: Embedded Linux Operating System
• Button Type: Mechanical
• Number of Buttons: 1
• Interoperability: ONVIF, CGI

Network Protocols

IPv4, RTSP, UDP, DNS, P2P, UPnP, RTP, TCP, SIP

Basic Features

• Camera: 1/2.9" 2 MP CMOS
• Field of View: Horizontal: 168.6°, Vertical: 87.1°, Diagonal: 176.7°
• WDR: 120 dB
• Noise Reduction: 3D NR
• Video Compression: H.265, H.264
• Video Resolution:
  • Main Stream: 720p, WVGA, D1, CIF
  • Sub Stream: 1080p, WVGA, D1, QVGA, CIF
• Video Frame Rate: 25 fps
• Video Bit Rate: 256 Kbps to 8 Mbps
• Light Compensation: Auto IR
• Day/Night Mode: Auto(ICR)/Color/B/W, Color/B/W
• Audio Compression: G.711a, G.711u, PCM
• Audio Input: 1 channel
• Audio Output: Built-in speaker
• Audio Mode: Two-way audio
• Audio Enhancement: Echo suppression, digital noise reduction
• Audio Bit Rate: 16 kHz, 16 bits

Functionality

• Communication Mode: Digital 2-wire
• Unlock Mode: Remote
• Leave Videos: Yes (requires SD card in the indoor monitor or door station)
• Storage: Supports Micro SD card (up to 256 GB)
• Web Configuration: Yes

Performance

• Casing Material: Aluminum
• Ports:
  • RS-485: 1
  • Alarm Output: 1
  • Power Output: 1 port, 12 V/600 mA
  • Exit Button: 1
  • Door Status Detection: 1
  • Lock Control: 1
  • Network Port: 1 × RJ-45, 10/100 Mbps

Alarm

• Tamper Alarm: Yes

General Information

• Appearance Color: Black
• Power Supply:
  • Dahua 2-wire switch (max. power supply distance: 50 m)
  • 48 VDC, 1 A; PoE (802.3af/at)
• Power Adapter: Optional
• Installation: Surface Mount
• Certifications: CE
• Accessories:
  • Surface mount box (optional)
  • Flush mount box (optional)
  • Rain cover (optional)
• Product Dimensions: 130 mm × 96 mm × 28.5 mm (5.12" × 3.78" × 1.12")
• Protection: IK07, IP65
• Operating Temperature: –30°C to +60°C (–22°F to +140°F)
• Operating Humidity: 10%–90% RH, non-condensing
• Operating Environment: Outdoor
• Operating Altitude: 0 m–3000 m (0 ft–9842.52 ft)
• Power Consumption: ≤4 W (standby), ≤5 W (working)
• Gross Weight: 0.48 kg (1.06 lb)
• Storage Temperature: 0°C to +40°C (+32°F to +104°F)
• Storage Humidity: 30%–75% RH, non-condensing

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• Highly durable and elegant: Made of aluminum panel with a mechanical keypad.

• 2MP HD Camera

• User Capacity: Supports up to 5,000 users and 10,000 cards.

• Unlock Methods: Allows multiple unlock methods including password, IC card, and remote unlock.

• Connectivity: Connects card readers and controllers through Wiegand protocol.

• Power Supply: Provides 12 VDC, 600 mA power.

• Weatherproofing: IP65 rated (silicone sealant is required for the shell; refer to the quick start guide).

• Vandal Resistance: IK08 rated.

• PoE Compatibility: Standard PoE power supply. If the VTO device with 12 V power output needs to charge the load, it should be connected to a PSE switch compliant with the 802.3.at standard.

System

• Main Processor: Embedded Processor
• Operating System: Embedded Linux OS
• Button Type: Mechanical
• Number of Buttons: 12

Basic Features

• Camera: 1/2.9" 2 MP CMOS
• Field of View: Horizontal: 140°, Vertical: 80°, Diagonal: 160°
• WDR (Wide Dynamic Range): 120 dB
• Noise Reduction: 3D NR
• Video Compression: H.264, H.265
• Video Resolution:
  • Main stream: 720p, WVGA, D1, CIF
  • Sub stream: 1080p, WVGA, D1, QVGA, CIF
• Video Frame Rate: 25 fps
• Light Compensation: Auto white light
• Day/Night Mode: Color/B/W

Audio

• Audio Compression: G.711a, G.711u, PCM
• Audio Input: 1
• Audio Output: Built-in Speaker
• Audio Mode: Two-way audio
• Audio Enhancement: Echo suppression and digital noise reduction
• Audio Bit Rate: 16 kHz, 16 bit

