8 MP Smart Hybrid Light with ColorVu Fixed Turret Network Camera
- High quality imaging with 8 MP resolution
- Smart Hybrid Light: advanced technology with long range
- Clear imaging against strong back light due to 130 dB WDR technology
- Efficient H.265+ compression technology
- Focus on human and vehicle classification based on deep learning
- -U: Built-in microphone for real-time audio security
- Water and dust resistant (IP67)
- Datasheet
Camera Specifications
Camera
- Image Sensor: 1/1.8" Progressive Scan CMOS
- Max. Resolution: 3840 × 2160
-
Min. Illumination:
- Color: 0.0008 Lux @ (F1.0, AGC ON)
- 0 Lux with light
- Shutter Time: 1/3 s to 1/100,000 s
- Day & Night: IR cut filter
-
Angle Adjustment:
- Pan: 0° to 360°
- Tilt: 0° to 75°
- Rotate: 0° to 360°
Lens
- Lens Type: Fixed focal lens (2.8 mm and 4 mm optional)
-
Focal Length & FOV:
- 2.8 mm: Horizontal FOV 108.8°, Vertical FOV 56.4°, Diagonal FOV 134.3°
- 4 mm: Horizontal FOV 93.3°, Vertical FOV 47.2°, Diagonal FOV 114.2°
- Lens Mount: M16
- Iris Type: Fixed
- Aperture: F1.0
-
Depth of Field:
- 2.8 mm: 3.3 m to ∞
- 4 mm: 3.8 m to ∞
DORI (Detection, Observation, Recognition, Identification)
-
2.8 mm:
- Detection: 89 m
- Observation: 35 m
- Recognition: 17 m
- Identification: 8 m
-
4 mm:
- Detection: 109 m
- Observation: 43 m
- Recognition: 21 m
- Identification: 10 m
Illuminator
- Supplement Light Type: IR, White Light
- Supplement Light Range: Up to 40 m
- Smart Supplement Light: Yes
- IR Wavelength: 850 nm
Video
-
Main Stream:
- 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- 60 Hz:
- 24 fps (3840 × 2160)
- 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
-
Sub-Stream:
- 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
-
Third Stream:
- 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- Supported under certain settings.
-
Video Compression:
- Main Stream: H.265/H.264/H.264+/H.265+
- Sub-Stream: H.265/H.264/MJPEG
- Third Stream: H.265/H.264
-
Video Bit Rate: 32 Kbps to 16 Mbps
-
H.264 Type: Baseline Profile, Main Profile, High Profile
-
H.265 Type: Main Profile
-
Bit Rate Control: CBR, VBR
-
Scalable Video Coding (SVC): H.264 and H.265 encoding
-
Region of Interest (ROI): 1 fixed region for main stream and sub-stream
Audio
- Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
-
Bit Rate:
- 64 Kbps (G.711ulaw/G.711alaw)
- 16 Kbps (G.722.1)
- 16 Kbps (G.726)
- 16 Kbps to 64 Kbps (AAC-LC)
- 32 to 192 Kbps (MP2L2)
- 8 to 320 Kbps (MP3)
- Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
- Environment Noise Filtering: Yes
Network
- Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
- Simultaneous Live View: Up to 6 channels
- API: ONVIF (Profiles S, G, T), ISAPI, SDK, ISUP
- User/Host: Up to 32 users, 3 user levels (administrator, operator, user)
-
Security:
- Password protection, HTTPS encryption, 802.1X authentication, IP address filtering, security audit log
- TLS 1.1/1.2/1.3, host authentication (MAC address)
- Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance
- Day/Night Switch: Day, Night, Auto, Schedule
- Enhancement: BLC, HLC, 3D DNR
- SNR: ≥ 52 dB
- Wide Dynamic Range (WDR): 130 dB
- Privacy Mask: 4 programmable polygon masks
General
-
Power:
- 12 VDC ± 25%, 0.54 A, max. 6.5 W
- PoE: IEEE 802.3af, Class 3, max. 8 W
- Material: Cover and main body (metal)
- Dimensions: Ø138.3 mm × 115.4 mm (Ø5.4" × 4.5")
-
Weight:
- Without package: Approx. 770 g (1.7 lb.)
- With package: Approx. 1040 g (2.3 lb.)
- Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), humidity ≤ 95% (non-condensing)
Approvals
- EMC: CE-EMC, RCM, IC, KC
- Safety: UL, CB, CE-LVD, BIS
- Environment: CE-RoHS
- Protection: IP67
Warranty: 3 Year Hikvision ANZ Manufacturer Warranty
