• Up to 8-ch IP camera inputs, plug & play with 8 power-over-Ethernet (PoE) interfaces
• H.265+/H.265/H.264+/H.264 video formats
• Up to 1-ch@12 MP or 2-ch@8 MP or 4-ch@4 MP or 8-ch@1080p decoding capacity
• Up to 80 Mbps incoming bandwidth
• Adopt Hikvision Acusense technology to minimize manual effort and security costs
• 4TB Hard Drive
• Datasheet

Intelligent Analytics

• AI by Device:

  • Facial recognition
  • Perimeter protection
  • Motion detection 2.0

• AI by Camera:

  • Facial recognition
  • Perimeter protection
  • Throwing objects from building
  • Motion detection 2.0
  • ANPR
  • VCA

Facial Recognition

• Facial Detection and Analytics:

  • Face picture comparison
  • Human face capture
  • Face picture search

• Face Picture Library:

  • Up to 16 face picture libraries
  • Total of up to 20,000 face pictures (each picture ≤ 4 MB, total capacity ≤ 1 GB)

Facial Detection and Analytics Performance

• 1-ch, 8 MP
• Face Picture Comparison
  • 4-ch

Motion Detection 2.0

• By Device:

  • 1-ch, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarms
  • 4-ch, 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarms
  • All channels, 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarms

• By Camera:

  • All channels

Perimeter Protection

• By Device:

  • 1-ch, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarms

• By Camera:

  • All channels

Throwing Objects from Building

• By Camera:
  • All channels

Video and Audio

• IP Video Input:

  • 8-ch

• Incoming Bandwidth:

  • 80 Mbps

• Outgoing Bandwidth:

  • 80 Mbps

• HDMI Output:

  • 1-ch, 4K (3840 × 2160)/30 Hz
  • 2K (2560 × 1440)/60 Hz
  • 1920 × 1080/60 Hz
  • 1600 × 1200/60 Hz
  • 1280 × 1024/60 Hz
  • 1280 × 720/60 Hz

• VGA Output:

  • 1-ch, 1920 × 1080/60 Hz
  • 1280 × 1024/60 Hz
  • 1280 × 720/60 Hz

• Video Output Mode:

  • HDMI/VGA simultaneous output
  • HDMI/VGA independent output

• CVBS Output:

  • N/A

• Audio Output:

  • 1-ch, RCA (Linear, 1 KΩ)

• Two-Way Audio:

  • 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)

Decoding

• Decoding Format:

  • H.265/H.265+/H.264+/H.264

• Recording Resolution:

  • 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF

• Synchronous Playback:

  • 8-ch

• Decoding Capability:

  • AI on: 1-ch@12 MP (30 fps) / 1-ch@8 MP (30 fps) / 3-ch@4 MP (30 fps) / 6-ch@1080p (30 fps)
  • AI off: 1-ch@12 MP (30 fps) / 2-ch@8 MP (30 fps) / 4-ch@4 MP (30 fps) / 8-ch@1080p (30 fps)

• Stream Type:

  • Video
  • Video & Audio

• Audio Compression:

  • G.711ulaw / G.711alaw / G.722 / G.726 / AAC

Network

• Remote Connection:

  • 128

• API:

  • ONVIF (profile S/G)
  • SDK
  • ISAPI

• Compatible Browser:

  • IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version

• Network Protocol:

  • TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS

• Network Interface:

  • 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
  • 1 RJ-45 10/100 Mbps self-adaptive Ethernet interface

• PoE Interface:

  • 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface

Power

• Power Supply:

  • 48 VDC, 1.875 A

• Consumption:

  • ≤ 10 W (without HDD, and PoE off)

Auxiliary Interface

• SATA:

  • 1 SATA interface

• Capacity:

  • Up to 10 TB capacity for each HDD

• USB Interface:

  • Front panel: 1 × USB 2.0
  • Rear panel: 1 × USB 2.0

• Alarm In/Out:

  • 4/1; N/A; N/A; N/A (4/1 is optional)

General

• GUI Language:

  • English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz, Brazilian Portuguese, Indonesian

• Power Supply:

  • 48 VDC, 1.875 A

• Consumption:

  • ≤ 10 W (without HDD, and PoE off)

• Working Temperature:

  • -10 °C to 55 °C (14 °F to 131 °F)

• Working Humidity:

  • 10% to 90%

• Dimension (W × D × H):

  • 320 mm × 240 mm × 48 mm (12.6" × 9.4" × 1.9")

• Weight:

  • ≤ 1 kg (without HDD, 2.2 lb.)