Functions

• Communication Mode: Digital 2-wire
• Unlock Mode: Card swiping, password, remote
• Card Type: Mifare card
• Auto Snapshot: Yes (requires SD card in VTH or FTP server for VTO)
• Leave Videos: Yes (requires SD card in indoor monitor or door station)
• Storage: Supports Micro SD card (up to 256 GB)
• Web Configuration: Yes

RFID

• Modulation Type: AM
• Frequency Range: 13.56 MHz
• Max. Transmission Power: 42 dBuA/m @10 m

Performance

• Card Reading Distance: 0–3 cm (0"–1.18")
• Casing Material: Aluminum

Capacity

• Card Capacity: 10,000

Ports

• RS-485: 1
• Wiegand: 1
• Alarm Input: 1
• Alarm Output: 1
• Power Output: 1 port, 12 V/600 mA
• Door Bell: 1
• Exit Button: 1
• Lock Control: 1
• Network Port: 1 × RJ-45, 10 Mbps/100 Mbps

Alarm

• Tamper Alarm: Yes

General

• Appearance Color: Silver
• Power Supply: 48 VDC, 0.4 A, PoE (802.3af/at)
• Power Adapter: Optional
• Installation: Flush Mount; Surface Mount
• Certifications: CE
• Accessory: Flush mount box (optional), Surface mount box (optional)
• Product Dimensions: 200.0 mm × 98.0 mm × 35.4 mm (7.87" × 3.86" × 1.39")
• Protection: IK08, IP65 (silicone sealant required; see quick start guide)

Operating Conditions

• Operating Temperature: –40 °C to +60 °C (–40 °F to +140 °F)
• Operating Humidity: 10%–90% RH, non-condensing
• Operating Environment: Outdoor
• Operating Altitude: Up to 3,000 m (9,842.52 ft)

Power and Weight

• Power Consumption: ≤ 5 W (standby), ≤ 7 W (working)
• Gross Weight: 692 g (1.53 lb)

Storage Conditions

• Storage Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
• Storage Humidity: 30%–75% RH

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

DHI-KTX01 Dahua 2Wire Wi-Fi Hybrid Intercom Surface Or Flash Mount Kit

• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• 1 x Dahua VTO2202F-P IP Villa Door Station
• 1 x Dahua VTH2421FW IP Indoor Monitor

• 1 x Dahua PFS3005-4ET-60 4-Port PoE Switch (Unmanaged)
• 1 x Dahua VTM115 Surface mounted Box or VTM114 Flush mounted

• IP Villa Door Station

• 2MP CMOS camera

• Mechanical button

• Night vision & voice indicator

• 160° angle of view

• Group call

• Aluminium alloy plate

• IK07 & IP65 (Apply silicon gel to gaps between the device and the wall

•  Support standard PoE

• IP Indoor Monitor

• IPC surveillance

• Alarm integration

• High performance

• Embeded 8GB SD card

• Support standard PoE

• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• 1 x Dahua VTO2202F-P IP Villa Door Station
• 1 x Dahua VTH2421FW IP Indoor Monitor

• 1 x Dahua PFS3005-4ET-60 4-Port PoE Switch (Unmanaged)
• 1 x Dahua VTM115 Surface mounted Box or VTM114 Flush mounted

• IP Villa Door Station

• 2MP CMOS camera

• Mechanical button

• Night vision & voice indicator

• 160° angle of view

• Group call

• Aluminium alloy plate

• IK07 & IP65 (Apply silicon gel to gaps between the device and the wall

•  Support standard PoE

• IP Indoor Monitor

• IPC surveillance

• Alarm integration

• High performance

• Embeded 8GB SD card

• Support standard PoE

• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• IP Villa Door Station

• 2MP CMOS camera

• Mechanical button

• Night vision & voice indicator

• 160° angle of view

• Group call

• Aluminium alloy plate

• IK07 & IP65 (Apply silicon gel to gaps between the device and the wall

•  Support standard PoE

• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• 7" TFT display

• Color video & audio intercom

• 2 indicator lights

• Surface mounted

• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty

• Screen dimension: 7 inch

• Indoor monitor function: Unlock, video call

• Volume adjustment, and doorway monitoring

• Max quantity of outdoor station: 2 outdoor station

• Max quantity of indoor station: 3 indoor monitor

• Product specification

Warranty: 3 Year Dahua ANZ Manufacturer Warranty