Certification

• FCC:

  • Part 15 Subpart B, ANSI C63.4-2014

• CE:

  • EN 55032: 2015
  • EN 61000-3-2
  • EN 61000-3-3
  • EN 50130-4
  • EN 55035: 2017

• Obtained Certification:

  • CE, FCC, IC, CB, KC, UL, RoHS, REACH, WEEE, RCM, UKCA, LOA, BIS

• High quality imaging with 4 MP resolution
• Excellent low-light performance via DarkFighter technology
• Clear imaging against strong back light due to 140 dB WDR technology
• Efficient H.265+ compression technology to save bandwidth and storage
• 5 streams to meet a wide variety of applications
• Vandal proof (IK10)
• Datasheet

• High quality imaging with 8 MP resolution
• Excellent low-light performance via DarkFighter technology
• Efficient H.265+ compression technology to save bandwidth and storage
• Clear imaging against strong back light due to 120 dB true WDR technology
• 5 streams to meet a wide variety of applications
• Vandal proof (IK10)
• Datasheet

Camera Specifications

Image Sensor

• 1/1.8" Progressive Scan CMOS
• Max Resolution: 3840 × 2160
• Min. Illumination:
  • Color: 0.002 Lux @ (F1.2, AGC ON)
  • B/W: 0.0002 Lux @ (F1.2, AGC ON), 0 Lux with IR
• Shutter Time: 1 s to 1/100,000 s
• Day & Night: IR cut filter with blue glass module to reduce ghost phenomenon
• Angle Adjustment:
  • Pan: 0° to 355°
  • Tilt: 0° to 75°
  • Rotate: 0° to 355°

Lens

• Focal Length & Field of View (FOV):
  • 2.8 to 12 mm:
    • Horizontal FOV: 112.3° to 41.2°
    • Vertical FOV: 58° to 23.1°
    • Diagonal FOV: 137.3° to 47.3°
  • 8 to 32 mm:
    • Horizontal FOV: 41.8° to 14.9°
    • Vertical FOV: 22.92° to 8.48°
    • Diagonal FOV: 48.7° to 17°
• Focus: Auto, Semi-auto, Manual
• Iris Type: P-iris
• Aperture:
  • 2.8 to 12 mm: F1.2 to F2.5
  • 8 to 32 mm: F1.7 to F1.73

DORI (Detect, Observe, Recognize, Identify)

Wide View

• 2.8 to 12 mm:
  • D: 87 m, O: 34.5 m, R: 17.4 m, I: 8.7 m
• 8 to 32 mm:
  • D: 218 m, O: 86.5 m, R: 43.6 m, I: 21.8 m

Tele View

• 2.8 to 12 mm:
  • D: 216 m, O: 85.7 m, R: 43.2 m, I: 21.6 m
• 8 to 32 mm:
  • D: 580 m, O: 230.2 m, R: 116 m, I: 58 m

Illuminator

• IR Wavelength: 850 nm
• Smart Supplement Light: Yes
• Supplement Light Range:
  • 2.8 to 12 mm: 30 m
  • 8 to 32 mm: 50 m
• Light Type: IR

Video

• Main Stream:
  • 50 Hz: 25 fps @ 3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720
  • 60 Hz: 30 fps @ same resolutions
• Sub-Stream:
  • 50 Hz: 25 fps @ 704 × 576, 640 × 480
  • 60 Hz: 30 fps @ 704 × 480, 640 × 480
• Third to Fifth Stream: Resolutions vary; refer to main streams.
• Video Compression: H.265+/H.265/H.264+/H.264, MJPEG
• Bit Rate: 32 Kbps to 16 Mbps
• H.264/H.265 Types: Baseline, Main, High Profiles

Audio

• Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
• Sampling Rates: 8/16/32/44.1/48 kHz
• Bit Rate:
  • 64 Kbps (G.711)
  • 16–192 Kbps (MP3/MP2L2/AAC-LC)

Network

• Protocols: TCP/IP, HTTP, HTTPS, RTSP, etc.
• Simultaneous Live View: Up to 20 channels
• API Support: ONVIF, ISAPI, SDK

Intelligent Features

• Face Capture & Comparison:
  • Detects 120 faces simultaneously
  • Supports 150,000 faces in total
• People Counting: Real-time data, deduplication, export reports
• Perimeter Protection: Line crossing, intrusion

General Specifications

• Power Supply:
  • 12 VDC ±20%, 24 VAC ±20%, PoE IEEE 802.3at
• Material: Aluminum alloy
• Weight: Approx. 875 g (1.93 lb.)
• Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), ≤95% humidity

Certifications

• EMC: FCC, CE-EMC, RCM, IC
• Safety: UL 62368-1, CE-LVD
• Environment: RoHS, WEEE

• High quality imaging with 4 MP resolution
• Excellent low-light performance via DarkFighter technology
• Clear imaging against strong back light due to 140 dB WDR technology
• Efficient H.265+ compression technology to save bandwidth and storage
• 5 streams to meet a wide variety of applications
• Water and dust resistant (IP67) and vandal proof (IK10)
• Anti-IR reflection bubble guarantees image quality
• Datasheet

• High quality imaging with 4 MP resolution
• 25 × optical zoom captures details in remote area
• Clear imaging against strong back light due to 140 dB WDR technology
• Efficient H.265+ compression technology to save bandwidth and storage
• Built-in heater on the front viewing window to ensure clear image under snowy weather
• Built-in gyroscope to ensure stable image output
• Water and dust resistant (IP67) and vandal proof (IK10)
• Datasheet

• High quality imaging with 4 MP resolution
• Excellent low-light performance via DarkFighter technology
• Clear imaging against strong back light due to 140 dB WDR technology
• Efficient H.265+ compression technology to save bandwidth and storage
• 5 streams to meet a wide variety of applications
• Water and dust resistant (IP67) and vandal proof (IK10)
• Datasheet

• High quality imaging with 4 MP resolution
• Excellent low-light performance via DarkFighter technology
• Clear imaging against strong back light due to 140 dB WDR technology
• Efficient H.265+ compression technology to save bandwidth and storage
• 5 streams to meet a wide variety of applications
• Water and dust resistant (IP67) and vandal proof (IK10)
• Datasheet

• High quality imaging with 8 MP resolution
• Excellent low-light performance via DarkFighter technology
• Clear imaging against strong back light due to 120 dB true WDR technology
• Efficient H.265+ compression technology to save bandwidth and storage
• 5 streams to meet a wide variety of applications
• Water and dust resistant (IP67) and vandal proof (IK10)
• Datasheet


Camera Specifications

Image Sensor

• Type: 1/1.8" Progressive Scan CMOS
• Max. Resolution: 3840 × 2160
• Min. Illumination:
  • Color: 0.002 Lux @ (F1.2, AGC ON)
  • B/W: 0.0002 Lux @ (F1.2, AGC ON), 0 Lux with IR
• Shutter Time: 1 s to 1/100,000 s
• Day & Night:
  • IR cut filter
  • Blue glass module to reduce ghost phenomenon

Lens

• Aperture:
  • 2.8 to 12 mm: F1.2 to F2.5
  • 8 to 32 mm: F1.7 to F1.73
• Iris Type: P-iris
• Focal Length & Field of View (FOV):
  • 2.8 to 12 mm:
    • Horizontal FOV: 112.3° to 41.2°
    • Vertical FOV: 58° to 23.1°
    • Diagonal FOV: 137.3° to 47.3°
  • 8 to 32 mm:
    • Horizontal FOV: 41.8° to 14.9°
    • Vertical FOV: 22.92° to 8.48°
    • Diagonal FOV: 48.7° to 17°
• Focus Modes: Auto, Semi-auto, Manual

DORI (Detect, Observe, Recognize, Identify)

• Wide (2.8 to 12 mm):
  • D: 87 m
  • O: 34.5 m
  • R: 17.4 m
  • I: 8.7 m
• Tele (8 to 32 mm):
  • D: 218 m
  • O: 86.5 m
  • R: 43.6 m
  • I: 21.8 m

Illuminator

• Type: IR
• Range:
  • 2.8 to 12 mm: 50 m
  • 8 to 32 mm: 100 m
• Smart Supplement Light: Yes
• Wavelength: 850 nm

AI Open Platform

• Model Specification:
  • Supports up to 4 models
  • Model types: detection, classification, mixed

Video

• Main Stream Resolutions:
  • 50 Hz: 25 fps
  • 60 Hz: 30 fps
• Sub-Streams & Frame Rates: Multiple resolutions supported
• Compression: H.265+/H.265/H.264+/H.264/MJPEG
• Bit Rate: 32 Kbps to 16 Mbps
• Encoding Features: ROI, SVC

Audio

• Bit Rate: 64 Kbps to 320 Kbps
• Compression: G.711, G.722.1, G.726, MP3, AAC-LC
• Sampling Rates: 8 kHz to 48 kHz
• Type: Mono
• Noise Filtering: Yes

Network

• Protocols: TCP/IP, HTTP, HTTPS, FTP, RTSP, etc.
• Simultaneous Live Views: Up to 20 channels
• API Support: ONVIF (Profiles S, G, T, M), SDK

Security

• Password protection, encryption (HTTPS, TLS 1.3), IP filtering, and more.

Interface

• Ethernet: 1 RJ45 10/100/1000 Mbps
• Audio: Line in/out
• Alarm: 2 inputs, 2 outputs
• On-Board Storage: Up to 1 TB (microSD)
• Video Output: Composite (for debugging)

General

• Power:
  • 12 VDC, PoE (IEEE 802.3at)
• Material: Aluminum alloy
• Dimensions: Ø144 mm × 347 mm (Without -Y)
• Weight: Approx. 1.95 kg (4.2 lb)

• Table bracket for KH6320/8520 series indoor station
• Working temperature-10 °C to +55 °C (14 °F to 131 °F)
• Dimension (W × H × D)122 × 86 × 64 mm (4.80" × 3.39" × 2.52")
• Material SUS430, silica gel

• Junction Box
• Aluminum Alloy
• Hikvision White
